Summary of Contents for Beckman Coulter COULTER AC T ANALYZER Series
- Page 1 COULTER A •T SERIES ANALYZER Roll Printer User’s Guide PN 4237381AA (March 2011) Manufactured for Beckman Coulter, Inc. 250 S. Kraemer Blvd. Brea, CA 92821...
- Page 2 This equipment is used in a manner other than specified. Operate the instrument as instructed in the Product Manuals. r You introduce software that is not authorized by Beckman Coulter into your computer. Only operate your system’s computer with software authorized by Beckman Coulter.
- Page 3 This document applies to the latest software listed and higher versions. When a subsequent software version changes the information in this document, a new issue will be released to the Beckman Coulter website. For labeling updates, go to www.beckmancoulter.com and download the most recent manual or system help for your instrument.
- Page 4 REVISION STATUS PN 4237381AA...
-
Page 5: Table Of Contents
CONTENTS CONTROL PANEL, 1 UNPACKING THE PRINTER, 1 LOADING THE RIBBON CASSETTE, 2 CONNECTING THE PRINTER, 3 Connecting to the Ac·T Analyzer, 3 Connecting to the Power Source, 4 LOADING THE PAPER, 5 PERFORMING A PRINTER SELF-TEST, 7 PN 4237381AA... - Page 6 PN 4237381AA...
-
Page 7: Control Panel
ROLL PRINTER CONTROL PANEL POWER Switch Supplies power to the printer. LF button Feeds paper when the printer is offline. SEL button Sets printer online to the instrument. SEL lamp Lights when the printer is online. Printer will function only when this lamp is on. POWER lamp Lights when POWER switch is ON. -
Page 8: Cassette
ROLL PRINTER LOADING THE RIBBON CASSETTE LOADING THE RIBBON CASSETTE Ensure that the printer’ s power switch is off. 7381002A Remove the printer cover by holding it as shown and lifting up. 7381003A Turn the knob (1) to take up the ribbon slack. -
Page 9: Printer
ROLL PRINTER CONNECTING THE PRINTER Replace the printer cover. 7381005A CONNECTING THE PRINTER Connecting to the A ·T Analyzer · Turn off the A T analyzer. Ensure that the printer’ s power switch is OFF . 7381002A PN 4237381AA... -
Page 10: Source
ROLL PRINTER CONNECTING THE PRINTER Connect the data cable to the printer, as shown. 7381007A · Connect the roll printer to the A analyzer with the data cable, as shown. 7381011A Connecting to the Power Source Connect the ac adapter to the printer. 7381012A PN 4237381AA... -
Page 11: Loading The Paper
ROLL PRINTER LOADING THE PAPER Plug the ac adapter directly into the outlet. Do not use an extension cord. 7381013A LOADING THE PAPER Remove the printer cover by holding it as shown and lifting up. 7381003A Ensure that the end of the paper is straight. Insert the end of the roll into the slot of the printer mechanism. - Page 12 ROLL PRINTER LOADING THE PAPER Turn the printer on. The POWER and SEL lamps light. 7381008A Press the SEL button, then press the LF button until 1.5 to 2 inches of paper feed out of the printer mechanism. 7381009A Move the paper holder to the right, insert the paper, then secure the roll with the holder.
-
Page 13: Self-Test
ROLL PRINTER PERFORMING A PRINTER SELF-TEST Replace the printer cover so that the end of the paper comes out of the opening in the cover. 7381005A PERFORMING A PRINTER SELF-TEST Ensure that the paper and the ribbon cassete are loaded correctly. Turn the power switch OFF . - Page 14 ROLL PRINTER PERFORMING A PRINTER SELF-TEST When the self-printing operation starts, release the LF button. To end self-printing, turn the power switch OFF . 7381002A PN 4237381AA...
- Page 15 TRADEMARKS Beckman Coulter logo, Beckman Coulter and COULTER are trademarks of Beckman Coulter Inc. Beckman Coulter logo, Beckman Coulter and COULTER are registered in the USPTO and SIPO. All other trademarks, service marks, products, or services are trademarks or registered trademarks of their respective holders.
- Page 16 Come visit us at www.beckmancoulter.com Printed on Recycled Paper Copyright © Beckman Coulter, Inc. 1997-2011 All Rights Reserved...
