- Page 1 HIQUEL HIQUEL-MBUS-Konverter HIQUEL-MBUS- Converter Hardware- user manual...
- Page 2 This manual may not be copied in part or whole in any form including electronic media without the written consent of HIQUEL. Neither may it be transferred in any other language suitable for machines or data processing facilities. Also rights for reproduction through lecture, radio or television transmission are reserved.
- Page 3 HIQUEL HIQUEL-MBUS-Konverter History Datum Author Description 30.06.06 O. Reisky First version 27.09.06 H.Weiß Add-on of the function query pause 15.12.06 H.Weiß Add-on of the tested counters 05.03.07 M. Niederl Add-on of the tested counters 16.01. 08 M. Niederl Discription of the system registers...
- Page 4 HIQUEL HIQUEL-MBUS-Konverter Caution! You are handling dangerous electrical current! Disconnect the supply voltage before making any wiring modifications. Ensure that the system cannot be switched on accidentally. Ensure that the device and its surroundings are potential free. Please refer to the specific installation and mounting instructions.
- Page 5 HIQUEL HIQUEL-MBUS-Konverter Safety-related advice Danger to life through electrical current! Only skilled personal trained in electro-engineering should perform the described steps in the following chapters. Please observe the country specific rules and standards for the mini module installation. Do not perform any electrical work while the device is...
-
Page 6: Table Of Contents
HIQUEL HIQUEL-MBUS-Konverter Content HISTORY CONTENT INTRODUCTION BLOCK CONNECTION DIAGRAM ESCRIPTION ONNECTION BLOCK DIAGRAM DESCRIPTION OF THE FUNCTIONS TECHNICAL DATA IMENSIONS LECTRICAL DATA APPENDIX ESTED METERS CONTACT Seite 6 von 21... -
Page 7: Introduction
HIQUEL HIQUEL-MBUS-Konverter Introduction Since the data from SLS-500-MBUS-MODBUS Converters can be read from any Modbus-Master (automated control, visualisation system etc...) a very broad range of applications becomes possible. For instance data from a heat meter can be easily represented on a mimic display. Each MBUSMODBUS Converter... - Page 8 HIQUEL HIQUEL-MBUS-Konverter Specification supply voltage 24 V= operating conditions -40...85 °C power consumption 1 VA Tolerable humidity 10...90 % rH non condensing degree of protection IP20 (EN 60529) Modbus interface protection class IP20 protocol Modbus/RTU type RS232 or RS485 block connection...
-
Page 9: Block Connection Diagram
HIQUEL HIQUEL-MBUS-Konverter Block connection diagram Description version with RS232 connection version with RS485 connection Figure 4-1: Description of terminals and indications. SLS-500-MBUS-MODBUS- SLS-500-MBUS-MODBUS- RS232 RS485 supply voltage supply voltage L+: 24 V=; M-: ground L+: 24 V=; M-: ground RS232 Modbus interface... -
Page 10: Connection Block Diagram
Touch Panel, etc. < 3 A M-Bus meter M-Bus meter M-Bus meter (1,5 mA load) (1,5 mA load) (1,5 mA load) Up to 8 separate M-Bus meters 1,5 mA each can be connected per HIQUEL-MBUS- MODBUS Converter Seite 10 von 21... - Page 11 Touch Panel, etc. < 3 A M-Bus meter M-Bus meter M-Bus meter (1,5 mA load) (1,5 mA load) (1,5 mA load) Up to 8 separate M-Bus meters 1,5 mA each can be connected per HIQUEL-MBUS- MODBUS Converter Seite 11 von 21...
-
Page 12: Description Of The Functions
HIQUEL HIQUEL-MBUS-Konverter Description of the functions The SLS-500-MBUS-MODBUS converter automatically reads preconfigured values from MBUS meters and makes them available in Modbus holding registers. Up to 100 values can be read via Modbus. On application of the supply voltage the converter verifies if a valid configuration is available or not. - Page 13 HIQUEL HIQUEL-MBUS-Konverter • PRESET SINGLE REGISTER (function code: 6) • PRESET MULTIPLE REGISTERS (function code: 16) Note: The functions READ HOLDING REGISTER and PRESET MULTIPLE REGISTERS are limited to max. 50 register per query! Overview of the registers: 4x00001 Modbus address...
- Page 14 HIQUEL HIQUEL-MBUS-Konverter System registers: Version of the converter software Error code Device status Start Register Short name type address value Software version SWVERSION read 4x00301 Error code ERRCODE read 4x00302 status device 1 SLAVESTATE1 read 4x00303 status device 2 SLAVESTATE2...
- Page 15 HIQUEL HIQUEL-MBUS-Konverter Software version: SWVERSION Holding Register (4x00301) factory setting: - MAJOR MINOR RELEASE description MAJOR main version range: 0 to 15 MINOR secondary version range: 0 to 15 RELEASE issue range: 0 to 255 Error code: ERRCODE Holding Register (4x00302)
- Page 16 HIQUEL HIQUEL-MBUS-Converter State device x: SLAVESTATEx Holding Register factory setting: - (4x00303...4x00310) SLAVEADR SLAVESTATE description SLAVEADR Meter-Bus address of the device range: 0 to 255 SLAVESTATE device state 0: not configured 1: ready for initialisation 2: send the initialisation 3: wait for answer...
- Page 17 HIQUEL HIQUEL-MBUS-Converter Identification number device x: The identification number is derived from the M-Bus protocol header and is stored as a signed 32-bit binary number in 2 Modbus registers. SLAVEIDx (1. Register) Holding Register factory setting: - (4x00313, 4x00315, ... ,...
-
Page 18: Technical Data
HIQUEL HIQUEL-MBUS-Converter Technical Data Dimensions Figure 6-1 Housing type – dimensions in mm. dimensions installation dimensions B x H x T (mm) 22,5 x 85 x 70 weight 85 g colour grey (RAL 7012) ® Noryl (housing) ® material Wellamid (terminals) ®... -
Page 19: Electrical Data
HIQUEL HIQUEL-MBUS-Converter Electrical data voltage, current, temperature supply voltage nominal voltage 24 V= voltage range 18 V= to 30 V= typically 36 mA= current drain max. 55 mA= max. switch-on current 100 mA= (20 ms) operating conditions 0 °C to 60 °C storage temperature -20 °C to 85 °C... -
Page 20: Appendix
HIQUEL HIQUEL-MBUS-Converter Meter-Bus interface physics Meter-Bus carrying out terminals to the supply voltage and the Modbus electrical isolation interface power supply for external devices max. 8 devices á 1,5 mA per participant status indication send and receive 300 to 38400 baud, 8 data bits, even parity,... -
Page 21: Contact
HIQUEL HIQUEL-MBUS-Konverter Contact HIQUEL GmbH Bairisch Koelldorf, Gewerbepark 266 A-8344 Bad Gleichenberg Tel: +43-(0) 3159-3001 Fax: +43-(0) 3159-3001-4 www.hiquel.com e-mail: hiquel@hiquel.com...
