Summary of Contents for SoftWheel M Series
- Page 1 USER MANUAL English SoftWheel Ltd. www.softwheel.technology Email: amya@softwheel.technology Telephone: +1-202-749-8666 Number/Version: SW-00-0015/R18...
- Page 2 All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prewritten permission from SoftWheel Ltd. The name SoftWheel and the SoftWheel logo are registered trademarks owned by SoftWheel Ltd. The information in this manual may be subject to change without notice. Number/Version: SW-00-0015/R18...
-
Page 3: Table Of Contents
Accessories Package ........................5 5.2. Tires .............................. 5 5.3. Inner Tubes ........................... 5 5.4. Valve Adapters..........................6 5.5. Push Rim Spacers .......................... 6 Push Rims…............................6 5.7. Axle pins ............................6 SOFTWHEEL SIZES: WHEELS AND BEARINGS ..................8 6.1. Wheels ............................8 Number/Version: SW-00-0015/R18... - Page 4 6.2. Bearings ............................8 ASSEMBLING ACCESSORIES FOR YOUR SOFTWHEEL ................9 7.1. Push Rim Assembly ........................9 7.2. Tire Assembly ..........................10 CONNECTING SOFTWHEELS TO YOUR WHEELCHAIR ................11 8.1. Safety Information ........................11 8.1. ASSEMBLING SOFTWHEELS TO YOUR WHEELCHAIR FOR THE FIRST TIME ......... 11 8.1.
-
Page 5: General
Information about the User Manual Thank you for choosing SoftWheel. The user manual contains important information about your new wheels; please review carefully and follow the safety information to ensure your safety and prevent damage to the product. This information will also help you avoid invalidating your product warranty and maintaining product quality. -
Page 6: Product Identification
Standard precautions should be applied for general safety. Several precautions, however, should be made for the protection of the wheelchair user or assistant. For information about product safety notices and product recalls, please see www.softwheel.technology. Number/Version: SW-00-0105/R2... - Page 7 Softwheel occurs while the wheel-lock is engaged. The chair may move slightly during this disengagement. This may happen, for example, when dropping into the wheelchair during a transfer. It is recommended that the wheel lock be placed above the wheel axle whenever possible.
-
Page 8: Components
• Ensure that you are using the correct stage on your SoftWheel. If you don’t know which stage fits for you, contact your authorized dealer, therapist or medical professional. (See section 15.4). An unsuitable stage will lead to an uncomfortable ride and could negatively impact your SoftWheel riding experience. -
Page 9: Accessories
ACCESSORIES 5.1. Accessories Package Recommended accessories for the standard SoftWheel sizes (24” or 25”): Tires: ETRTO 25-540 or 24 x 1'' or ETRTO 25-559 or 25 x 1'' Inner Tubes: ETRTO 25-540 or ETRTO 25-559 Push rims: 24'' or 25'' Push rim spacers If SoftWheels are not purchased together with accessories, please see below for recommendations for accessory parts (sections 5.2 –... -
Page 10: Valve Adapters
You must use the axle pin type that matches the specification of your wheelchair. • You must choose the correct axle pin diameter that matches both the internal diameter of the SoftWheel bearing and the diameter of the wheelchair’s axle housing unit. - Page 11 • Do not use a metric axle pin with an imperial SoftWheel or an imperial wheelchair housing unit - it will cause a space of 0.7mm between the axle pin and the housing, leading to an uncomfortable ride and negative impact on your SoftWheel riding experience.
-
Page 12: Softwheel Sizes: Wheels And Bearings
• You must choose the correct bearing diameter that will match the diameter of your wheelchair’s axle housing unit. • The axle pin must match both the SoftWheel bearing diameter and the diameter of your wheelchair’s axle housing unit. See section 5.7 for advice on axle diameters and lengths. -
Page 13: Assembling Accessories For Your Softwheel
ASSEMBLING ACCESSORIES FOR YOUR SOFTWHEEL If you purchased SoftWheels with accessories, you will receive your SoftWheels ready for use with the accessories already assembled (you will only need to inflate your tires). If you purchased SoftWheels without accessories, you must follow these instructions to assemble your accessories onto your SoftWheels. -
Page 14: Tire Assembly
Insert the inner tube into the tire Screw the Valve Adapter into the valve Put the tire onto the SoftWheel - the direction of the tire treads should be aligned with the rotation direction of the wheel (see figure) Inflate the tire to the recommended pressure of the tire manufacture... -
Page 15: Connecting Softwheels To Your Wheelchair
• Ensure that you are using the correct SoftWheel size that matches your wheelchair specifications! (see section 6.1) • Ensure that you are using the correct stage on your SoftWheel. If you don’t know which stage is the correct fit for you, contact your authorized dealer, therapist or medical professional. - Page 16 The difference between LEFT / RIGHT wheels: Each wheel is marked with an “L” or “R” to indicate whether it is a LEFT wheel or a RIGHT wheel. This is indicated with a letter on the hub, on the back side of the wheel. The difference between the FRONT / BACK of the wheel: The FRONT of the wheel is the side of the wheel that faces out from your wheelchair.
- Page 17 Remove the axle pin from your old wheel. 5. Insert the axle pin into your new SoftWheel by pushing the axle pin into the SoftWheel hub. Make sure that the axle pin is the correct size & type for your new SoftWheel (See section 5.7).
-
Page 18: Assembling & Removing Softwheels In Everyday Use
The SoftWheel should not move out at all, if it’s properly engaged. 8. Rotate the wheel slowly and ensure that there are no ‘touches’ or ‘rubs’ between the SoftWheel and the wheelchair frame or wheel lock. A minimum clearance of 10mm is recommended. - Page 19 Ensure that you are holding your wheelchair properly. Insert the axle pin into your left or right SoftWheel by pushing the axle pin into the SoftWheel hub. Make sure that the front side of the wheel is directed to you.
-
Page 20: Safety Information Before Use
Hold your wheelchair upright with one hand. Ensure that you are holding your wheelchair properly. With your second hand, remove your left or right SoftWheel from the wheelchair by pressing on the quick release axle pin and pulling the wheel out (see diagram below). -
Page 21: Safety Information During Use
• Before using SoftWheels, ensure that you do not have a tire puncture in one of your SoftWheels. Improper air pressure could lead to potential risk of injury. When using SoftWheels with small front wheels, the wheelchair could possibly get stuck at curbs or on floor grooves. If your front wheels are unsuitable for the surface you’re driving on, it can cause a tip or fall and lead to potential injury. -
Page 22: 9.2. Storage
9.2. Storage • Do not store your SoftWheels in a wet or humid environment! Store your SoftWheels in a dry environment, only indoor. • Do not store your SoftWheels near a source of heat! • Do not store other items on top of your SoftWheels! Do not store your SoftWheels in unstable or broken storage units, this could lead to a risk of injury and/or damage to the product! MAINTENANCE AND GENERAL CONDITIONS... - Page 23 Test descriptions: Tire pressure: It is highly recommended that you check the tire pressure at least on a weekly basis. • Test the tire pressure of your SoftWheels and ensure sufficient air pressure in both tires (not less than the minimum required according to the tire specifications) •...
- Page 24 If the SoftWheels are not engaged properly, remove the SoftWheel and remove the axle pin. Check if there is any dirt or materials in the hub bearing or axle housing unit of your wheelchair. Check to ensure that the axle is adjusted to the correct length (see section 5.7).
-
Page 25: After Use (Disposal)
It is recommended that you have your SoftWheels checked once a year by an authorized supplier to ensure proper operation. AFTER USE (DISPOSAL) To properly dispose of a SoftWheel, contact your local waste service provider for disposal guidelines. Be environmentally responsible; disposal and recycling methods are subject to local and national regulations. TECHNICAL INFORMATION 12.1. - Page 26 Bearings Stainless steel Inserts Nylon 6,6 Screws Stainless steel SoftWheel M Wheel size: 24” / 540mm (ETRTO 25-540mm) or 25” / 559mm (ETRTO 25-559mm) Suspension: Adaptive in-wheel suspension system Weight (without accessories): 1850 gr Load limit: 120 kg Materials: Part Material Pure magnesium (97.5%)
-
Page 27: Accessories
12.1. Accessories Technical information for accessories, if purchased together with SoftWheels: Part Description Size Push Rim 24'' WC AL- Push Rim- Black 24'' 24'' Push Rim 25'' WC AL- Push Rim- Black 25'' 25'' Tire 24'' ETRTO: 25 - 540 Tire 25'' ETRTO: 25 - 559 Inner tube 24''... -
Page 28: General Dimensions
12.4. General Dimensions: SoftWheel 24'' SoftWheel 24'' (with accessories) SoftWheel 25'' SoftWheel 25'' (with accessories) Number/Version: SW-00-0105/R2... -
Page 29: Warranty
NFR pricing. The distributor shall pay all shipping charges or loss connected with the return of the Wheels to SoftWheel for repair or replacement. If a defect will be found in the Wheels, SoftWheels hall return the repaired or replaced Wheel(s) to the distributor at its expense. - Page 30 Limited Warranty may not apply to you. This Limited Warranty set forth herein may not be extended, enlarged or otherwise modified by any SoftWheel dealer, distributor, agent, or employee, and SoftWheel does not assume any liability or make any warranty except as stated in this Limited Warranty.
