Summary of Contents for XTBA SMART SPLITTER
- Page 1 ISSUE C 11/07/11 35 Fernleigh Road London N21 3AN +44 (0)208 882 0100 +44 (0)208 882 9326 e. mail dmx@xtba.co.uk www.xtba.co.uk. XTBA SMART SPLITTER Manual Page 1 of 3 Product #01501 - Issue C 11/07/2011 © XTBA 1986 – 2012...
-
Page 2: System Operation
TERMINATED via the amber LED (LED not fitted on rear connector units). The Smart Splitter will normally run terminated and the LED will be lit. If the LOOP THROUGH is used the unit will switch out the termination as it is no longer the last unit in the line. - Page 3 19” RACK MOUNTING The rack version of the XTBA Smart Splitter is provided with a pair of ‘ears’ for fitting into a 19” rack frame. The ears are fitted to the unit by removing the two screws on either side at the front of the unit.
