12 Volt Load Control for Electric
Brake Systems No. 1300-78
Installation Instructions
P-1385
819-0128
Advertisement
Table of Contents
Related Manuals for Altra Industrial Motion Warner Electric 1300-78
Summary of Contents for Altra Industrial Motion Warner Electric 1300-78
- Page 1 12 Volt Load Control for Electric Brake Systems No. 1300-78 Installation Instructions P-1385 819-0128...
-
Page 2: Specifications
The Warner Electric Load Control provides the For under-dash mounting proceed as follows: capability to properly proportion the braking 1. While holding the Load Control case in power of the trailer brakes to the trailer weight. position, mark the underside of the The Load Control is a variable resistor which instrument panel through the two mounting allows the operator to reduce current flow to the... - Page 3 NOTE: Use only 10 or 12 gauge wire meeting SAE Behind Instrument Panel Installation Specification J558a for connecting the Load Remove the jam nut from the Load Control shaft Control. and insert the shaft and the washer projection into the holes provided in the front portion of Strip the insulation back about 1/4"...
- Page 4 Warranty Warner Electric LLC warrants that it will repair or replace (whichever it deems advisable) any product manufactured and sold by it which proves to be defective in material or workmanship within a period of one (1) year from the date of original purchase for consumer, commercial or industrial use. This warranty extends only to the original purchaser and is not transferable or assignable without Warner Electric LLC’s prior consent.
