Reel Parts Diagram
CAUTION: The Air Hose System is rated for dry, indoor use only.
DO NOT OPERATE IN WET ENVIRONMENT
This Quick Start Guide does not replace the User Guide. For complete details and precautions concerning this product, read all instructions in the User Guide provided
Portable Air Hose Reel
Quick Start Guide – Page
IF YOU HAVE ANY QUESTIONS OR DIFFICULTIES CALL OUR CUSTOMER SUPPORT TEAM: 1-888-GR8-STUFF
1.
Connect Power
1. Plug Power Entry Cable securely into AC outlet.
* The unit will emit a tune, indicating it is ready to use
3.
Connect Air Tool
1.
Connect air tool / device to Quick Coupler
2.
Extract hose / tool to desired working length
1-888-GR8-STUFF
1
2.
Connect Air Supply
1. Connect Air Input Hose to air supply
CAUTION: DO NOT EXCEED 300 PSI PRESSURE
4.
Remove Tool / Retract Hose
1. Disconnect tool from Quick Coupler by pulling
down then pushing upward on coupler.
2. Press Remote or Dome Retract Button to reel in
hose
then
push
pull
first
www.roboreel.com
Doc. No. 070-000139-01, Rev 1
