- Page 1 52CC BACKPACK PETROL TRIMMER OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
-
Page 2: For Safe Operation
Never start the engine inside a wear jewellery, shorts sandals or go barefoot. Se- closed room or building. Exhaust cure hair so it is above shoulder level. gases contain dangerous carbon monoxide. WWW.SGS-ENGINEERING.COM PAGE 2 PAGE 3 CALL FOR ASSISTANCE: 01332 576 850... - Page 3 The engine of the product we offer is designed to run place so as to ensure that neither the cutting contact on a mixed fuel, which contains highly flammable with any obstacle when the engine starts. gasoline. WWW.SGS-ENGINEERING.COM PAGE 4 PAGE 5 CALL FOR ASSISTANCE: 01332 576 850...
-
Page 4: Components Location Diagram
Installing the cutting attachment guard Put the cutting attachment guard on the gearbox, attach it with the 2 screws and bracket provided. WWW.SGS-ENGINEERING.COM PAGE 6 PAGE 7 CALL FOR ASSISTANCE: 01332 576 850... - Page 5 The trimming knife will cut and keep the trimmer line in correct length. WWW.SGS-ENGINEERING.COM PAGE 8 PAGE 9 CALL FOR ASSISTANCE: 01332 576 850...
-
Page 6: Fuel And Chain Oil
Unleaded gasoline is recommended to reduce the contamination of the air for the sake of your health and the environment. WWW.SGS-ENGINEERING.COM PAGE 10 PAGE 11 CALL FOR ASSISTANCE: 01332 576 850... - Page 7 9. Stop the engine before refueling the unit. At that time, be sure to sufficiently agitate the mixed petrol in the container. WWW.SGS-ENGINEERING.COM PAGE 12 PAGE 13 CALL FOR ASSISTANCE: 01332 576 850...
-
Page 8: Operation
Overchoking can make the engine hard to start due to excess fuel. When the engine failed to start after several attempts, open the choke and repeat pulling the rope, or remove the spark plug and dry it. WWW.SGS-ENGINEERING.COM PAGE 14 PAGE 15... - Page 9 Such mate- trigger, turn the adjusting rials can stall the head and cause the clutch to slip, resulting in screw counter-clockwise. damage to the clutch system if repeated frequently. WWW.SGS-ENGINEERING.COM PAGE 16 PAGE 17 CALL FOR ASSISTANCE: 01332 576 850...
- Page 10 Change the blade if it has been damaged. Turn off the engine and make sure the blade has completely stopped before checking the blade, and removing any object got caught in. WWW.SGS-ENGINEERING.COM PAGE 18 PAGE 19 CALL FOR ASSISTANCE: 01332 576 850...
- Page 11 10. Keep both feet spread apart in a comfortable stance and yet braced for the possibility that the unit could bounce. Do not overreach. Keep firm footing and balance. WWW.SGS-ENGINEERING.COM PAGE 20 PAGE 21 CALL FOR ASSISTANCE: 01332 576 850...
-
Page 12: Maintenance
Clean the spark plug and check that the plug gap is in the correct range. For a replacement plug, use the correct type. WWW.SGS-ENGINEERING.COM PAGE 22 PAGE 23 CALL FOR ASSISTANCE: 01332 576 850... - Page 13 WWW.SGS-ENGINEERING.COM PAGE 24 PAGE 25 CALL FOR ASSISTANCE: 01332 576 850...
- Page 14 6. Line up the slot on the bottom cap with the hook on the housing, press the cap against the housing until it clicks. WWW.SGS-ENGINEERING.COM PAGE 26 PAGE 27 CALL FOR ASSISTANCE: 01332 576 850...
-
Page 15: Troubleshooting
Store the unit indoor taking necessary measures for rust prevention. When disposing your machine, fuel or oil for the machine, be sure to allow your local regulations. WWW.SGS-ENGINEERING.COM PAGE 28 PAGE 29 CALL FOR ASSISTANCE: 01332 576 850... -
Page 16: Engine Parts Diagram
904287 Inner cover 904249 Knob 904288 Inner cover cap 904250 Knob starter 904289 Tapping screw ST4.2x10 Knob Fuel tank assembly 904251 904290 WWW.SGS-ENGINEERING.COM PAGE 30 Cover for air filter Recoil starter assembly 904252 904291 CALL FOR ASSISTANCE: 01332 576 850... -
Page 17: Parts Diagram
904208 Transmission shaft 904176 Bolt M5x20 903960 Nut M6 904048 Colloid 904210 Nut M4 904178 Location shelf 904211 Gasket ø6x ø12x1.5 904179 Back pack assembly 904212 Lock net 904180 WWW.SGS-ENGINEERING.COM PAGE 32 PAGE 33 CALL FOR ASSISTANCE: 01332 576 850... - Page 18 SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd PETROL BRUSH CUTTER TYPE OF EQUIPMENT: GPBS520 PART NUMBER: APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:...
