Videopark C PRO/M Series User Manual

Embedded dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

http://www.videopark.com.cn
Embedded DVR User Manual
2013.8
Email:techsupport@videopark.com.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C PRO/M Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Videopark C PRO/M Series

  • Page 1 Embedded DVR User Manual 2013.8 Email:techsupport@videopark.com.cn...

  • Page 2: Precautions

    1. PRECAUTIONS Please observe the following precautions, in order to avoid damaging or losing data caused by improper operation. DVR should work at proper temperature and humidity. Do not install DVR in humid, dusty or smoky environment. Require a solid mounting surface for installation.

  • Page 3: Note

    2. NOTE This user manual is for reference only, subject to available products. This user manual may contain inaccurate data or printing error. Updates to the manual or products themselves will occur without further notification. The products and manual will be updated regularly without further notice Pictures are not from the same machine, for illustrative purposes only.

  • Page 4: Table Of Contents

    CONTENT 1. PRECAUTIONS............................. 1 2. NOTE................................2 3. PRODUCT INTRODUCTION........................5 3.1. SUMMARY............................5 3.2. FEATURES............................5 3.3. INSTALLATION..........................6 3.4. PANEL INTRODUCTION.........................7 3.5. REAR PANEL..........................14 3.6....25 3.7.... 26 3.8....27 3.9.... 29 3.10. POWER ON/OFF..........................30 3.11. ICON............................... 32 3.12.
  • Page 5 4.7. MAINTAIN............................63 4.8. SHUTDOWN............................ 66 4.9. HYBRID&NVR CHOOSE....................... 66 4.10. IPC CONFIGURATION.........................68 5. WEB&CLIENT.............................70 5.1. WEB OPERATION.......................... 70 5.2. CLIENT OPERATION........................77 6. FUNCTION..............................78 6.1. DDNS FUNCTION...........................78 6.2. PORT MAPPING..........................81 6.3. NTP FUNCTION..........................82 6.4....83 6.5....87 6.6.

  • Page 6: Product Introduction

    3. PRODUCT INTRODUCTION 3.1. SUMMARY Our Embedded Digital Video Recorder is an excellent digital surveillance product which adopts H.264 video compression, hard disk recording, TCP/IP transmission, and a Linux based OS in addition to some of the more advanced technologies in the information technology industry.

  • Page 7: Installation

    COMMUNICATION INTERFACE USB 2.0 high speed interface connecting various backup devices; Standard Ethernet interface, work under various networks. NETWORK PROTOCOL Support TCP / IP, UDP, RTP / RTSP, DHCP, PPPoE, DDNS, NTP etc.; support network real-time live view, recording, playback, control;...

  • Page 8: Panel Introduction

    Connect cable to RJ45 interface when access network. Mouse should be USB interface type, front or back panel USB interface both work. Power supply. CAUTION For an exte DVR powe 3.4. PA 3.4.1. C PRO/M SERIES Front Panel: Diagram 3- 1 Explain: Index Name Function Receive remote control signal;...
  • Page 9 1. Back to previous menu, operation cancel; 2.Back to live view when playing back records. 1. Direction control; 2.Up/Down: The current active control switch, can jump up or down; Direction Activate the digital input box increase or decrease the number; 3.Left/Right: playback speed control.
  • Page 10 Diagram 3- 3 Explain: Index Name Function etection “REC” Receive remote control signal; 1. Back to previous menu, operation cancel; 2.Back to live view when playing back records. 1. Direction control; 2.Up/Down: The current active control switch, can jump up or down;...
  • Page 11 Diagram 3- 4 Explain: Index Name Function Power Power Key, press 5 seconds to turn DVR off; Light Powe,HDD.Net,Alarm,Rec,IR Light; Number Number Key; Playback Key, Stop Key, Function Key,ESC; Direction Up,Down,Light,Right,OK; Connect Mouse, USB Flash Disk, Backup or upgrade;...
  • Page 12 PTZ control to switch different sub-pages when PTZ control. Digital input (Digital input mode). Num Lock Text input (Text input mode). Image switch (Single screen mode). Number (≥10) input: Press this key then press each number, resulting 10+Num Lock in 10 to 19 input.
  • Page 13 3.4.6. HY&N SERIES Diagram 3- 6 Explain: Index Name Function detection “REC” Receive remote control signal. 1. Back to previous menu, operation cancel; 2.Back to live view when playing back records. 1. Keys Direction control; 2.Up/Down: The current active control switch, can jump up or down;...
  • Page 14 3.4.7. HY PRO&N PRO SERIES Diagram 3- 7 Explain: Index Name Icon Function On/Off Power Turn on by short press. 1. Display output switching;2.Text box is selected, a continuous press can different 3.Image g in 10 to pull-down menu to switch the drop-down box options; 3.Activate the digital input box Up and increase or decrease the number;...

  • Page 15: Rear Panel

    1. Play; 2.Come to normal when rewind; 3.Resume playback when pause; Play/Pause ▶ 4.PTZ control: Zoom +. Outside the 1. PTZ control: Aperture, CW +, CCW -; 2.Play control: clockwise the previous, shuttle counter clockwise the next.
  • Page 16 Audio Input Audio input interface. Video/Audio Composite video/audio signal (CVBS) output interface. Output RJ-45 VGA output interface. Power DC 12V. Ports RS-485 Form 3- 8 3.5.2. C SERIES Explain: Index Video Input Composite video signal (CVBS) input interface. Video/Audio Output Composite video/audio signal (CVBS) output interface.
  • Page 17 3.5.3. M SERIES Diagram 3- 12 M0401 Diagram 3- 14 M1601 Explain: Index Name Description Video Input Composite video signal (CVBS) input interface. Audio Input Audio input interface. Video/Audio Composite video/audio signal (CVBS) output interface. Output RJ-45, 2 USB Interface.
  • Page 18 3.5.4. H SERIES Diagram 3- 15 H0401 Diagram 3- 17 H1601 Explain: Index Name Description Video Input Composite video signal (CVBS) input interface. Audio Input Audio Input&1ch. Voice Intercom Video/Audio Composite video/audio signal (CVBS) output interface. Output RJ-45Interface Net&USB...
  • Page 19 3.5.5. P SERIES Diagram 3- 18 Loop DB25 PCB Diagram 3- 19 Explain: Index Name Description Video Input Composite video signal (CVBS) input interface. Audio Input Audio Input&1ch. Voice Intercom Video/Audio Composite video/audio signal (CVBS) output interface. Output RJ-45 Email: techsupport@videopark.com.cn...
  • Page 20 VGA Interface Power AC 220V Ports Alarm,RS-48 HDMI HDMI Interface LOOP The input video signal up to the needs of the other video signal equipment Form 3- 12 3.5.6. HY SERIES Diagram 3- 20 HY0400 Diagram 3- 21 HY0800...
  • Page 21 Diagram 3- 23 HY0801 Diagram 3- 24 HY1601 Explain: Index Name Description Video Input Composite video signal (CVBS) input interface. Audio Input Audio input interface. Video/Audio Composite video/audio signal (CVBS) output interface Form 3- 13 3.5.7. HY PRO SERIES...
  • Page 22 Diagram 3- 26 HY1600 PRO Diagram 3- 28 HY1600 PR-E Explain: Index Name Description Video Input Composite video signal (CVBS) input interface. Audio Input Audio input interface. Video/Audio Composite video/audio sign (CVBS) output interface. Output RJ-45 Email: techsupport@videopark.com.cn...
  • Page 23 VGA output interface. Power Input DC 12V Ports Alarm input/output, RS-485 interface. HDMI HDMI output interface. LOOP Connect the input video out to the other devices. Ports ESATA,RS-232 Form 3- 14 3.5.8. N SERIES Diagram 3- 30 N0800P Email:...
  • Page 24 Diagram 3- 31 N3200 Explain: Index Name Description Video/Audio Composite video/audio signal (CVBS) output interface. Output RJ-45 Power On/Off Power On/Off Ports ESATA,RS-232 POE Net 4 POE Power Ports POE Power DC 48V Form 3- 15 Email: techsupport@videopark.com.cn...
  • Page 25 3.5.9. N PRO SERIES Diagram 3- 32 N3200 PRO Explain: Index Name Description Power On/Off Power On/Off Ports ESATA,RS-232 POE Net 4 POE Power Ports POE Power DC 48V Form 3- 16 Email: techsupport@videopark.com.cn...
  • Page 26 3.6. OTHER INTERFACE 3.6.1. I/O INTERFACE Explain: Index Name Description Alarm Input Alarm Input. Alarm Output Alarm Output. RS-485 RS-485 Form 3- 17 3.6.2. ALARM INPUT Alarm input type support NO/NC. Com ports connect with DVR. NC/NO port connect to DVR.
  • Page 27 3.6.3. ALARM OUTPUT Alarm output is relay output, please refer to the relay parameters to avoid overload and damage the host. Explain: Contact Material Silver Maximum switching power 240VA,48W Electric property Maximum switching voltage 125VAC,60VDC Maximum Form 3- 18 3.6.4.
  • Page 28 Click the combo box drop-down list will pop up. Under 3D PTZ control mode, click the mouse and drag to lower right can achieve 3D PTZ control .drag from lower right to up left, make 3D PTZ control narrow, details refer to 4.1.2 PTZ.
  • Page 29 Diagram 3- 34 Explain: Icon Function Mult Switch the screen Specify the remote control address 1.enter numbers (Digital input state); 2.enter text ( Text input state);3.switch screen (single-screen state) Pause the screen round (screen round state) -/-- Enter the number above 10: press 10 at first, then press this key and the unit digit key 1.
  • Page 30 1. Bring up the function menu in single-screen monitoring state (PTZ control, image color); 2.Set the screen region as dynamic detection with arrow keys; 3. Backspace function: delete a character before the caret in input state (it’s for input method switching if there’s no shift key on the front panel), press 1.5s to clear all the characters;...

  • Page 31: Power On/Off

    Diagram 3- 35 Number Input Interface Diagram 3- 36 3.10. POWER ON/OFF 3.10.1. DVR instal different boot up sta DVR will detect the hardware when power on, the process will last 20 seconds more or less. After the detection, DVR make a “Buzzing”...
  • Page 32 Diagram 3- 37 Note: Power supply has to match with DVR any other substitutes are not allowed 3.10.2. Hold down 【Main Me Diagram 3- 38 Note: turn off device and switch off power when changing HDD. Email: techsupport@videopark.com.cn...

  • Page 33: Icon

    3.10.3. OUTAGE RECOVERY Reboot after an outage or forceful shutdown, DVR will save the record before outage and return to normal operation mode. 3.11. ICON 3.11.1. STATUS ICONS : Record; : Video loss; : Motion detection; : Chan : Adju : Allows 3.11.2.

  • Page 34: Live View

    :Set parameters; :Save parameters; :Restore factory settings, return to the last set of parameters after the modified parameters; :Apply current set to the system; :Copy current set to other channels; :Enter the configuration menu; :Config alarm, video detection trigger’s processing 3.12.

  • Page 35: Operation Guide

    4. OPERATION GUIDE 4.1. RIGHT BUTTON MANU Click the right mouse button after booting into the real-time browser interface, action menu pop-up, shows as 4.1.1. SCREEN SWITCHING Max 16 channel in one screen, user can choose single, four, nine and sixteen channel.
  • Page 36 Diagram 4- 2 【Period】Two periods can be set according to ambient light during the day and night; device will automatically switch configuration time. Need to select the Enable box. 【Hue】Adjust according to image color cast 【Brightness】Visual image brightness, according to the environment, reduces or increases the brightness of the image brightness to make the image relatively clear 【Contrast...
  • Page 37 Diagram 4- 3 【Manual】The highest priority, no matter what the current status of each channel, the corresponding channels will make common recording when press "Manual" button; 【Schedule】Record according to recording type in recoding set. (Common motion Detection and alarm);...

  • Page 38: Main Menu Introduction

    Diagram 4- 4 Default users: User Type User Name Password Administrator Admin 123456 User User 123456 Hidden Default Default Note ter 5 unsuccess dd groups, users and m character input method in mouse mode. 4.2. MAIN MENU INTRODUCTION The main menu as shown, there are search, configuration, storage, output, maintain and shutdown.

  • Page 39: Search

    Diagram 4- 5 【Search】Search recoding by type, channel, time and playback. 【Configur urations. 【Storage】 【Output】 et the 【Maintain factory defa 【Shutdown】Log off the user menu, turn off the machine, restart the system, and switch user and other operations. 4.3. SEARCH In real-time monitoring screen, click the right mouse button, click 【search】, or enter video playback via main menu...
  • Page 40 Email: techsupport@videopark.com.cn...
  • Page 41 Diagram 4- 7 Explain: Index Name Description Record Record and Picture to choice. Calendar Select record search day Channel Choose searched channel Play Playback control: stop/play, pause, fast, slow, previous/next frame in pause. Choose searched recording mode, including whole, outside alarm, motive Recoding mode detection, whole alarm recording.

  • Page 42: Configuration

    Rewind or Manual single frame single-frame playback, single frame playback by clicking (│and│( press the play button when common playback pause ►/( to enter the normal playback playback . Form 4- 3 Remark: 1. The player playback control bar show file playback speed, channel, time, playback progress and other information.
  • Page 43 Diagram 4- 9 【Time】:Set the current time. Note 【Date For l down at a 【Snapsho certain freq ing time.. 【Daylight 【Date Separator】: To select the separator for date. 【Time Format】:24 hr or 12 hr display mode. 【Language】: language selections vary by different model).
  • Page 44 【Device Name】 : Push function of form a complete set of network configuration, display iphone equipment received alarm information device name. 4.4.2. RECORD Base management The “Base management” interface: 【Channel】the channel selection. 【Compression】H.264. 【Resolution】main stream options are D1/CIF, frame rate scope is different depending on channel and resolution. Vice stream support D1/CIF.
  • Page 45 【Picture Quality】6 levels 【Snapshot Rate】set highest capture rate for single channel,1s/pc 2s/pc 3s/pc 4s/pc 5s/pc 6s/pc 7s/pc 8s/pc 【More Configuration】enter 【Configuration】 【Channel 【Date Dis uld not vary 【Channel in displayer or monitor, and varied position can be shown recorder and WEB interface.
  • Page 46 Diagram 4- 12 【Channel】To select channel. Green, yellow and red refer to the normal, MD and alarm recording type. Modify it in【Set】 . 【Snapsho correspond 【Set】Se Diagram 4- 13 【Period】recording time, 6 recording time zone can be set every day.
  • Page 47 【Alarm】For alarm record. 4.4.3. NETWORK Set the DVR network parameters in “Network” interface. The default IP address is 192.168.1.88 Base setting Base setting interface 【DHCP】Enable the DVR to obtain an IP address automatically. If this is enabled, the DVR will reboot and search for a DHCP server, and then assign a dynamic IP address.
  • Page 48 Diagram 4- 15 【PPPOE】enable PPPOE Input PP Operatio n then visit the web 【3G】Inse 【DDNS】 Select DDNS type supports various DDNS currently, include CN99 DDNS, NO IP DDNS, Private DDNS and Dyndns DDNS, Sysdns DDNS with many other compatible and enable the function; input the update server IP, port, DNS, username and password.
  • Page 49 【IP Filter】DVR authority management, if you enable the white list, only the DVR in IP list is allowed to connect. This system supports a max of 64 IPs. 【Multicast】 【Transfer Capability Set】 【Max Connect】range: 0-10, 0 indicates that no connections are allowed.
  • Page 50 【Alarm Center】reserved interface Network status Display the current DHCP PPPoE and IP. 【Push】 Push service and premium version of the Iphone client, the operating interface is mainly used to push the opening of the service function, the current mobile client associated with the hard disk video recorder, even in the case of mobile client did not open, a local of real-time alarm message will be sent to the Iphone for customer inquiries.
  • Page 51 Enable P2P by clicking OPEN, and click OK to finish the device configuration. [Enable]: Open or Close. [Transfer Mode]: Fluency/Latency/None. [Device ID]: Each serial number Of devices are different, this cannot be modified. [Password]: This is generated by the system, you can change it.
  • Page 52 Diagram 4- 19 【Period】 set alarm active period Diagram 4- 20 【Linkage】 on/off 【Record Channel】, 【PTZ】, 【Tour】, 【Snapshot】 linkage and select channel. Email: techsupport@videopark.com.cn...
  • Page 53 Diagram 4- 21 【Abnormity】: enable or disable 【Alarm Out】, 【Show Message】, 【Send Email】 and 【Buzzing】 Time delay Notic Video det 【motion d 【zone set 【Sensibility】6 grades 【management】as same as local alarm 【preview】alarm preview 【video lose】detect video loses and alarm 【management】as same as local alarm...
  • Page 54 There is no limit to the number of groups or users. By default there are two different group levels: admin and user. User management determined upon two levels: the group and the user level. Group and user names cannot be duplicated, and each user can only belong to one group.

  • Page 55: Storage

    Click【Save】to confirm Password can be in 1-6 numbers, letters or symbol; blank in beginning and end is invalid. The account with management authority could change others’ password. 4.4.6. ABNORMITY Abnormity interface 【No Disk】alarm when HDD is not present or can not be detected.
  • Page 56 Diagram 4- 24 Base Configuration “Base Con Diagram 4- 25 【Format】it is possible to format an individual HDD. Note: Hard disk format operation result in the loss of video data 【Set】to set HDD as read-write, read only or redundancy mode. In read only mode, video data cannot be covered.
  • Page 57 Diagram 4- 26 Record Record me Diagram 4- 27 4.5.2. RECORD BACKUP Connect an External USB device with the USB port to backup in the “Record Backup” menu Email: techsupport@videopark.com.cn...
  • Page 58 Diagram 4- 28 【Detect】: Identify external USB device and display the device information. 【Backup】 Diagram 4- 29 Back Select the record start-stop time and click【Add】to add in list; duplicate it by inputting the start-stop time again; click 【Delete】to clear the files list.

  • Page 59: Output

    Note: this operation probably cause permanent data loss 4.6. OUTPUT 4.6.1. Set PTZ channel, protocol, address, baud rate, etc. Firstly, set the dome address and ensure the A, B lines of dome and DVR are connected correctly. The configuration...
  • Page 60 Diagram 4- 31 【Channel】Select the channel for PTZ camera 【Protocol】Select associated dome protocol (e.g. PELCOD) 【Address】select associated dome address, default: 1(Note: this address has to correspond with dome address, or the dome wills not control.) 【Baudrate】Select the dome baud rate and control, default is 9600.
  • Page 61 Notice: Some models have no LOCAL ALARM; please refer to the products descriptions. 4.6.3. PORT CONFIGURATION 【Function Genera Keyboard: keyboard connected by port; Transparent port: transparent transmission of data; Protocol Port: port information overlay need to set this Agreement;...
  • Page 62 4.6.4. DISPLAY Display mode can set the unit's display and polling Display Menu 【Transpa 【Channel Note: 1) Channel name up to 48 half-width characters 2) 16 characters is suitable, otherwise some problems happen when multi-screen 【Time Display】: to choose whether time displays on screen 【Channel Display】: to choose whether channel name displays on screen...
  • Page 63 Diagram 4- 35 【VGA Output】to select VGA resolution and refresh rate, default is 1024×768@60Hz. 【TV Adjus 【VGA/TV 【TV Color Tour conf Diagram 4- 36 Setting tour mode and interval between rotation , the time is within 5-120s,the mode include single screen, four-, eight-, nine-, sixteen-screen.

  • Page 64: Maintain

    【Motion Tour Type】: to set the motion detection tour mode 【Alarm Tour Type】: to set the alarm tour mode Note: Shortcut Setting: click the button at the top right corner of the monitoring picture or press the Shift Key to switch, you can control the tour.
  • Page 65 Diagram 4- 38 Select the type and time press the Find, the system will display the log in tabular form, you can also click the backup button to export the log backup to your computer Log type: s elete;...
  • Page 66 Diagram 4- 39 Note: Menu transparency language time format video format IP user ID etc are not restored 4.7.4. 【BPS】sh Note 4.7.5. AUTO MAINTAIN 【Auto Maintain】set auto maintenance items. 4.7.6. ON-LINE USER 【On-line Users】check the current online user’s status.

  • Page 67: Shutdown

    4.8. SHUTDOWN 4 40 【Menu Lo 【Shutdow 【Restart S 4.9. HYBRID&NVR This product can work as Hybrid Mode or NVR Mode. While in Hybrid Mode, it can support both Analog cameras and IP cameras. While in NVR Mode, it can support IP cameras only.
  • Page 68 Diagram 4- 41 Choose Hybrid Mode or NVR mode according the menu and save setting Channel Mode shows the ability of the product that how m check the product spe After chang Diagram 4- 42 Email: techsupport@videopark.com.cn...

  • Page 69: Ipc Configuration

    4.10. IPC CONFIGURATION 4.10.1. IPC ADD Open【Ma 【channel】 【Protocol 【Device IP】input the IPC IP address; 【Port】input the IPC port; 【User name】input the IPC user name; 【Password】input the IPC password; 【Equipment Testing】input the above parameters, click the Detect button, the device will connect the IPC and return the connection status Search function;...
  • Page 70 Diagram 4- 44 Click the Detect button to enter the search function interface. Select the appropriate protocol type, it will begin search and return the result as shown. IPC and the device must be in the same LAN. Double-click the search result, it will add the device automatically and return to the network channel configuration interface.

  • Page 71: Web&Client

    5. WEB&CLIENT 5.1. WEB OPERATION 5.1.1. NETWORK CONNECTION H Series: Check network connection by LCD on front panel, “ “ refers connection error, P Series: Check B-Lamp on front panel, light indicates connection Set IP, subnet mask and gateway for computer and DVR. Please assign the same segment IP address without router, need to set the appropriate subnet mask and gateway with router.
  • Page 72 Install ActiveX: Right click and choose install. If installation is blocked by Windows, please add the IP as a trusted site or lower your Internet Explorer security settings to allow this. Diagram 5- 2 The following interface will popup when you input your username, password and click “Login”. Interface like Diagram 5-3 Web Interface when user login successfully.
  • Page 73 Other: set capture path, record download path and reboot PTZ control PTZ Control Menu Menu System config, record search, alarm setting, exit, etc. Form 5- 1 5.1.4. LIVE VIEW Into the WEB interface, select the focus window in live window, the focus window has a light blue border.
  • Page 74 Capture: capture of the present channel, set the path in “other”; Sound: on/off sound. Off video: off the focus window video. 5.1.5. Set protoco Control PTZ direction, step size, zoom, IRIS, preset, tour, pattern, border scan, light, wiper, auto pan, etc.
  • Page 75 Diagram 5- 7 Border scan Operation: in the left /right marg Preset Operation: Tour Operation: select “Tour”; Point between the first cruise line cruise input box value. And input numbers in “Path” and “preset”. Click【Add Preset】to adds one preset in the cruise path, and repeat to add additional presets. Click 【Clear Preset】to delete a preset, repeat to delete more.
  • Page 76 5.1.6. CONFIGURATION Access DVR local configuration menu by click “System Setting”, the further details please refer【Local operation guide】. 5.1.7. Click “Sear Search record By selecting the record type, start and end times, and click the check button, get a list of files on the DVR. Select the...
  • Page 77 5.1.8. Click the Choose type of alarm on menu, monitor video loss, motion detection, and disk full, disk error, video mask, external alarm. Click 【Video Pop-up】, open the video loss, motion detection, hard disk full, hard disk failure, video block, video encoder alarm pop-up linkage.

  • Page 78: Client Operation

    5.1.9. Please refe 5.2. CLIENT OPERATION Please refer to IMS 200 Description Email: techsupport@videopark.com.cn...

  • Page 79: Function

    6. FUNCTION 6.1. DDNS FUNCTION 6.1.1. SUMMARY Dynamic DNS is a kind of system which point internet domain name to variable IP. According to the rule of internet domain name, domain name must associate with the fixed IP address. Dynamic DNS provide a fixed Name server for the dynamic domain, and then guide the domain search to the IP address of dynamic user through Name server, which can make the outside user connect to the dynamic user’s URL.
  • Page 80 Best advice: amend the basic configuration of DNS server to the router's DNS servers. 5. After successful registration, click 【OK】,complete preservation. 6.1.3. NO-IP(www.no-ip.com) Register Register new username at no-ip, click 【Create Account】. Create domain name, click 【Add a Host】.
  • Page 81 Port Domain Name xxx.xxx.com User Name Password xxxxxx Form 6- 2 6.1.5. TEST AND VERIFY DDNS After setting the Embedded DVR, wait for a few minutes, analysis records will update. Click Operation in the Menu of computer, input “cmd”, click “OK” to open a window. As the shows.

  • Page 82: Port Mapping

    The computer will analyses the domain name confabulated in DVR, and return to the current IP, as the picture shows underlined in red. When the IP correspond to the embedded DVR’s IP in Public internet, it means the DDNS is setting right.

  • Page 83: Ntp Function

    Enter into the Router management interface; detect the port if there is already a Port mapping. If there is, it shows UPnP setting’s finished. The forth step Input the IP address in IE, and add port number of the Embedded DVR, for example: 155.157.12.227:81. If you want to enter by the Client Software, use the TCP port offered by the outer net.
  • Page 84 6.3.1. INTERNET CONFIGURATION Get to the 【CONFIGURATION】→【NETWORK】, choose 【Advanced】, and then choose 【NTP】to set. After the device can access the Internet, NTP server can use the standard NTP server as the time. For example, the server of China’s national research center (IP address: 210.72.145.44). Input the IP address and domain name of relative server at NTP setting.
  • Page 85 Diagram 6- 4 Step size :Controls PTZ direction and speed, e.g. step size 8 is moved faster than step size 1. (Range 1-8, 8 is max value) Click of zoom, focus and IRIS to modify zoom, focus and brightness.
  • Page 86 Diagram 6- 6 PTZ SETTING Click 【P/T/Z】to set【Preset】, 【Tour】, 【Pattern】, 【Border】. Gray keys represent unsupported function. 【Preset】 Click【Pre 【Tour】setting: Select “Tour”, as, input numbers in “Path” and “Preset”. Click【Add Preset】to adds one preset in cruise path, repeat to add more than one preset. Click 【Clear Preset】to delete a preset, repeat to delete more.(clear preset...
  • Page 87 Diagram 6- 9 【Border】setting: Click 【Border】, as. Move camera to left/right Boundary by direction key and click 【Left Border】and 【Right Border】to confirm the setting. 6.4.2. Click “Page cess or quit the camera setting menu. Click “Page Switch” to back to interface Direction key is mainly used to internal menu control i.e.
  • Page 88 6.5. VOICE INTERCOM 6.5.1. SUMMARIZE Embedded DVR Bidirectional Talk: user can talk to remote client software or Web via DVR audio input and output ports; user can listen voice from Client Software and WEB via DVR audio output ports.
  • Page 89 Note: Make sure 2pcs HDD at least in DVR, one for read and write, another for redundancy. Channel redundancy configuration User can choose part channels or all channels to set redundancy backup. Please get to 【Configuration】→【Record】, choose redundancy channel, check mark 【Redundancy】.
  • Page 90 5 Relocated Sector Count 7 Seek Error Rate 9 Power-on Hours Count 10 Spin up Retry Count 194 Power temperatures 195 ECC on the Fly count 197 Current Pending Sector Count 198 Disconnection beyond repair 199 CRC cyclic redundancy check...
  • Page 91 7 Statuses It is current statues of HDD’s every attribute after analyzing and comparing above attribute values by S.M.A.R.T, also is important information to judge HDD healthy or not. There are three statuses: Normal, Alarm and Error----which is closely related with Pre-failure/advisory BIT.

  • Page 92: Appendix

    7. APPENDIX 7.1. TERMS Dual-stream Dual-stream: one high bit rate stream for the local HD store, QCIF/CIF/2CIF/DCIF/4CIF coding, other low bit rate stream for network transmission, such as QCIF / CIF coding, I Frame I frame: intra frame image, remove redundant information to compress the transmittal data, also called key frames.

  • Page 93: Hdd Capacity Calculation

    7.2. HDD CAPACITY CALCULATION 7.2.1. REFERNCE OF HDD CAPACITY CALCULATION The first time install DVR, please check if the HDD has installed. The capacity of the HDD There is no limitation of capacity of single HDD to DVR, please choose the HDD according to the Vedios’ saving time.
  • Page 94 7.2.2. HARD DISK PROBLEM Use Detection Tool provided by the HDD manufacturer to detect the Function of HDD to solve data problem. We recommend Seagate and Western Digital. How to detect Seagate HDD a) Get into www.seagate.com, Click Support & Downloads choose Sea Tools, download tool, as...

  • Page 95: Common Faults

    Diagram 7- 3 7.3. CO DVR star Possible re The s There is a problem with the DVR main board error, please contact supplier. There is an HDD error. Replace faulty HDD. Remote control does not work Possible reasons: Check for batteries in remote control , especially Positive and Negative;...
  • Page 96 PTZ decoder, protocol, baud rate, address are incorrect; Parallel connect a 120Ω resistance to resolve signal reflex caused by too many PTZs on the line. The RS-485 port on DVR is defective Blurred screen in preview mode Possible reasons: Please make sure your cameras match your video format selected in the General menu.
  • Page 97 Email: techsupport@videopark.com.cn...
