Aikexin DK104 User Manual

_______________________________________________________________________________
Model:DK104
The 1×4 HDMI Splitter uses a single HDMI sources, accessing to multiple
HDMI sinks. The Splitter allows one HDMI devices to be split easily to eight
HDMI compatible monitors or projectors. The Splitter can also be placed at the
end of a long HDMI cable to regenerate the HDMI signal.

FEATURES

1)HDMI TM (1.3b with 3D & 1080p)
2)Distributes 1 HDMI source to 4 HDMI Displays simultaneously.
3)Supports all the mandatory and several optional 3D formats
4)Supports High Definition Resolutions : 1080p @ 60HZ, 720p/1080i @ 120Hz
5) Supports Digital Audio Format, such as High Definition Audio support: Dolby
TrueHD, and DTS-HD Master Audio
6) DC 5V Power

SPECIFICATION:

Name of the product
Signal Inputs/ Output
HDMI Connector
HDMI Version
HDCP Version
HDMI Resolution
Support video color format
Support audio format
Max bandwidth
Max baud rate
Input cable distance
Output cable distance
Input/output DDC Signal
Input/Output TMDS Signal
Max working current
Power adapter format...
HDMI Splitter
1× 4
User Manual
1× 4 HDMI Splitter
1 input ...4 outputs
Type A 19 pin female
HDMI 1.4v
HDCP 1.3
24/50/60fs/1080p/1080i/720p/576p/576i/480p/
480i
24bit/deep color 30bit 36bit
DTS-HD/Dolly-true
HD/LPCM7.1/DTS/Dolby-AC3/DSD
225MHz
6.75Gps
≤15m HDMI AWG26
≤25m AWG26 HDMI 1.4 standard cable
5 volts p-p (TTL)
0.5~1.5 Volts p-p
1.4A
AC(5OHZ,60HZ) 100V-240V;Output: DC5V
