LARA & MUSIC

IN THE SWITCH

KIT FOR CONROLLING MUSIC, WHICH

PERFECTLY FITS IN YOUR HOME´S INTERIOR.

MUSIC AND INTERNET

RADIO STATIONS PLAYER

IN THE SIZE OF THE SWITCH

www.inels.com/kits

User's manual 2.0

Table of Contents

Need help?

Do you have a question about the LARA and is the answer not in the manual?

Questions and answers

Summary of Contents for iNels LARA

Page 1 LARA & MUSIC IN THE SWITCH KIT FOR CONROLLING MUSIC, WHICH PERFECTLY FITS IN YOUR HOME´S INTERIOR. MUSIC AND INTERNET RADIO STATIONS PLAYER IN THE SIZE OF THE SWITCH www.inels.com/kits User‘s manual 2.0...
Page 2 EVEN YOUR HOUSE CAN BE „HEARD“! Would you like some help? TECHNICAL SUPPORT +420 800 100 671 support@inels.com...
Page 3 LARA plays the music stored in the NASA storage or in the external sour- ce (phone, MP3 player) connected through cable on the front panel of device.
Page 4: Table Of Contents
The overview of other kits ......................................Virtual kits ............................................... LEGEND: LARA-NAS application - application for controlling the music via a Smartphone Network cable - LAN cable for connection LARA PoE adapter LAN (Local Area Ethernet, computer network) computer cables (UTP) distributed throughout the building and connected to the switch.
Page 5: Kit Content
USER´S MANUAL CONTENT MUSIC PLAYER IN THE SIZE OF THE SWITCH - LARA 3 frame - white (90930 TBR) Speakers 2“ LARA Radio - white Speaker cover (21581) (LARA-R/BR) (90710 TBR) LARA Remote LARA PoE adapter Network cable, controller 20 cm...
Page 6: Installation
THE EXAMPLE OF INSTALLATION LARA - can be mounted inside your wall (installation box) or oﬀ ers a surface mounting option. You can use the installation boxes mentioned in the Section “Accessories”. Surface mounting Flush mounting (adapted to be mounted...
Page 7 To terminals OUT +/- OUT +/- you connect speakers cables (Fig.1). To terminals LINE OUT L, LINE OUT R, GND you can connect input to the external ampliﬁ er. Plug a network cable into connector RJ45 (on LARA). Using screws ﬁ x a device to the installation box (Fig. 2). The upper part of music player should be snapped into the frame (LOGUS90 design) - (Fig.
Page 8: Control
CONTROL IP address LARA has a DHCP, what means that LARA automatically assigns itself an IP address from the range of your network settings. In the case of other network settings please contact our technical support or your Internet provider.
Page 9 CONTROL There are 40 preset radio stations in LARA radio, the overview of radio station you can find on page 15. Lock buttons: By long press on the both arrow keys the touch screen will be locked. The locking is indicated by the symbol on the display.
Page 10: Additional Setup
English The setting up a network LARA has a DHCP, what means that LARA automatically assigns itself an IP address from the range of your network settings. In the case of other settings of your network, you can change LARA parameters according to the procedure described below.
Page 11 ADDITIONAL SETTINGS Audio Output Settings output to the speakers connected to terminals OUT L, R OUT Line output to terminals Line OUT L, Line OUT R intended for external ampliﬁ er PA+Line output to both terminals simultaneously (The default audio output is PA) 01.01.2013 12:54 01.01.2013...
Page 12 ADDITIONAL SETTINGS Device reset to the factory default setting After resetting the player, the default IP address is set to 192.168.1.10 and all saved stations will be deleted. There are two ways of resetting: 01.01.2013 12:54 01.01.2013 12:54 01.01.2013 12:54 Radio stations Settings Language...
Page 13: Lara Conﬁ Gurator
ﬁ rmware update of LARA Radio remotely control LARA Radio LARA Conﬁ gurator can simply run without installing the operating systems Microsoft Windows XP, Windows 7 and Windows 8. The condition that allows starting the program is support Microsoft. NET Framework 4 or its installation (free download at www.microsoft.com).
Page 14: Setting Up Radio Stations
40 from 40   Tab „Station List“ is used for the complete management of the list of Internet radio saved on your LARA Radio.  EDIT THE STATION: In the Tab „Edit stations“ you can add a new radio station or modify existing sta- tions in the list.
Page 15 RADIO STATION EDITING THE LIST OF THE PRESET STATIONS 1.FM AMERICAS KISSFM ROMANIA 1.FM LOLLIRADIO 1DANCE.FM MEGAHITRADIO 89.0 RTL OLAFM 100HITZ POLSKASTACJA 181.FM LITE POLSKIE RADIO 181.FM MIX RADIO CONTINU 181.FM ROCK RADIO FREJUS 181.FM RADIO FUNKY ABC 80s RADIO INTERNATIVA ALL HITS STATION RADIO JUNIOR BOING...
Page 16: Additional Setup - Lara Conﬁ Gurator
You can obtain the IP address of connected device using function „Search a device“. Within a few seconds the function „Search a device“ will ﬁ nd all LARA radio connected to a network. In the dialog box „Search a device“...
Page 17: Device Settings
SNTP server: If necessary, enter the IP address of another time server that supports SNTP protocol. Time Zone: Select the time zone in the place of LARA Radio installation to display the correct times. Winter / Summer clock changes can be done using the control tool „Summer time“.
Page 18: Additional Setup
FW update   To update Lara Radio FW it is necessary to download the update ﬁ le with the extension „* .lfw“ from the webpage http://www.elkoep.com/download/software/.  TO OPEN A FILE: Using the button „ open ﬁ le ﬁ le“ the dialog box to search and select the update ﬁ le will appear on your screen.
Page 19: Remote Controller
Control/settings Front panel: Touch buttons IR controller (included in the package) Remore control: Ethernet communication: via PC setup and communication SW LARA conﬁ gurator RESET button: device reset / reset to factory settings Ethernet interface Communications Interface: 0/100 Mbps Connector:...
Page 20: Technical Parameters Of Lara
Used to connect LARA with exter. ampliﬁ er. Reduction 4pin from 5208 LARA LINE OUT to 2x CINCH plug into ampliﬁ er, length 2x20 cm. Used to connect LARA with external ampliﬁ er. Reduction 4pin from LARA LINE OUT to 2x CINCH plug into ampliﬁ er.
Page 21: Accessories
ACCESSORIES - INSTALLATION MATERIAL PICTURE DEVICE DESCRIPTION ORDER CODE 90910 TBR 1-FRAME 2-FRAME 90920 TBR 90930 TBR 3-FRAME 4-FRAME 90940 TBR 5-FRAME 90950 TBR 10976 ABR SURFACE MOUNT BOX 6705 INSTALLATION BOX 1-GANG (KP 67/2) 6706 INSTALLATION BOX 2-GANG (KP 64/2) 6707 INSTALLATION BOX 3-GANG (KP 64/3) 6708...
Page 22 WiFi bridge with PoE and power supply into an installation box. Power supply 230V. POE SUPPLY 5225 Power injector with plug-in adapter 230V. PICTURE DEVICE DESCRIPTION ORDER CODE WIFI BRIDGE Used for LARA wireless connection via WiFi network. 5210 U S E R ´S M A N U A L 2 . 0...
Page 23 Provides LAN connectivity and PoE power supply for up to 6605 5 x LARA. Max. distance between LARA and switch is 10 m at the power supply 12 V, and approximately 20 m at the power supply 24 V. Power supply AC 230 V.
Page 24: The Overview Of Other Kits
THE OVERVIEW OF OTHER KITS THE GAME OF LIGHTS ORDER CODE: 5453 RF SMART 1× COLOURED WIRELESS 3× BULB KIT TO CONTROL LIGHTS VIA SMARTPHONE It has never been easier to set the appropriate ambience for reading a book, watching a movie or a party with friends.
Page 25 THE OVERVIEW OF OTHER KITS HEATING WITH SAVINGS ORDER CODE: 5455 WIRELESS CONTROL × UNIT RF TOUCH WIRELESS × THERMOVALVES KIT TO CONTROL HEATING VIA WIRELESS RF TOUCH UNIT Includes 3 wireless thermovalves that are installed instead the standard radiator valves. They measures the room temperature and send it to the RF Touch control unit.
Page 26 The starter kit consists of 2 x colored wireless bulbs, 1 x switching socket and 1 x camera, what allows you to try the basic units of iNELS RF Control – wireless solution. Everything is preset to ensure fast and easy installation.
Page 27: Virtual Kits
VIRTUAL KITS The virtual kit is a set of wireless units that are packed individually (as an individual product), but on the other hand they are preset together (they are meant to work together) to ensure simple installa- tion. They are oﬀ ered at a discounted price and it is not possible to separate any unit from this price. UNDERFLOOR HEATING - BY WATER Any wireless temperature regulator measures the room temperature, it compares with set temperature and time program, then sends a command to switch on the units.
Page 28 Manufacturer: ELKO EP, Ltd. / Palackeho 493 Holešov - Všetuly 769 01 / Czech Republic Phone: +420 800 100 671 / e-mail: elko@elkoep.com www.elkoep.com...
