D-1 Instructions

TO BEGIN:

• Connect instrument cable to the IN jack.
Connect amplifier cable to the OUT Jack. If using
an AC Adapter, connect to DC-9V jack. Or use
9Volt battery.
• LED light will be on when foot switch is
activated.

CONTROL FUNCTIONS:

LEVEL: This control sets the level of the output to
the amplifier.
TONE: Rotate this control to adjust the EQ.
DISTORTION: Use this control to set the amount of

Distortion.

caution:
This is a high gain device. Start with the LEVEL
control at 25% and then advance as needed.
FAB
Distortion
DISTORTION:
Adjusts the amount Adjusts the EQ
of Distortion
INPUT
BATTERY: Uses one S-006P 9-Volt Battery. Danelectro "Vintage Power
Source" batteries are recommended.
BATTERY ELIMINATOR: Uses 9-Volt Battery Eliminator.
Polarity: Center Negative (-). 300mA maximum. Danelectro "Zero Hum"
Battery Eliminators are recommended.

TONE:

LEVEL:

Adjusts the
output level
9V DC OUTPUT
