Summary of Contents for ShinewayTech OCI-20B
- Page 1 OCI-20B User’s Manual OCI-20B Optical Connector Inspector User’s Manual Shineway Technologies, Inc. All rights reserved. Shineway Technologies, Inc.
- Page 2 OCI-20B User’s Manual Thank you for purchasing ShinewayTech OCI-20B Optical Connector Inspector. Please read carefully this User’s Manual before operating, which can be of great help. This product is controlled by microprocessor; improper use may cause the monitor stop operating. Please read the manual carefully to enjoy the performance.
-
Page 3: Table Of Contents
OCI-20B User’s Manual Table of Contents OCI-20B-P Probe Overview ......................1 Components Introduction ......................1 Major Structure ........................1 Inspection Lens ........................2 Barrel Assembly ........................2 Inspection Tips ........................2 Key Features & Specification ......................3 Magnification ........................... 3 Resolution .......................... -
Page 4: Oci-20B-P Probe Overview
OCI-20B User’s Manual OCI-20B-P Probe Overview OCI-20B Optical Connector Inspector is used to inspect end-face of fibers and check the optic connectivity. It magnifies fibers of 125μm diameter 650 times, enlarging picture through a video signal to the display where the status of fiber end-face is showed clearly. -
Page 5: Inspection Lens
The inner structure of the Handle is compact and complex, long time working may cause handle body heating. This isn’t the mechanical faulty but normal phenomena. Unauthorized disassembling may cause damage to OCI-20B. Inspection Lens Optical magnification system is in the front of handle body, the beginning of which comes a lens-bar. -
Page 6: Key Features & Specification
OCI-20B User’s Manual Mind the tip before removal of the nut during disassemble. Key Features & Specification Magnification The optical and picture magnification can reach up to 12× and 650× respectively. Different size display has correspondingly different magnification; the table of... -
Page 7: Major Function
OCI-20B User’s Manual Major Function To inspect fiber ends of both simplex and ribbon types To inspect male fiber ends, which refer to the end of patch cords or pigtails. To inspect female fiber ends, which refer to the end of port through adapters or inside devices. -
Page 8: Bottom End Of Display
OCI-20B User’s Manual Bottom end of Display CH1 Image Input: Connector: press CH1/CH2 key to display CH1 image. Charger Connector. Earphone Connector: adjust volume via up/down keys. CH2 Image Input Connector: press CH1/CH2 key to display CH2 image. Video Output: connect to have voice output. -
Page 9: High Performance
OCI-20B User’s Manual High Performance 960 x 240 definition , 2.5inch LCD monitor Image recording, timing display Two channels for image signal input CH1/CH2, manually switching Sensitive microphone installed for sound recording Functions of key-locked ,stand-by and recording Storage (128MB internal memory, SD card optional provided ),16G support Mobile disk optional provided Can upload files of music and video or other kinds through USB 2.0... -
Page 10: Files Playback
OCI-20B User’s Manual Press [Record] to record the being image and timing, When working, voice is recorded at the same time, which can be used as indentifying different files. Press left/right keys to control the recording speed, Press up/down keys to control the volume. -
Page 11: Oci-20B Microscope Installation
Adjust the focus control to centralize the image on the display if necessary. Note: Probes can be mounted on the monitor slot right beside rubber boot (As shown in the right figure), convenient for single operation. Mount the OCI-20B-P Probe into OCI-20B-D Display through the monitor slot Shineway Technologies, Inc. -
Page 12: Warranty Information
Contact Customer Service Please check our web site (www.shinewaytech.com) for updates to this manual and additional application information. If you need technical or sales support, please contact local Shineway Technologies Customer Service. - Page 13 OCI-20B User’s Manual Shineway Technologies, Inc.
