Summary of Contents for Electrify America innogy eBox professional

Page 1 Dock installation instructions...
Page 2 DOCK INSTALLATION INSTRUCTIONS...
Page 3: Table Of Contents
Electrical connection Single power supply line to the Dock Almost done: electrical tests and sealing Clicking the charger into the Dock Linking the charger to the Electrify America app Dismounting Disposal Legal notice In case of questions or problems with this product please contact Electrify America Customer Assistance: 1-833-532-2778.
Page 4: Important Safety Instructions
DOCK INSTALLATION INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. WARNING When using electric products, THEY MUST BE PROVIDED TO always follow basic precautions, including the following: EACH NEW OWNER. DANGER Risk of fatal injury This symbol in conjuction with the key word DANGER indicates an imminent danger. It will cause death or severe injuries if not avoided.
Page 5 Electrify America Customer time during installation or Assistance at 1-833-532-2778. CAUTION operation! Only trained personnel • Electrify America is not responsible Ensure that all components are should open the Dock. for physical injury, damage to dry throughout the installation.
Page 6: Qualifications For Electrical Work
However, there is no guarantee that inter ference will innogy eBox professional with Wi-Fi not occur in a particular installation. innogy SE If this equipment does cause Model: innogy eBox professional...
Page 7: Electric Vehicle Charger Characteristics
IMPORTANT SAFETY INSTRUCTIONS Electric vehicle charger characteristics 1. The product must be connected 3. The product can be installed to AC supply power. on walls. 2. The product can be installed and 4. The Dock and charger together used in indoor and outdoor areas. are rated electrical protection class IP I.
Page 8: Product Overview
DOCK INSTALLATION INSTRUCTIONS Product overview Together, the Dock and charger unit form the home charging solution for electric vehicles. Thanks to its modular design, the Dock can also be installed without the charger, which is then fitted at a later time. The Dock can be mounted on a suitable wall.
Page 9: Dock - Product Details
PRODUCT OVERVIEW Dock – product details Dock Contact guard Cable routing plates Locking bracket Mains board Sealing plug Interface board Specifications Measurements H x W x D 1'-4" (399 mm) x 6" (155 mm) x 2 ½" (62 mm) Installation type Wall Weight Approx.
Page 10: Installation Instructions
DOCK INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS. SAVE THESE INSTRUCTIONS. THEY SHOULD BE PROVIDED TO EACH NEW OWNER. Installation summary 1. Checks: Make sure that the circuit breaker has been DANGER installed in the sub-panel on the power supply circuit to Danger of electrical shock this device.
Page 11: Compatible Electrical Network Type
INSTALLATION INSTRUCTIONS CAUTION CAUTION For space reasons, the supply When multiple charging points line chosen must have, are to be installed, every tenth whenever possible, a cable must be provided with additional size no greater than 10 AWG earthing. (6 mm²). Compatible electrical network type Split phase Connection: L1, L2, PE...
Page 12: Choosing The Site
DOCK INSTALLATION INSTRUCTIONS Choosing the site Consult the customer concerning the choice of a suitable holes of the Dock, connect the studs using the associated site. The optimal site for the charging station depends brackets. Ensure that the correct channel strut nuts are on the owner’s needs and the parking and wiring used and use 5/16"...
Page 13: Tools Needed
INSTALLATION INSTRUCTIONS Tools needed To mount the Dock on a wall, you will need a spirit level, with torque display. You will also need a side cutter, the drilling template provided in the packaging, a pencil a pair of round nose pliers, and, for cable assembly, or other marker, an 0.315"...
Page 14: Information On Mounting
DOCK INSTALLATION INSTRUCTIONS Information on mounting The Dock is secured through three screw holes to the wall. To start, place the rear side of the Dock on a flat surface, and remove the contact guard. The contact guard is clipped without screws to the Dock. It is replaced after the connection to the main power supply.
Page 15 INSTALLATION INSTRUCTIONS Drill the holes with an 5/16" (8 mm) bit, and insert the provided wall plugs. If the provided screws are unsuitable for the wall type at the chosen location, use another type of suitable fastener. CAUTION Screw the Dock to the wall using the Insert the provided sealing You must insert the provided screws provided.
Page 16: Preparing The Electrical Connection
DOCK INSTALLATION INSTRUCTIONS Preparing the electrical connection Make sure that the hole in the cable routing plate is facing the side where you want to insert the supply cable. If not, pull out and change over the plates. CAUTION When inserting the cable routing plates, make sure that they are flush.
Page 17: Welding Detection
INSTALLATION INSTRUCTIONS Cable routing plate Drill a suitable hole for the M20 cable gland using the step drill. Drill step by step to ensure that the hole is not too large and that there is no leakage after the cable gland has been installed.
Page 18: Electrical Connection
DOCK INSTALLATION INSTRUCTIONS Electrical connection DANGER WARNING Installation is made much easier by using the HAZARD OF ELECTRIC SHOCK, The conductor size may not pre- wired NEMA 14-50 power plug and inserting it EXPLOSION, OR ARC FLASH. exceed 7 AWG (10 mm²) into a standard NEMA 14-50 outlet that is installed ENSURE THAT POWER IS OFF! (bending radii of the cables).
Page 19: Almost Done: Electrical Tests And Sealing
INSTALLATION INSTRUCTIONS Almost done: electrical tests and sealing Once all cables have been configured and secured as depicted in the respective figure, tighten the screws (if necessary). You may now switch in the voltage and conduct the electrical tests. DANGER There is a risk of electric shock and danger to life and limb.
Page 20: Clicking The Charger Into The Dock
DOCK INSTALLATION INSTRUCTIONS Clicking the charger into the Dock After the electrical installation, the charger can be clicked into the Dock. Before mounting the charger, make sure there is no voltage across the Dock by unplugging the power cable or by disconnecting the main power supply at the circuit breaker.
Page 21 CLICKING THE CHARGER INTO THE DOCK WARNING Make sure that the flat ribbon data cables are not trapped between the Dock and charger when mounting the charger. Place the charger carefully Keep a firm hold on the If necessary, readjust the on the Dock, and push in charger while pulling down locking bracket until it is...
Page 22 DOCK INSTALLATION INSTRUCTIONS WARNING NOTE Make sure that the charger The set screws should only clicks correctly into the Dock. be fully inserted when the Marking of the locking clip is locking clip is fully inserted in end position. Set screws and properly aligned.
Page 23: Linking The Charger To The Electrify America App
After the preceding steps, you can switch on the voltage. Bear in mind that the charger does not light up until you have approached it within one meter. You are prompted to link to the charger via Bluetooth . For this you will need the Electrify America app. ® Linking during installation for private use:...
Page 24: Dismounting
DOCK INSTALLATION INSTRUCTIONS Dismounting Only a qualified electrician should dismount the Dock. charger and the Dock. Now remove the contact guard from the dock, and detach the supply cable and, if You must disconnect the main power supply before fitted, the Ethernet cable to the local network. Unscrew dismounting the charger.
Page 25 NOTES...
Page 26 DOCK INSTALLATION INSTRUCTIONS...
Page 27: Legal Notice
LEGAL NOTICE Legal notice Copyright © 2019 Electrify America. All rights reserved. This document is copyright-protected. It may not be changed, reproduced, or distributed without the prior agreement issued in writing by Electrify America. Electrify America, LLC 2003 Edmund Halley Drive...
Page 28 In case of questions or problems with this product please call Electrify America Customer Assistance: 1-833-532-2778. Electrify America, LLC 2003 Edmund Halley Drive 2nd Floor, Suite 200 Reston, VA 20191...
