MODEL W1871
6" PORTABLE BENCH 
GRINDER 
/LED LIGHTS
w
OWNER'S MANUAL
(FOR MODELS MANUFACTURED SINCE 05/19)
Phone: (360) 734-3482 • Online Technical Support: techsupport@woodstockint.com
COPYRIGHT © MAY, 2019 BY WOODSTOCK INTERNATIONAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
#20270RSKBAL  Printed in China

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W1871 and is the answer not in the manual?

Questions and answers

Related Manuals for Shop fox W1871

Summary of Contents for Shop fox W1871

  • Page 1   MODEL W1871 6" PORTABLE BENCH  GRINDER  /LED LIGHTS OWNER'S MANUAL (FOR MODELS MANUFACTURED SINCE 05/19) Phone: (360) 734-3482 • Online Technical Support: techsupport@woodstockint.com COPYRIGHT © MAY, 2019 BY WOODSTOCK INTERNATIONAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC. #20270RSKBAL  Printed in China...
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    Contents INTRODUCTION........2 ACCESSORIES........22 Woodstock Technical Support ....2 Grinder Accessories ......22 Machine Specifications ......3 MAINTENANCE........23 Identification ........4 Schedule ......... 23 Controls & Components ......5 Grinding Wheels ........ 23 SAFETY..........6 Cleaning & Protecting ......23 Standard Machinery Safety Instructions ..

  • Page 4: Introduction

    Model W1871 (For Machines Mfd. Since 05/19) INTRODUCTION Woodstock.Technical.Support This machine has been specially designed to provide many years of trouble-free service. Close attention to detail, ruggedly built parts and a rigid quality control program assure safe and reliable operation.

  • Page 5: Machine Specifications

    Wheel Material ..................Aluminum Oxide Wheel Diameter ..................... 6 in. Wheel Thickness ....................3/4 in. Spindle Diameter ....................1/2 in. Work Rest ....................... Yes Construction Base .......................Cast Aluminum Work Rest ......................Steel Lamp ........................LED Model W1871 Machine Specifications, Page 1 of 2...

  • Page 6: Identification

    Model W1871 (For Machines Mfd. Since 05/19) Identification Become familiar with the names and locations of the controls and features shown below to better understand the instructions in this manual. LED Light Wheel ON/OFF Switch Guard (1 of 2) Spark...

  • Page 7: Controls & Components

    Model W1871 (For Machines Mfd. Since 05/19) Controls.&.Components Refer to Figures.1–2.and the following descriptions to become familiar with the basic controls and components of this machine. Understanding these items and how they work will help you understand the rest of the manual and stay safe when operating this machine.

  • Page 8: Safety

    Model W1871 (For Machines Mfd. Since 05/19) SAFETY SAFETY For.Your.Own.Safety, Read.Manual.Before.Operating.Machine The. purpose. of. safety. symbols. is. to. attract. your. attention. to. possible. hazardous. conditions.. This. manual.uses.a.series.of.symbols.and.signal.words.intended.to.convey.the.level.of.importance.of.the. safety.messages..The.progression.of.symbols.is.described.below..Remember.that.safety.messages.by. themselves. do. not. eliminate. danger. and. are. not. a. substitute. for. proper. accident. prevention. mea- sures—this.responsibility.is.ultimately.up.to.the.operator!
  • Page 9 Model W1871 (For Machines Mfd. Since 05/19) WEARING.PROPER.APPAREL..Do not wear FORCING.MACHINERY..Do not force machine. It clothing, apparel, or jewelry that can become will do the job safer and better at the rate for entangled in moving parts. Always tie back which it was designed.

  • Page 10: Additional Safety For Bench Grinders

    Model W1871 (For Machines Mfd. Since 05/19) Additional.Safety.for.Bench.Grinders Serious.injury.or.death.can.occur.from.impact.injuries.if.grinding.wheel.breaks.apart.during.use.. Entanglement/amputation.injuries.can.occur.from.being.caught.in.moving.parts.or.in-running.pinch. points..Flying.sparks.can.ignite.explosive.or.flammable.materials..Rotating.grinding.wheels.can. easily.remove.skin..To.minimize.risk.of.getting.hurt.or.killed,.anyone.operating.machine.MUST. completely.heed.hazards.and.warnings.below. SAFE.MOUNTING.&.WORK.AREA. An unsecured EYE.SHIELDS. Place eye shields close to grinding grinder may become dangerously out of wheel and re-adjust as wheel wears down. control during operation. Before use, verify grinder is FIRMLY secured in a location free TOOL.REST.POSITION.

  • Page 11: Electrical

    Model W1871 (For Machines Mfd. Since 05/19) ELECTRICAL Circuit.Requirements This machine must be connected to the correct size and type of power supply circuit, or fire or electrical damage may occur. Read through this section to determine if an The machine must be properly set up adequate power supply circuit is available.

  • Page 12: Grounding Requirements

    Model W1871 (For Machines Mfd. Since 05/19) Grounding.Requirements This machine MUST be grounded. In the event of certain types of malfunctions or breakdowns, grounding provides GROUNDED 120V 5-15 RECEPTACLE a path of least resistance for electric current to travel—in order to reduce the risk of electric shock.

  • Page 13: Setup

    Model W1871 (For Machines Mfd. Since 05/19) SETUP Unpacking This machine has been carefully packaged for safe This machine presents transportation. If you notice the machine has been serious injury hazards damaged during shipping, please contact your authorized to untrained users. Read Shop Fox dealer immediately.

  • Page 14: Machine Placement

    Model W1871 (For Machines Mfd. Since 05/19) Machine.Placement Bench.Mounting Workbench.Load Number.of.Mounting.Holes......4 Diameter.of.Mounting.Hardware.Needed..⁄ " Refer to the Machine.Specifications for the weight and footprint specifications of your The base of this machine has mounting holes machine. Some workbenches may require...

  • Page 15: Assembly

    Test.Run.or connecting Housing the machine to power. Round Knob The Model W1871 comes mostly assembled from the factory. Using the hardware from the Inventory list on Carriage Bolt Page 11, complete the assembly by attaching the LED light housings, safety shields, and tool rests.

  • Page 16: Tool Rest Adjustment

    Model W1871 (For Machines Mfd. Since 05/19) Tool.Rest.Adjustment The tool rest stabilizes the workpiece when grinding. It must always be positioned correctly when using the grinder, to avoid workpiece and possibly operator's hands from being pulled into grinding wheel. ⁄...

  • Page 17: Test Run

    Model W1871 (For Machines Mfd. Since 05/19) Test.Run Once assembly is complete, test run the machine to ensure it is properly connected to power and safety components are functioning properly. Serious. injury. or. death. can. result. from. using. this. machine. BEFORE.

  • Page 18: Operations

    Model W1871 (For Machines Mfd. Since 05/19) OPERATIONS Operation.Overview This machine will perform many types of operations that are beyond the scope of this manual. Many of these operations can be dangerous or deadly if performed incorrectly. The instructions in this section are written with the understanding that the operator has the necessary To.

  • Page 19: Workpiece Inspection

    Model W1871 (For Machines Mfd. Since 05/19) Workpiece.Inspection Wheel.Selection Some workpieces are not suitable for grinding The Model W1871 only accepts Type-1 wheels on a bench grinder. Before.grinding,.inspect.all. with a ⁄ " bore. workpieces.for.the.following: Aluminum oxide and silicon carbide wheels are marked in a somewhat uniform manner by all Hard.Workpiece...

  • Page 20: Wheel Inspection

    Model W1871 (For Machines Mfd. Since 05/19) Wheel.Inspection Before mounting a new grinding wheel, it must be inspected. Do not assume that a wheel is in sound condition just because it is new. Often, damage can occur Warped wheel flanges can increase in shipping, with age, or with exposure to moisture.

  • Page 21: Wheel Care

    Model W1871 (For Machines Mfd. Since 05/19) Wheel.Care When grinding, your safety depends, to a large degree, on the condition of the wheel. A wheel in poor condition could break apart during rotation and injure the operator and others in the area.

  • Page 22: Wheel Dressing

    Model W1871 (For Machines Mfd. Since 05/19) Wheel.Dressing Depending on the type of grinding you do, the grinding wheel may require periodic dressing. There are several different types of wheel dressing Always.adjust.the.tool.rest.and.spark. devices available on the market (see Accessories on deflector.after.dressing.or.replacing.
  • Page 23 Model W1871 (For Machines Mfd. Since 05/19) 3. Remove arbor nut (see Figure 18). Tip: Hold grinding wheel with free hand to stop it from turning while loosening the arbor nut. Note: Nut on left side of grinder has left-hand threads.

  • Page 24: Accessories

    Model W1871 (For Machines Mfd. Since 05/19) ACCESSORIES Grinder.Accessories The following grinder accessories may be available through your local Woodstock International Inc. Dealer. If you do not have a dealer in your area, these products are also available through online dealers.

  • Page 25: Maintenance

    Model W1871 (For Machines Mfd. Since 05/19) MAINTENANCE Schedule For optimum performance from this machine, this maintenance schedule must be strictly followed. Ongoing To minimize your risk of injury and maintain proper machine operation, shut down the machine immediately if you ever observe any of the items below, and fix the problem before continuing operations: MAKE.

  • Page 26: Service

    Model W1871 (For Machines Mfd. Since 05/19) SERVICE Troubleshooting The following troubleshooting tables cover common problems that may occur with this machine. If you need replacement parts or additional troubleshooting help, contact our Technical Support. Note: Before contacting Tech Support, find the machine serial number and manufacture date, and if available, your original purchase receipt.

  • Page 27: Electrical Safety Instructions

    Model W1871 (For Machines Mfd. Since 05/19) Electrical.Safety.Instructions These pages are current at the time of printing. However, in the spirit of improvement, we may make changes to the electrical systems of future machines. Compare the manufacture date of your machine to the one stated in this manual, and study this section carefully.

  • Page 28: Wiring Diagram

    Model W1871 (For Machines Mfd. Since 05/19) Wiring.Diagram Base Electrical Access Panel ON/OFF Ground Switch Motor 120V ON/OFF Motor Switch Gn Bk Neutral SHOCK HAZARD! Disconnect power 5-15 Plug before working on wiring. 120 VAC Run Capacitor Ground Figure.20. W1871 wiring components.

  • Page 29: Parts

    Model W1871 (For Machines Mfd. Since 05/19) PARTS 8. Securely mount machine to stable workbench or stand before starting. 9. Disconnect power before changing grinding wheels, adjusting, or servicing. 10. Only operate with guards and eye shields installed. 11. DO NOT expose to rain or use in wet locations.
  • Page 30 Model W1871 (For Machines Mfd. Since 05/19) Parts.List REF PART # DESCRIPTION REF PART # DESCRIPTION X1871001 PHLP HD SCR M5-.8 X 50 X1871027 FLAT WASHER 6MM X1871002 WHEEL GUARD (OUTER, LEFT) X1871028 KNOB M6-1, D26, 6-LOBE X1871003 HEX NUT M12-1.75 LH...

  • Page 31: Warranty

    Woodstock International, Inc. will repair, replace, or arrange for a dealer refund, at its expense and option, the Shop Fox machine or machine part proven to be defective for its designed and intended use, provided that the original owner returns the product prepaid to an authorized warranty or repair facility as designated by our Bellingham, Washington office with proof of their purchase of the product within two years, and provides Woodstock International, Inc.
