Battery Installation Instructions
WARNING: Disconnect the power to the Crusher Pitching Machine while
installing batteries! Failure to do so may result in bodily injury.
STEP 1: Locate both battery
compartments on the bottom
side of the Fireball pitching
machine.
STEP 2: Locate the Red and
Black battery wires inside the
battery compartment.
STEP 2: Connect the Red wire
to the "RED Colored" battery
post and the Black wire to the
"BLACK Colored" battery post.
Place the battery back into
the compartment, replace the
cover, and tighten the holding
screw.
95 West 650 South • St. George, Utah 84770 • PH: 800-492-9334 • PH: 435-656-1756 • Fax: 435-688-0741
For Machines With Bottom Access Panels
Unscrew the holding screw for one or both compartments.
(Each compartment holds a 4 hour battery for a total of 8 hours)
Each battery compartment will have a pair of Red and Black wires.
The Crusher will run on either one battery or both batteries.
