- Page 1 GS-FW035 SINGLE USER ANALOGUE AUDIO INTERFACE PRODUCT DETAILS 6 BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. ENGLAND. TEL: +44 (0) 1622 753662 Visit our Website at www.glensound.co.uk FAX: +44 (0) 1622 762330...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Product Warranty
PRODUCT WARRANTY: All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or... - Page 4 Single User Analogue Audio Interface This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the following Union harmonisation legislation:...
- Page 5 RoHS DIRECTIVE EC directive 2002/95/EC restricts the use of the hazardous substances listed below in electrical and electronic equipment. This product conforms to the above directive and for these purposes, the maximum concentration values of the restricted substances by weight in homogenous materials are: Lead 0.1%...
- Page 6 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR Page 6 of 15...
-
Page 7: Table Of Contents
GLENSOUND GS-FW0035 Handbook Contents Issue 1 Description Page No. Contents PRODUCT WARRANTY: ........................3 OVERVIEW ............................. 8 GS-FW0035 FRONT PANEL LAYOUT ....................9 GS-FW0035 REAR PANEL LAYOUT ....................10 SIMPLIFIED BLOCK DIAGRAM ......................11 SWITCH OPERATION .......................... 12 INTERNAL SIDETONE ADJUST ......................13 WIRING INFORMATION ........................ -
Page 8: Overview
OVERVIEW The Glensound GS-FW0035 is an analogue audio device comprising of a mic input stage with sidetone monitoring, mic output and external audio input monitoring. The GS-FW0035 has two output options, lazy and switched. Lazy Switched Always outputing the mic input signal Only sends the mic audio when the regardless of the switch position. -
Page 9: Gs-Fw0035 Front Panel Layout
GS-FW0035 FRONT PANEL LAYOUT 2. Headphone volume pot 1. Mic on Switch 1. Mic on Switch This switch activates the microphone to send to the ‘Switched output’ and the headphone output (sidetone). The switch illuminates when it is in an ‘on’ position. -
Page 10: Gs-Fw0035 Rear Panel Layout
GS-FW0035 REAR PANEL LAYOUT 4. Lazy Output 1. Headphone output 5. Switched output 7. Four Wire In 8. AC Mains in 2. Microphone input 6. Four Wire in gain 3. Mic gain pot Headphone output This standard 6.3mm (1/4”) stereo headphone socket accepts headphones from 32 to 1000 Ω. -
Page 11: Simplified Block Diagram
SIMPLIFIED BLOCK DIAGRAM Page 11 of 15... -
Page 12: Switch Operation
SWITCH OPERATION Four separate modes are available for the mic on switch. The selected configuration will be stored and reloaded when the GS-FW0035 is powered on. To change the operation of the switch: 1. Turn the device off 2. Hold down the mic on button 3. -
Page 13: Internal Sidetone Adjust
INTERNAL SIDETONE ADJUST There is an internal trimmer pot for adjusting the level of the microphone that is sent to the local headphone output (sidetone). To access the trimmer pot the lid of the unit must be removed. Equipment needed 1x M3 screwdriver Please ensure that the unit is powered off and disconnected from mains before starting this procedure... - Page 14 Page 14 of 15...
-
Page 15: Wiring Information
WIRING INFORMATION XLR & JACK Wiring STANDARD XLR AUDIO PINOUTS: 1: Ground/ Earth XLR SOCKET (FEMALE) 2: INPHASE/ POSITIVE/ MIC + 3: MATE/ NEGATIVE/ MIC - STANDARD HEADPHONE WIRING: TIP: A/ LEFT Ear XLR PLUG (MALE) RING: B/ RIGHT Ear SLEEVE: Common/ Earth RING SLEEVE...
