NRS Healthcare Linton Plus M53564 User Instructions

User Instructions

Linton Plus Raised Toilet Seat Range
M53163/M53564 - 50mm (2")
M53175/M53576 - 100mm (4")
Maximum User Weight:
30st
190kg

General Safety Warning

Please ensure these instructions are fully
read and understood before installation/
use. Retain these instructions in a safe
place for future reference.

Intended Use

The Linton Plus Raised Toilet Seat has a
contoured form that offers comfort as well as
support with a rear cutaway for the coccyx,
and a front cutaway allows easier personal
cleaning. It is simple to install and maintain. It
has a buffer fitted to the front skirt to reduce
"tipping" of the seat. The seat fits to a
standard toilet with plastic fixing brackets
provided.

Unpacking

Check all parts carefully before assembling
the product.
Do not assemble if any of the parts are
damaged.
Do not assemble if any of the parts in the
Contents list are missing.
CONTENTS LIST
Item Description
1 Linton Plus Raised Toilet Seat
2 Hand Wheel
"L" Shaped Support Bracket
3

Fitting Instructions

1 - Engage the support brackets into the slots on
the seat (See Diagram 1)
2 - Turn the hand wheel clockwise until the
threads engage. Do not tighten any further at
this stage.
Hand
Wheel
Support
Bracket
Fitting to the Toilet bowl:
Qty.
Note: Ensure the toilet to which the seat is being
1
fitted is safe and secure.
2
2 3 - Lift the existing toilet seat up.
Page 1
Seat
Diagram 1
