Summary of Contents for CNX CNX-Trio
-
Page 28: Product Description
HDD, USB memory..) in connection with the PC. PRODUCT FEATURES CNX product is a entertainment device that you can play all kinds of file like movie, music, and image on TV. ∙Use for multimedia MPEG (DiVX, Xvid, DAT, VOB, MPG, MPEG) files with connection to TV ∙Play digital photo album with JPEG file format. -
Page 29: Warnings For Use And Safety
WARNINGS FOR USE AND SAFETY Before using this product, please read carefully the user manual first and use product safely. 1. The contents like software, sound source, image are protected according to the related copyright and regulation. The users who violates this regulations are responsible for the infringement of the copyright. -
Page 30: Product Specifications
PRODUCT SPECIFICATIONS Product Name CNX multimedia player MPEG-1/2, MPG, MPEG, DAT, VOB, AVI Movie (DivX 3.x/4.x/5.x, XviD(Except GMC or Qpel option Supported applied file) File Formats Movie MP3, WMA, OGG Vorbis, AC3 Music Photo JPEG Main chip set EM8511 (sigma design), Arm9 266MHz, 32MB SRAM... -
Page 31: Setup Menu
SETUP MENU Setup menu screen of CNX multimedia player is as following. Left white items are Showing setting items. Middle yellow items are showing currently configured values. Right white items shows alternative options can be set for the selected menu item. - Page 32 SETUP MENU Slide Show time : ∙ 1,3,5,7,10,20 sec, Off : Configure the slide show interval for the JPEG files. Press the [PLAY] button on remote control to show images in slide show mode. Start the slide show. The picture will be consecutively showed in the seconds set for the time interval. Subtitle Font Size : ∙...
-
Page 33: Main Menu Screen
Extensions of the music files are mp3, wma, AC3 and ogg. 4. Firmware file - It shows Firmware files of CNX product. Firmware can be easily upgraded by selecting desired firmware from the main screen. Extensions of the Firmware files is upd. -
Page 34: Play Music
PLAY MUSIC ∙You can play the MP3, WMA, OGG vorbis, and AC3 music files. ∙The search function does not work on OGG files. ∙If you want to play the music file, pressing [OK] or [PLAY] button after select a audio. file you want, using △,▽... - Page 35 PLAY MUSIC KEY Label Functions Description ▽ Arrow : Move downward among menu items. ▷ Change the setting value into next higher level. ◁ Change the setting value into next lower level. Select a menu item or plays the chosen file in current folder.
-
Page 36: Play Movie
PLAY MOVIE ∙You can play AVI, MPG, MPEG, DAT, VOB movie files. ∙The subtitle must be saved in same folder with movie file. ∙If you want to play the video file, pressing [OK] or [PLAY] button after select a movie. file you want, using button to select the file. - Page 37 PLAY MOVIE KEY Label Functions Description It turns up volume. Volume goes 3 steps up when you press the button VOL + or long time. It turns down volume in a step The volume goes 3 steps down when you VOL - press it for long time.
-
Page 38: Viewing Photo
VIEWING PHOTO ∙You can play JPEG files. ∙If you want to play the image file, pressing [OK] or [PLAY] button after select a photo file you want, using △,▽ button to select the file. And then, the chosen image file in a certain folder is being shown as the picture slide until the STOP button pressed If you press CH up/down button, it also stop the slide show. - Page 39 VIEWING PHOTO KEY Label Functions Description The screen can rotate at an angle of 90 ▷ It stops slide show. degrees, clockwise direction. The screen can rotate at an angle of 90 ◁ It stops slide show. degrees, counterclockwise direction. EXIT Stops the current displayed file and goes back into file list menu.
-
Page 40: Firmware Upgrade
FIRMWARE UPGRADE <Caution> Do not operate or manipulate the power or remote control while you are upgrading it. CNX product will be upgraded anytime for codec update and bug fix to satisfy user’ ’ s needs. You can download the latest firmware file from CNX homepage. - Page 41 FIRMWARE UPGRADE 5. firmware upgrade screen1 [ Erasing flash ]. 6. firmware upgrade screen2 [ writing flash ]. 7. When upgrading the firmware completed successfully, following screen screen appears. And system restarts automatically.
-
Page 42: Troubleshooting
Then Press [TV OUT] button slowly and change video output mode. 2. If CNX Divx freezes after initial screen appears, and does not proceed to main menu screen. ∙Check out if USB Device is connected well.
