- Page 1 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY INSTRUCTIONS Top quality from Japan Metal shed Yokohama The assembly video can be found on: www.finnhaus.de 018150|14...
- Page 2 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE BASEMENT AND CROSS-BEAM The basement and the cross-beam must be layed together as in the plan. Required accessories Pce no. Article To guarantee the shed Base frame, in front stands correctly it requires a good found- Base frame, left ation.
- Page 3 ASSEMBLY INSTRUCTIONS YOKOHAMA FITTING OF THE BASE FRAME AND THE CROSS-BEAM Attention: Please insure that all the base frame parts are level, so that after completion the door opens and closes easily. Required accessories After the frame has been checked that it is level the two Pce no.
- Page 4 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE CORNER POST Required accessories ATTENTION: To maintain that everything is at a right angle Pce no. Article check the length of diagonals are exactly the Corner post, front left same. Corner post, front right Please check that all the edges of the frames Corner post, rear left are together.
- Page 5 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE REAR AND FRONT ROOF FRAME Required accessories After fitting the rear top framework please fit the smaler rubber grommets (these holes are for electric cable). Pce no. Article Roof frame, rear Roof frame, front Rubber plug, small Short screws Rubber plug,...
- Page 6 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE LEFT AND RIGHT DECORATIVE COVER Required accessories Pce no. Article Decorative cover, left Decorative cover, right Short screws Short screws Short screws...
- Page 7 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE CENTRAL WALL STRENGTHENERS FOR THE LEFT, RIGHT AND THE REAR Required accessories Please fit the wall strengthener provisionaly. Pce no. Article Central wall strengthener, left, right Central wall strengthener, rear Short screws Central Top side Central hole Top, shorter...
- Page 8 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE CENTRAL WALL STRENGTHENERS IN FRONT Required accessories Pce no. Article Central wall strengthener, front Long screws Short screws Upper Attachement Long Long screws screws Long screws Short screws Lower Attachement Short screws The base of the strengthener is pressed and secured into the third hole of the corner post.
- Page 9 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE GROUND PANEL Required accessories Pce no. Article Central Ground panel Ground panel left, right Special screw Special screw Ｂ Ａ The front of the ground panel to be mounted Please usw the special srews. over ledge of gutter.
- Page 10 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE ROOF PANELS Required accessories Pce no. Article Roof panel, big A bag with each roof Roof panel, small panel contains Rear seven snow plugs. Short screws Remove glue covering Snow plug (3 Bags) and fit as shown. No snow plugs are used on the small panels.
- Page 11 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE ROOF STABILISER Required accessories Pce no. Article Lift the roof stabilisator and secure with two long screws central holes. Roof stabiliser Long screws and nuts each with Strengthering of the roof panels long screw Fix both ends of the lower...
- Page 12 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE SIDE WALL PANELS BEFORE ASSEMBLING Required accessories Only the hooks within the red markings can be moved Pce no. Article when the shed is finished. Please decide – before the shed is build up – where the hooks should be. Side wall panel big 76 / 106 Attaching the hooks...
- Page 13 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE SIDE WALL PANELS SIDE WALL PANELS, REAR Please check the right angle of 90 ° between the base frame and the posts. BOLTING In corner posts secure with short srews, all the strengtheners with long nuts and bolts and strengthen, then fix strengtheners.
- Page 14 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE DOOR PANEL FOR OPENING AT THE RIGHT Required accessories Pce no. Article Door panel rear, fixed Hole caps Short screws Please fit the hole caps in the holes as shown and screw short screws in the shown order below: Short screws...
- Page 15 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE FRONT DECORATIVE COVER AND THE HEIGHT COMPENSATION COVER BAR Required accessories Pce no. Article Decorative cover, front Height compensation cover bar Hole caps Short screws Short screws Hole caps Hook the trim panel in the front roof frame. Rotate the trim panel as shown up over the roof and secure it with short screws.
- Page 16 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE GUTTER Required accessories Hook both ends of the Pce no. Article gutter on the trim panels. Gutter Rotate over the roof Short screws and secure it with short screws.. Short screws...
- Page 17 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY OF THE RAINWATER PIPE In one or the other rain holes which you Required accessories ever wish can be used to fit the down pipe. Drain Metal clamp for Article The other hole must be sealed with a rubber hole rainwater pipe plug.
- Page 18 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY RIGHT HAND DOOR Required accessories Before mounting door please fit Pce no. Article both metal stoppers top and bottom Door panel, rear, front as shown. Metal stopper Take precaution that the cylinder Short screws lock isn‘t scratched. Door stop cover Short screws...
- Page 19 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY LEFT HAND DOOR Required accessories Changes neccessary to chance from right Pce no. Article hand to left hand door. On both doors the ends must be changed over, i.E. running wheel Door paneel, rear, front unit to door space cover and vice versa. Door paneel, centre, rear Take precuation that the cylinder look doesn´t Metal stopper...
- Page 20 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY RIGHT HAND DOOR Required accessories Pce no. Article Door panel, rear, front Door panel, centre, rear Rubber plug Rubber plug Mount the rubber plug on the front, right and left corner post. Rubber plug Hole for rubber plug Press the rubber plug together...
-
Page 21: Adjusting The Door
ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLY LEFT HAND DOOR Required accessories Pce no. Article Door panel, rear, front Door panel, centre, rear Door stop cover Drip ledge The rear movable door must be fitted so that both runner wheels are either side of fixed door strengthener. - Page 22 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLING THE FRONT DECORATION COVER Required accessories Pce no. Article Anzahl Front decoration cover Metal holder for the upper front decoration cover Short screws Metal holder for the upper front decoration cover Short screws 1. Fit the front decoration cover 2.
- Page 23 ASSEMBLY INSTRUCTIONS YOKOHAMA ASSEMBLING THE RACKS Required accessories Building the racks Pce no. Article Rack frame for side panels Hook the rear rack frame in the last gap on wall panels. Then add the Rack frame for rear wall front rack frame to fit shelves. Cross rear strengthener For large wall panels Front cross strengthener...
-
Page 24: Fitting The Shelves
ASSEMBLY INSTRUCTIONS YOKOHAMA You need four metal shelves supports for one shelf. (Two on each side) FITTING THE SHELVES For example: With a gap of 5 cm you can create 21 ranks. Required accessories Pce no. Article Metal shelves supports You need four metal shelves Big shelf supports for one shelf. - Page 25 ASSEMBLY INSTRUCTIONS YOKOHAMA ANCHORING THE BUILDING Required accessories The shed must be ankered to protect against falling over. Pce no. Article ※ The accessoires marked „ “ may be used when the shed is more Anchor, big than 120 mm above ground. In this case the large anchors can be ※...
- Page 26 ASSEMBLY INSTRUCTIONS YOKOHAMA FITTING THE SCREW CAPS AND COVER Required accessories In cold weather the plastic cover can become hard. In Pce no. Article this case warm up for example in your trouser pocket to Screw head cover soften. Cover for rightangled holes Check that all screws are tight before you fit all 41 screw head covers and the...
-
Page 27: General Advise
ASSEMBLY INSTRUCTIONS YOKOHAMA TIPS FOR ASSEMBLING GENERAL ADVISE MOUNTING ADVISE FOR THE SUBSTRUCTURE / FLOOR PANELES 1. Ensure youself that the base frame is level 1. Ensure the ground is flat and firm where you and square (for example on a cemented want to build uo your metal shed. - Page 28 ASSEMBLY INSTRUCTIONS YOKOHAMA TIPS FOR ASSEMBLING Screwing: 6. If a door sticks adjust runner wheels to run free. Firstly screw the four corner posts with panels provionally and check that none are cross threaded. Then tighten. Please screw CAREFULLY to protect the screws threads from damage.
