Professional UHF Wireless Microphone Systems
The Studiomaster Professional NT Series is a high quality UHF Wireless technology system engineered for
the most demanding touring environments & installations. This NT Series Wireless systems offers unprecedented
flexibility & versatility. To ensure optimum performance & safety, please follow this instruction manual
carefully. Please retain this manual for future reference. For any complaint, feedback or testimonials please
contact our distributor / dealer.
2...........................................................................................................................................Systems Options
NT Series
Advertisement
Table of Contents
Related Manuals for Studiomaster Professional NT Series
Summary of Contents for Studiomaster Professional NT Series
- Page 1 NT Series Professional UHF Wireless Microphone Systems The Studiomaster Professional NT Series is a high quality UHF Wireless technology system engineered for the most demanding touring environments & installations. This NT Series Wireless systems offers unprecedented flexibility & versatility. To ensure optimum performance & safety, please follow this instruction manual carefully.
-
Page 2: Operating Instructions
1. Features NT-50 RECEIVER NT-60 RECEIVER • High Quality UHF Wireless Microphone System. • High Quality UHF Wireless Microphone System. • Single Fixed Frequency. • 16 Changeable Frequencies. • Backlit Display for Frequency Indication. Easy Setup via Infrared (IR) • •... - Page 3 Front Panel NT-60 NT 60 1. Power ON/OFF Switch: It is used to switch the receiver ON/OFF. 2. IR Sensor: The IR sensor is used for transmitter synchronization. 3. IR Switch: Long press the IR switch to match (synchronize) and set the frequencies between the transmitter and receiver.
- Page 4 3.2 Handheld Transmitter Description: NT-50, NT-60 15V AA 1. Grill: It protects the capsule from damage. It also acts as an effective wind & pop filter. 2. Display: The display on the handheld transmitters of the NT-50 & NT-60 series show different useful operating parameters as mentioned below.
- Page 5 4. Display: The display on the body pack transmitters of the NT-50 & NT-60 series show different useful operating parameters as mentioned below. NT-50: It displays the fixed channel frequency. FREQUENCY 512.300 Transmitter OFF Transmitter ON NT-60: It displays the selected channel number, frequency and battery indication. RF-HI RF-LO 888.888 512.300...
- Page 6 3. Transmitter Settings: Switch on the transmitter. The receiver display shows the RF bargraph reception level, as shown below. • If the transmitter and receiver frequencies are same. • If the transmitter and receiver frequencies are different. NT 60 NT 60 512.300 527.200 512.300...
- Page 7 • Change the channel number on the NT-60 receiver unit using the Set button. Step 1: Long press the Set button to enter the frequency select function. Step 2: Single press the Set button to switch between channels 001 to 016. Step 3: After selecting the required frequency, the channel number icon on the receiver will flash 6 times and the chosen frequency is set.
-
Page 8: Technical Specifications
• Please remove the batteries/ power supply when the product is not being used for a long time. • Do not open any of the components yourself, for repairs please contact an authorised Studiomaster Professional dealer. • Do not use systems with the same frequency at the same place, please separate them by a considerable distance.
