Stakon COMFORT CRIMP SHURE STAKE ERG4 Instructions For Use

COMPRESSION TOOL WITH SHURE STAKE
For Installing Ferrules 26-1/0 AWG (0.14-50 mm
IMPORTANT:
information in this manual before operating or servicing this tool.
WARNING
KEEP ALL BODY PARTS AWAY FROM DIE NEST
DURING GAGING OR CRIMPING PROCEDURE.
10 16 25
In the event the SHURE STAKE
1.0
1.1

Die Set Installation

Die Screws
REAR
10 16 25 10
Insert
Main Axle
1. Remove die screws from frame with supplied torx wrench.
2. Choose an appropriate die set to match wire gauge.
3. Insert die set into frame. Ensure the rear side of die set
faces the main axle of the frame.
4. Install die set screws loosely and close the handles while
ensuring proper alignment of the die halves.
5. Tighten the die screws with supplied torx wrench.
TA04536 D Page 1 of 2
TM
ERG4 COMFORT CRIMP
Read and understand all of the instructions and safety
mechanism must be released, please see Figure 5.
®
INSTRUCTIONS FOR USE
16 25
Figure 2
®
WARNING
HANDLES ARE NON-INSULATING.
DO NOT CRIMP ON HOT ENERGIZED WIRES.
1.2
Ferrules 26-1/0 AWG (0.14-50 mm
1. Open handles fully.
2. Position ferrule into the
proper nest.
3. Close handles slightly to secure
ferrule. Do not deform ferrule.
4. Insert stripped wire
5.
Close handles until the SHURE STAKE
mechanism cycle has been completed.
®
MECHANISM
)
2
Figure 1
For Use With
®
Figure 3
)
2
