VALCam Laptop Documentation
Introduction
Thank you for purchasing the VALCam Laptop,
the first image acquisition system designed
specifically for photo-ID and visual database
applications for laptop computers. All camera
controls (pan, tilt, zoom and exposure level) are
available from the mouse or keyboard. Manual
positioning of the camera is eliminated for
increased operator efficiency.
In addition to hands free control, the VALCam
Laptop uses Video Associates Lab's
technology. A high intensity light is automatically
fired with each capture. The VALCam will
automatically adjust for perfect captures.
Software adjustments are provided for exposure,
color intensity, and flesh tone control. High
quality captures with perfect skin tones can be
obtained effortlessly in any environment, even
dark rooms!
Video Associates Labs, Inc.
11525A Stonehollow Dr., Suite 130
Austin, TX 78758
1-800-331-0547
www.VAL.com
Advertisement
Related Manuals for VAL VALCam Laptop Zoom with CamLite
Summary of Contents for VAL VALCam Laptop Zoom with CamLite
- Page 1 Software adjustments are provided for exposure, color intensity, and flesh tone control. High quality captures with perfect skin tones can be obtained effortlessly in any environment, even dark rooms! Video Associates Labs, Inc. 11525A Stonehollow Dr., Suite 130 Austin, TX 78758 1-800-331-0547 www.VAL.com...
- Page 2 A trouble-shooting guide will help resolve installation and operational problems. The Imaging Hints and Tips section will help the end user achieve high quality captures. If technical support is needed please contact: Video Associates Labs Phone: 800-331-0547 Fax: 512-491-7619 Email: support@val.com...
- Page 3 9 pin to 25-pin adapter 110v power cord Universal mounting bracket for lamp Instruction Manual 6500-688 VALCam Laptop Zoom with CamLite High resolution S-video zoom camera VideoVue PCMCIA capture card with software S-video to PCMCIA cable CamLite external power transformer...
-
Page 4: Hardware Installation
Hardware installation NOTE: These instructions cover both the Pan/Tilt/Zoom and Zoom only camera. Follow the directions that are appropriate for your system. NOTE: All cable connectors and matching receptacles have been color coded for easy installation 1. Locate the PCMCIA card and the RCA to S-video cable. - Page 5 4. Pan/Tilt/Zoom Camera connections a. Attach the flash-mounting bracket to the screw hole bottom of the camera. Tighten the bracket knob to secure the bracket to the camera body. Verify that the flash shoe lies behind the camera body and not to the side. b.
- Page 6 d. Locate the multi-cable and attach the brown/black 25 pin D-sub connector to the matching connector on the Zoom camera. 5. Attach the AC power cable for the external box to a power source. Verify that the power switch on the Pan/Tilt camera is in the on position.
-
Page 7: Software Installation
Software Installation. 1. Verifying that the hardware is properly installed and the PCMCIA card is inserted in a PCMCIA slot 2. Power the computer and start windows. 3. The machine will find the new hardware and request a location for hardware drivers. Insert the supplied floppy for your operating system and indicate that the new drivers are located on the floppy (a: drive). - Page 8 Controlling Pan/Tilt/Zoom 1. Place the mouse over the button and hold down the left mouse button. The camera will tilt up. When the mouse button is released, camera motion will stop. The buttons works in a similar fashion. (Pan/Tilt/Zoom camera only) 2.
- Page 9 Capturing and Viewing an Image 1. Verify that the Use Lamp Yes button is enabled. Verify that the Preview Yes radio button is enabled. 2. Using the Zoom and Pan/Tilt controls(only on PTZ camera), frame the subject. Zoom in as tight to subject as image composition will allow.
- Page 10 4. Click the Capture button. The captured image will appear in the dialog box Click the capture button again and note that the lamp will automatically turn on and turn off. You do not have to turn the lamp on prior to taking a capture. 5.
- Page 11 Adjusting Camera and Capture Parameters All camera and capture adjustments are applied through the Adjust dialog box. Separate settings can be applied for both lamp and non-lamp captures. All settings are stored in an INI file and are remembered between sessions.
- Page 12 Using the Adjustment Controls 1. If the lamp is not on, click the Lamp On button. NOTE: The lamp will automatically turn off in about 45 seconds. If this occurs, click the Lamp On button again. 2. Zoom in as tight to the subject as your image composition will allow.
- Page 13 final setting. 8. Adjust the Gain spin control if you are in a very dark room and/or the subject is more than 5 feet from the camera. In most cases a value of 3 will give good results. This control can also be used to make fine adjustments in exposure settings.
- Page 14 Taking a Capture with the Twain Driver 1. Open your application and select the VALCam Laptop twain driver 2. Acquire an image through your application. The VALCam laptop dialog box will appear 3. Verify that the Use Lamp On and Preview Yes radio buttons are enabled.
- Page 15 5. Click the Capture button or press the ‘C’ key and the image will be displayed in the window. If the image is acceptable, click the Save button or press the ‘S’ key to send the image to your application. If the image is not acceptable click the Capture button to take another capture.
- Page 16 to optimize the image 4. Click the Capture button Setting an Administrators Password 1. Locate and double click on the Portable.INI file located in the Windows folder or sub folder 2. The file will open in Notepad. Scroll down and locate the Password=None entry.
-
Page 17: Troubleshooting
Trouble Shooting 1..“Camera Not Found” dialog box displayed when trying to start the application. a. Verify that all cable and camera connections conform to the instructions in the Hardware installation section b. Verify that the software has been installed according to directions c. - Page 18 2. I receive a slew of error messages when trying to start the application. In Win95/Win98SE/ME/2000 check Device Manager to verify that the hardware is properly installed. There should be an entry for Video Associates Labs in the Sound Video Game Controller section.
- Page 19 a. Verify that you have selected the VALCam as the twain source for your application. Consult the your application instructions for selecting a Twain source if you do not know how this is done. b. Verify that the file Twain_32.dll is in your Windows directory.
