EXCELiner and EXCELFlex
INSTALLATION INSTRUCTIONS
These 2 types of chimney lining are intended for use with solid,
liquid and gas fired appliances, including wood fired stoves,
fireplaces and furnaces.
The liner should be the size recommended by the appliance
manufacturer.
Use only EXCELiner and EXCELFlex components. Failure to
do so will void the certification and warranty on the product.
Contact local building or fire officials about restrictions and
installation inspection in your area.
Keep these installation and maintenance instructions for future
reference. Take the time to fill up the details of your installation
in section "Installation Reference" at page 4 of this manual.
KEEP YOUR CHIMNEY LINING CLEAN. Inspect your chimney
a minimum of once every two months during heating season.
EXCELiner and EXCELFlex have been tested
and listed to the ULCS635, ULCS640 and
UL1777 Standards by INTERTEK
INDUSTRIAL CHIMNEY COMPANY INC
400 J.F. Kennedy, St-Jerome
Quebec, Canada, J7Y 4B7
Tel. :(450) 565-6336
Fax: (450) 565-6519
http://www.icc-rsf.com
L-II-A-2017-05
ICC
Advertisement
Summary of Contents for Industrial Chimney Company EXCELiner
- Page 1 The liner should be the size recommended by the appliance manufacturer. Use only EXCELiner and EXCELFlex components. Failure to do so will void the certification and warranty on the product. Contact local building or fire officials about restrictions and installation inspection in your area.
-
Page 2: Chimney Fires
Do not use the stove again until your chimney lining and stovepipes have been inspected by a qualified chimney sweep or fire department inspector. EXCELiner and EXCELFlex Owner’s Manual... -
Page 3: General Notes
Using a single wall liner above a masonry chimney will cause the rapid accumulation of creosote. If you must extend the chimney above the existing masonry use ICC EXCEL insulated chimney. EXCELiner and EXCELFlex Owner’s Manual... -
Page 4: Installation Safety
At the end of the installation, take the time to fill the information in the table below for future reference. EXCELiner EXCELFlex Chimney liner model Date of installation Dealer Name Dealer Address Installer Name Installer Address EXCELiner and EXCELFlex Owner’s Manual... - Page 5 RIGID LINER - CLEARANCE REQUIREMENTS EXCELiner 5" to 8" DIAMETER CANADA RIGID LINER ULC S635 ULC S640 UL 1777 (existing chimney) (new chimney) 0" from liner to 0" from liner to masonry masonry Any diameter Rigid Liner without 2" ** from outside of 1"...
- Page 6 The following listing labels are affixed on the EXCELiner (rigid liner) and EXCELFlex (flexible liner).
-
Page 7: Installation Instructions
3. Measure the height from the opening in the masonry chimney to the top of the chimney. Lay out the liner lengths to insure that you have the correct parts for the job. EXCELiner and EXCELFlex Owner’s Manual... - Page 8 4. EXCELiner (rigid): Attach the first vertical length to the vertical portion of the tee and fasten with the three stainless steel rivets provided. Don’t attach the horizontal portion of the tee yet. The male end of each liner length should always point downwards. Be sure to put a stainless steel rivet in each pre-punched hole.
- Page 9 (MS) and seal the space between the sleeve and the masonry chimney with cement. 9. Fasten the trim collar to the masonry wall. Installing EXCELiner (rigid) through the fireplace damper area Measure the distance from the top of the masonry chimney to the smoke shelf area immediately above the damper.
- Page 10 Flexible liner can also be used as a substitute for rigid elbows. EXCELiner can be used in combination with all brands of UL and ULC approved flexible chimney liner.
- Page 11 Using adapters for EXCELFlex In general you do not require an adapter if flex is installed below rigid EXCELiner. The male end of an EXCELiner length will fit inside most standard diameter flexible liners (Fig.6). If the flexible liner is installed above the rigid liner, the Flex Adapter (LAF) will be required to connect them properly and is available in a variety of diameters.
- Page 12 Fig.8 Ø Dimension 6 3/8” 10 1/2” 6” 16 3/8” 20 5/8” 6 5/8” 9 1/2” 8” 18 5/8” 21 5/8” EXCELiner and EXCELFlex Owner’s Manual...
- Page 13 Fasten the top support plate to the top of the chimney with silicone, masonry anchors or with thinset mortar. Seal any gaps between the support plate and the masonry with silicone. Fasten the rain cap with the rivets or screws provided. EXCELiner and EXCELFlex Owner’s Manual...
- Page 14 An insulated system will accumulate less creosote and provide better draft than a non-insulated system. Insulation is a code requirement for some installations; see the table on page 5 to determine if insulation is required for your application. EXCELiner and EXCELFlex Owner’s Manual...
- Page 15 (Fig. 12). 8. Once you have fully covered the insulated liner with mesh fasten it in place with two stainless steel clamps per length of stainless steel mesh. EXCELiner and EXCELFlex Owner’s Manual...
- Page 16 Longueur (-) 1 1/2” Fig.11 Fig.12 EXCELiner and EXCELFlex Owner’s Manual...
- Page 17 ICC will only be responsible for repair or replacement of stainless steel components found to be defective under this warranty. In no event shall ICC be responsible for any incidental or consequential damage caused by defects in the EXCELiner and EXCELFlex stainless steel chimney liner system.
