Summary of Contents for KSI KSI-1700 SX HCFFFB-16
- Page 1 KSI-1700 SX HCFFFB-16 INSTRUCTIONS STAGING, ASSEMBLY, TESTING 7711 Oakport Street ksikeyboards.com Oakland, CA 94621 sanakey.com t (510) 562-5000 f (510) 562-0489 July 2019...
- Page 2 1/2” adhesive foam mounting tape, double-sided • Biometric fingerprint reader gaskets (included with TCS1 fingerprint readers) • Part number labels • Imprivata bubble label • KSI logo label • Long LED strip label • Rectangular window label, with cutout • Barcode label DOCUMENTS...
- Page 3 TOP HOUSING COMPONENT PREPARATION, ASSEMBLY and INSTALLATION PREPARE TOP HOUSING Remove and discard black tape from underside of top housing INSTALL TACT SWITCH With top housing face up, use triangular bit to unscrew clear plastic window Set screw aside Remove and discard clear plastic window Using triangular bit and the saved screw, screw tact switch into place Note: Over-screwing will cause tact switch window plastic to break...
- Page 4 INSTALL TCS1 FINGERPRINT READER Expose underside of top housing Use tweezers to carefully open “drawer” (CON 2) affixed to the fingerprint daughter board – opening one side first, then the other (only partway), until enough space is available to insert the TCS1 FPC (CON 3) into CON 2 fingerprint processor slot Use tweezers or a thumbnail to close the “drawer”...
- Page 5 INSTALL TCS1 FINGERPRINT READER – continued Still holding the reader in place, ensure no gaps exist between the reader and cutout and that no portion of the blue gasket is visible on the face of the top housing Still holding the reader in place, flip the top housing to expose underside Lay the top housing on work surface Carefully slide fingers away from holding the reader while aligning the four screw holes of the daughter board frame with the four screw holes embedded in the top housing...
- Page 6 PREPARE OEM-805N2AKU RFID READERS FOR INSTALLATION Unpackage each reader and discard all other components in the bag Lay out readers on work surface (Note: To prevent damage to processor boards, do not stack) Connect RFID cable to C1 Align protrusion on black plastic RFID clip with the center hole located on the RFID processor board Snap black plastic clip to the underside of the reader, ensuring four clip hooks are secured to reader processor board (without hooking or touching red antennae, or damaging any components on the processor board)
- Page 7 BUILD THE KEYBOARD PREPARE THE KEYBOARD BASE 1. Remove double-sided tape strip from base of keyboard and discard 2. Remove jumper (JP1) from processor board with hook pick and discard (Note: Ensure the jumper is discarded to prevent it from falling inside keyboard) INSTALL RFID READER INTO BASE 1.
- Page 8 On keyboard underside, use the triangular bit and screws to secure the base to the top (Note: Avoid over-screwing to prevent screw breakage) LABEL THE KEYBOARD On the underside of keyboard, apply part number label over “KSI-1700 B Black”...
- Page 9 Check for correct RFID configuration using RFIDeas pcProx config test Test for correct firmware using USB Firmware Downloader Program tact switch using KSI proprietary program; three keyboard LEDs should flash green Program TCS1 LED; TCS1 LED should flash blue Use 125 kHz and 13.56 Mhz cards to test RFID; ensure strong beep and green LED flash with each card Install window label;...
- Page 10 Apply long LED strip label where the top assembly meets the keyboard base; ensure label is straight and properly aligned with LED lights Center KSI logo label between “Enter” & “4” keys horizontally, “End” & “Page Up” arrow vertically Confirm keyboard footbar is operational...
- Page 11 TYPICAL ASSEMBLYLINE CONFIGURATION COMPONENT ASSEMBLER 1: Tact switch unboxing, unpackaging, staging Keyboard top housing unboxing, unpackaging, staging Tact switch installation into keyboard top housing Staging of top housings on mobile carts COMPONENT ASSEMBLER 2: TCS1 component unboxing, unpackaging, staging Installation of TCS1 assembly into keyboard top housing Staging of top housings on mobile carts COMPONENT ASSEMBLER 3: RFID card reader component unboxing, unpackaging, staging...
