Hot Attachment of Power Supplies:
1. Unpack the power supply carefully. Inspect for any damages. If any damage is
observed, do not use the power supply and call (949) 250-6510 to report the
damage immediately and request a replacement unit.
2. Attach the power supply to the chassis and reconnect the 48VDC power source
to the FlexPoint power supply.
3. Locate the 48VDC circuit breaker and switch the circuit breaker to the ON
position.
4. Turn the FlexPoint Chassis power supply ON.
5. Observe the LED in the front of the chassis indicating that the power has been
restored.
SPECIFICATION
Indicators:
Power ON:
LED (2), Yellow, power applied
Dimensions / Weight: W:19.0"xD:7.0"xH:3.5" / 9 lb.
Power:
48VDC / 3.0 Amps (for model 4386)
2ea. 48VDC / 3.0 Amps (for model 4385)
Environmental:
Temperature:
0 to 40 degrees C
Humidity:
0-90% (non-condensing)
©Copyright 1999-2001. Black Box Corporation. All rights reserved.
1000 Park Drive
Lawrence, PA 15055-1018
724-746-5500
Fax 724-746-0746
Omnitron Systems Technology, Inc.
TM
FlexPoint
48V Power Redundant
14 Module Chassis
User's Manual
CUSTOMER
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week; Call 724-746-5500 or fax 724-746-0746
SUPPORT
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
INFORMATION
Web site: www.blackbox.com
LMC200A-2PS-DC
LMC200A-DC
Powered Chassis
E-mail: info@blackbox.com
JULY 2001
PSFP20-DC
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Black Box FlexPoint LMC200A-2PS-DC
Summary of Contents for Black Box FlexPoint LMC200A-2PS-DC
- Page 1 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) FREE technical support 24 hours a day, 7 days a week; Call 724-746-5500 or fax 724-746-0746 SUPPORT Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 INFORMATION Web site: www.blackbox.com E-mail: info@blackbox.com...
- Page 2 TRADEMARKS All applied-for and registered trademarks are the property of their respective owners. FEDERAL COMMUNICATIONS COMMISSION CANADIAN DEPARTMENT OF COMMUNICATIONS RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication.
- Page 3 It is equipped with two power supplies in a power-redundant configuration. This User’s Manual describes the following models: Model Description LMC200A-2PS-DC Powered Chassis, rack-mountable chassis, 2 power supplies LMC200A-DC Powered Chassis, rack-mountable chassis, 1 power supply PSFP20-DC Power supply unit for models LMC200A-2PS-DC and LMC200A-DC...
- Page 4 Any evidence of damage should be noted and reported immediately. INVENTORY Review contents, the following items should be included: FlexPoint Powered Chassis unit. Power supplies (2 for model LMC200A-2PS-DC, 1 for model LMC200A-DC). (14) L shape tabs. (14) Screws User’s manual (this document).
