Lucky Duck Super Swimmer HD 10516-0 Quick Start Manual

Thank you for purchasing the Super Swimmer HD. To see more Lucky Duck™ products please visit your local Sporting
Goods dealer or online at www.luckyduck.com.

Directions for use:

Step 1: Unpack the box and make sure all parts are present.
Parts include:
1 – Super Swimmer HD body and battery module
1 – 12 Volt Rechargeable Battery
1 – 12 Volt Charger
1 – Dual jet propulsion system
Charge your battery before use. A fully drained battery will take approximately 8-10 hours to charge.
To Recharge the 12 Volt Battery: (NOTE THIS IS A 12V BATTERY SYSTEM – DO NOT MIX WITH 6V BATTERIES)
Step 1: Remove the battery from the module under the decoy and remove the wires from the battery.
Step 2: Connect the red clip on the charger to the red battery post and the black clip to the black battery post.
Step 3: Plug the charger into a wall outlet. The LED light on the charger will turn red after a few seconds during charging
and green once the battery is fully charged.

Battery installation:

Step 1: Locate the battery module on the underside of the decoy.
Step 2: DO NOT CROSS THE TERMINAL WIRES: Two wires (1 red and 1 black) will be exposed once the battery
module is removed. If you do not see the red and black wires they may still be inside the decoy. Simply locate the
wires inside the decoy and move the wires to the outside of the decoy body. Attach the red lead wire to the
positive battery terminal (Red Terminal on Battery) and attach the black lead wire to the negative battery terminal
(Black Terminal on Battery).
Step 3: Insert the battery on its side into the battery module.
Step 4: A two position switch is located in the battery module. Timer mode will run the decoy for 10 seconds on and 5
seconds off. On/Remote mode will run the decoy constantly or run the decoy utilitizing the Lucky HD Remote Kit
(sold separately).
Step 5: Screw the module onto the bottom of the decoy.

Dual jet propulsion system:

Step 1: Slide the dual jet propulsion system over the water pump outlet.
Step 2: Simply adjust the jets in the desired direction. The dual jet system is flexible and can be arranged in many
configurations. Point the jets stragith back for a natural swimming motion, point one jet out of the water for a spray
while the other jet swims the decoy, turn one jet off to the side to create a circling mtion, etc. – the options are
limitless.
Super Swimmer HD™
#10516-0
