17.000
FRONT
BEGINNING SHEET
Additional Notes:
2 sheets, 1 fold, side stitched
FRONT
11.000
FOLDED SHEET
DRAWING: In this area, draw the following:
beginning sheet, to scale
folded sheet, to scale
Enter the dimensions of the sheet with three decimal places.
Be sure to include FRONT labels, which indicate that the bar code
must remain visible when the final fold is completed.
Revision History
A
B
C
D
E
20156
Material
White Paper
Notes
1.
printed two sides
2.
printed black
3.
tolerance: ± .13
4.
see sheet 2 for artwork
5.
printed in country may vary
6.
drawings not to scale
Notes: Enter any notes here. These notes must include:
how many sides of the paper are printed
ink color (usually black, may also be one or two specific colors, such as a Pantone value, or
8.500
11.000
Revision Description:
F
F > Allegion Rebranding
062621
Edited By
Approved By
R. Byun
M. Roberts
Title
F-Series Hand Punch Modem Instruction
Creation Date
Number
70200-0013
08-29-11
Created By
Activity
J. Ellis
3899 Hancock Expwy
Software: Illustrator CS6
Security, CO
EC Number
Release Date
062621
05-14-2015
Revision
F
Allegion
80911
Copyright © 2015
Advertisement
Related Manuals for Schlage HandPunch F Series
Summary of Contents for Schlage HandPunch F Series
- Page 1 17.000 8.500 FRONT FRONT 11.000 11.000 BEGINNING SHEET FOLDED SHEET DRAWING: In this area, draw the following: beginning sheet, to scale folded sheet, to scale Enter the dimensions of the sheet with three decimal places. Be sure to include FRONT labels, which indicate that the bar code must remain visible when the final fold is completed.
-
Page 2: Installation Instructions
F Series HandPunch Modem Installation Instructions 70200-0013 Periodically, enhancements to the HandKey or HandPunch are introduced that offer added functionality and performance. Should it be necessary to incorporate the enhancements into the F Series circuit board (HP-2000, HP-3000, HP-4000, HK-2 and HK-CR), use the following procedures. CAUTION: This procedure requires erasing the existing hand templates. - Page 3 Set the reader on a firm surface such as a table. Remove the four screws that secure the back plate to the HandReader. Remove the grounding screw and/or ground lug (if present). See figure 2 below. CAUTION: Before removing back plate of reader, wear a grounding wrist strap to help aid in protecting the circuit board from any ESD damage that might occur from improper handling.
- Page 4 Locate the cable that runs from the top panel circuit board to the main circuit board. Disconnect this cable from J9 on the main circuit board. See “1” on figure 3. To remove the J9 connector on the main circuit board (lower board), depress the retaining clip on the connector and pull upwards.
- Page 5 Carefully slide the main circuit board out until the ribbon cable between the camera assembly and J2 on the main circuit board is accessible. First, disconnect the J5 connector from the main board. To remove, depress the retaining clip on the J5 connector and pull upwards.
-
Page 6: Side View
10. Install the modem PCB onto the main PCB. See figures 6 and 7 below. Align P1 on the modem PCB with J10 on the underside of the main PCB. Insert the P1 pins into the J10 socket. If done correctly, the two standoffs on the modem PCB should insert through the mounting holes in the main PCB. - Page 7 11. Carefully slide circuit board back into the chassis using the circuit board guides to locate the circuit board correctly. See figure 8 below. Circuit Board Guides Figure 8 12. Being careful to align all pins, attach the camera cable to J2 on the main circuit board. 13.
- Page 8 14. Locate the cable that runs from the top panel circuit board to the main circuit board. Connect this cable to J9 on the main circuit board. See figure 10 for cable routing. 15. If not already removed, remove the J7 jumper from the main PCB. See figure 9 below. Figure 9 CAUTION: If there is a ground strap on the main board, do not allow the ground strap to touch the J7 jumper.
-
Page 9: Customer Service
Battery Main Circuit Board Figure 10 16. Reinstall the back plate onto the chassis. Reinstall grounding screw and/or ground lug. If a ground lug is present, do not allow it to come into contact with J7. 17. Secure the back plate with the four screws removed in step 5. 18.
