Wall Mount Adaptor Installation Guide
Thank you for purchasing Pro-Face's Wall Mount Adaptor.
This adaptor can be attached to the following products:
PS-600G Series, PS-500P Series, GP-2500/2600 Series, FP-2500/2600 Series,
GLC2600 Series, and GP2000H Series units (hereafter referred to as the "Unit.")
Using this adaptor, you can attach any of the aforementioned Units to a wall.
• This product can be attached directly only to GP2000H Se-
ries units. To attach this product to any of the other Units
listed above, an optional "Rear Cover" is required. (CA1-
RCVLRG-01). Once this cover is attached to the rear of the
Unit, this product is then attached to that cover.
• This product is not CE marked or UL/c-UL(CSA) compliant.
Therefore, be aware that when it is used in combination with
a product that is CE marked and UL/c-UL(CSA) compliant,
that product will lose its conformance with these standards.
All Company/Manufacturer names used in this manual are the registered trade-
marks of those companies.
© Copyright 2001 Digital Electronics Corporation All rights reserved.
(CA1-WMALRG-01)
-1-
Advertisement
Table of Contents
Summary of Contents for Pro-face CA1-WMALRG-01
- Page 1 Wall Mount Adaptor Installation Guide (CA1-WMALRG-01) Thank you for purchasing Pro-Face's Wall Mount Adaptor. This adaptor can be attached to the following products: PS-600G Series, PS-500P Series, GP-2500/2600 Series, FP-2500/2600 Series, GLC2600 Series, and GP2000H Series units (hereafter referred to as the "Unit.") Using this adaptor, you can attach any of the aforementioned Units to a wall.
-
Page 2: Safety Precautions
Safety Precautions This Installation Guide includes important safety-related information that must be followed to ensure the correct and safe use of the Wall Mount Adaptor. Prior to attaching this product, be sure to read both this guide and any related manuals to thoroughly understand the correct operation and functions of both the Wall Mount Adaptor and the Unit. -
Page 3: Package Contents
Package Contents The Wall Mount Adaptor 's (Model No. CA1-WMALRG-01) package includes the following items. Prior to using the unit, be sure to check that all the items are included in the package. Unit Rear Face Plate : 1 Unit Rear Face Attachment Screws: 4... - Page 4 External Dimensions When using the Wall Mount Adaptor with PS-600G Series, PS-500P Series, GP- 2500/2600 Series, FP-2500/2600 Series, and GLC2600 Series units: With these Units the optional Rear Cover is required. (CA1-RCVLRG-01) The following drawings show the dimensions with the Wall Mount Adaptor attached to this cover.
- Page 5 When using the Wall Mount Adaptor with a GP2000H Series unit: The following drawings show the dimensions with the Wall Mount Adaptor attached to the Unit. The following Unit is a GP2301H. Unit: mm [in.] 90[3.54] 90[3.54] Wall Mount Adaptor dimensions W90[3.54] x H92[3.62] x D13[0.51] [2.56] 253[9.96]...
-
Page 6: Specifications
Specifications Structural External Dimensions W90[3.54] x H92[3.62] x D13[0.51] mm[in.] Weight Approx. 0.2[0.44] kg[lb.] Installation WARNING • Installing the Wall Mount Adaptor while power is supplied to the Unit may lead to an electric shock. Prior to installing theWall Mount Adaptor, confirm that the Unit's power supply is disconnected. - Page 7 Attach the Unit Rear Face Plate to the Unit's Rear Cover. (Fastening torque: 0.5 to 0.7 N•mm) With PS-600G Series, PS-500P Series, GP- 2500/2600 Series, FP-2500/2600 Series, With GP2000H Series units: and GLC2600 Series units: Rear Cover (sold separately) Unit Rear Face Plate Attach the Wall Mount Adaptor Plate to the wall.
- Page 8 Please be aware that Digital Electronics Corporation shall not be held liable by the user for any damages, losses, or third party claims arising from the uses of this product. Digital Electronics Corporation 8-2-52 Nanko Higashi, Suminoe-ku, Osaka 559-0031, Japan URL: http://www.pro-face.com/ © 2001 Digital Electronics Corporation. All rights reserved.
