Components
A
B
1
2x
2
M3x5mm
Tools Needed
For the latest User Installation Guide please visit: www.ergotron.com
User's Guide - English
Guía del usuario - Español
Manuel de l'utilisateur - Français
Gebruikersgids - Deutsch
Benutzerhandbuch - Nederlands
Guida per l'utente - Italiano
Användarhandbok - svenska
ユーザーガイ ド : 日本語
用户指南 : 汉语
888-97-351-G-00 rev. A • 03/14
C
4x
M4x8mm
LearnFit Basket
D
2x
M5x10mm
User's Guide
MAXIMUM WEIGHT CAPACITY.
< 5 lbs. (2.27 kg)
E
1 of 4
Advertisement
Table of Contents
Summary of Contents for Ergotron LearnFit Basket
- Page 1 < 5 lbs. (2.27 kg) Components M3x5mm M4x8mm M5x10mm Tools Needed For the latest User Installation Guide please visit: www.ergotron.com User's Guide - English Guía del usuario - Español Manuel de l’utilisateur - Français Gebruikersgids - Deutsch Benutzerhandbuch - Nederlands Guida per l’utente - Italiano...
- Page 2 Attach T-slot bracket in the orientation shown making sure you leave enough space between brackets to attach to cart. M5x10mm a. Insert T-slot bracket into T-slot opening on back of cart and slide up to desired location. b. Tighten screws to secure bracket. 888-97-351-G-00 rev.
- Page 3 Attach front bracket. M4x8mm a. Peel paper off back of bump-on and adhere to basket at specifi ed location. b. Attach basket to front bracket. M3x5mm 888-97-351-G-00 rev. A • 03/14 3 of 4...
- Page 4 (150mm) (80mm) 6" (152mm) 3.5" 2.9" (90mm) (75mm) 12.6" (322mm) 3.2" (82mm) 13.6" (347mm) NOTE: When contacting custom- er service, reference the serial number. For local customer care phone numbers visit: http://contact.ergotron.com 888-97-351-G-00 rev. A • 03/14 4 of 4...
