Summary of Contents for CNC Solutions DOOR MATE

  • Page 1 MANUAL...
  • Page 2 DOOR MATE cnc automatic door system Dear Customer, Thank you for purchasing your Door Mate CNC automatic door system from CNC Solutions llc. This manual contains all the important information regarding safety, installation, usage and care of the Door Mate.
  • Page 3 DOOR MATE INDEX cnc automatic door system OVERVIEW Safety f rst Warning Designed intent Limited Liability Overview Attaching to CNC Machine Preparation Mounting Installing the Door Mate Adjusting the Door Mate Door Mate Set up Programming Troubleshooting MAINTENANCE Maintenance overview...

  • Page 4: Safety First

    DOOR MATE cnc automatic door system OVERVIEW SAFETY FIRST Below are the safety symbols used in this manual: This symbol is shown to avoid a serious injury or serious damage to the CNC automatic door system and/or the cnc machine may occur if...

  • Page 5: Limited Liability

    The cnc automatic door system is an after-market product to an existing CNC machine. The automatic opening and closing of the CNC machine doorway will allow you to fill and remove parts from the CNC machine ergonomically and with Automation using Robots. Limited liability CNC Solutions llc accepts no liability for damage by: • Failure to comply with these operating instructions. • Unintended use.
  • Page 6 DOOR MATE cnc automatic door system Overview Complete Door Mate Assembly Exploded Door Mate Assembly View...
  • Page 7 DOOR MATE Attaching to CNC machine cnc automatic door system Preparation Inspect the Door mate upon delivery for any damages. Tools Needed: 6mm Allen Wrench 9mm Drill bit Pencil Parts included in Kit: Belt Electrical Enclosure Cable / Wire Check that there is sufficient stability around the CNC machine to enable a safe installation.
  • Page 8 Mounting on the CNC machine DOOR MATE cnc automatic door system The top covers need to be removed. There are (10) 8mm x 1.25 BHCS screws and washers. A 6mm Allen wrench is also needed to perform this task. FIG. 2.2-1...
  • Page 9 DOOR MATE Installing the Door Mate cnc automatic door system Remove machine backing plate with threaded holes from Door Mate brackets. Shown in FIG 2.2-3 Place unit on top of machine and mark hole pattern on the top of the door.
  • Page 10 DOOR MATE Installing the Door Mate cnc automatic door system Motor connection location Installing the Electrical Box Distance from the Electrical box must not exceed 5 Meters. Mount using hardware provided (attached to box) Place on top of machine or on the side of the machine within the correct distance for the legnth of the cable.
  • Page 11 FIG. 2-4-1 Remove machine backing plate with threaded holes from Door Mate door bracket. Align bracket to the edge of the door and transfer the holes. Drill out the marks on that door, attach threaded hole bracket from the bottom the door and tighten bolts.
  • Page 12 DOOR MATE Adjustment of the Door Mate cnc automatic door system Adjustability is built in with the slotted brackets shown here in FIG. 2.2-4 for varying door heights and parallelism need to run the belt straight. Adjust where needed to make belt run parallel.
  • Page 13 DOOR MATE Programming Door Mate cnc automatic door system Initial Setup - Starting a learn run when the line voltage is applied. Push the door into the CLOSED position. Disconnect the power supply from X3 (DC). Press and hold the learn run button (S401) Connect the power supply to X3 (DC).
  • Page 14 DOOR MATE Programming cnc automatic door system Initial Setup - Starting a learn run during operation Push the door into the CLOSED position. Press and hold the learn run button (S401). The learn run starts automatically, and the learn run button can be released.

  • Page 15: Troubleshooting

    DOOR MATE Troubleshooting cnc automatic door system...

  • Page 16: Maintenance

    DOOR MATE Maintenance cnc automatic door system Keep debris and dust clear of belts and motor drive. Do a routine checkup of all parts. FIG. 3-1-1 Make sure all bolts are tight and brackets are properly aligned FIG. 3-1-2...
