SPEEDKEY SK-AC2000 User Manual

Electric

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

SPEEDKEY TECHNOLOGY CO.,LTD.

www.speed-key.com

·Please be careful to read the manual before using the product.

·Please preserve properly for future reference.

PRODUCT

Electric

Thermostat

ON/OFF

SK-AC2000

SPEEDKEY TECHNOLOGY CO.,LTD

USER MANUAL

Room

SPEED

Table of Contents

Need help?

Do you have a question about the SK-AC2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for SPEEDKEY SK-AC2000

Page 1 PRODUCT USER MANUAL Electric Room Thermostat ON/OFF SPEED SPEEDKEY TECHNOLOGY CO.,LTD. www.speed-key.com ·Please be careful to read the manual before using the product. ·Please preserve properly for future reference. SK-AC2000 SPEEDKEY TECHNOLOGY CO.,LTD...
Page 2: Table Of Contents
· PRODUCT SAFETY All SPEEDKEY products have been designed and produced in accordance with CE and RoHS CONTENT requirement, with various performance indexes complying with BS4662 requirements. Incorrect wiring may cause burning-out or malfunctions. Please refer to the wiring diagram for specific details.
Page 3: Package Components
SK-AC2000 SK-AC2000 Electric Room Thermostat Electric Room Thermostat PACKAGE COMPONENTS PACKAGE COMPONENTS Electric Room Thermostat(integral)SK-AC2000I Electric Room Thermostat(detachable)SK-AC2000SYS ON/OFF SPEED ON/OFF SPEED 开/关速度开/关速度 Controller panel Thickening bracket Controller driving box SK-AC2000I Controller panel Fixed bracket...
Page 4: Introduction
Electric Room Thermostat (integral SK-AC2000I) SR-Single valve circuit diagram (see figure） With SK-AC2000 Electric Room Thermostat , fan speed of central air conditioning fan coil and electric cool-hot valve switch can be adjusted to keep the room at a setting...
Page 5 SK-AC2000 SK-AC2000 Electric Room Thermostat Electric Room Thermostat PRODUCT WIRING PRODUCT WIRING Electric Room Thermostat (detachable SK-AC2000SYS)SR-Single valve circuit diagram Electric Room Thermostat (detachable SK-AC2000SYS) NSR-Single valve circuit diagram (see figure） (see figure） Fan coil Fan coil wiring terminal 6-bit control terminals...
Page 6 SK-AC2000 SK-AC2000 Electric Room Thermostat Electric Room Thermostat PRODUCT WIRING PRODUCT WIRING Electric Room Thermostat (detachable SK-AC2000SYS) SR-Double valve circuit diagram Electric Room Thermostat (detachable SK-AC2000SYS) NSR-double valve circuit diagram (see figure) (see figure） -closing valve control 6-bit control terminals...
Page 7: Product Installation
SK-AC2000 SK-AC2000 Electric Room Thermostat Electric Room Thermostat PRODUCT INSTALLATION(SK-AC2000I) PRODUCT INSTALLATION(SK-AC2000I) 3 Check Bs4662 switch base box whether there is enough space (50mm)to install touch 1 Turn off main power supply of the circuit screen switch .If the space is not enough, the thickening bracket shall be used.
Page 8 SK-AC2000 SK-AC2000 Electric Room Thermostat Electric Room Thermostat PRODUCT INSTALLATION(SK-AC2000I) PRODUCT INSTALLATION(SK-AC2000I) Connecting method of non-screw terminal 5 Mount the switch driving section into base box,and fix with 2 screws Please use single wire of diameter of 1.6 or 2.0 to comply with non-screw terminals suitable cable.
Page 9 SK-AC2000 SK-AC2000 Electric Room Thermostat Electric Room Thermostat PRODUCT INSTALLATION(SK-AC2000I) PRODUCT INSTALLATION(SK-AC2000SYS) Electric Room Thermostat Illustration for installation of (detachable) SK-AC2000SYS 7 Cover the touch screen panel SK-AC2000T wall air conditioning control panel bracket O N /O 开 / 关...
Page 10: Illustration Of Sk-Ac2000 Series
SK-AC2000 Electric Room Thermostat Electric Room Thermostat PRODUCT DESCRIPTION PRODUCT DESCRIPTION Illustration of SK-AC2000 series Introduction of SK-AC2000 display screen Operating status of indoor Heating mode fan can be indicated: Liquid crystal 3 levels as low, medium, high level Cooling mode...
Page 11: Parameter Setting
PRODUCT DESCRIPTION PARAMETER SETTING SK-AC2000 Remote explanation Time setting: the system must be set up with remote controller. Press SET button on the remote at first, and then press HOUR button and set up the hour,and then press MIN button and set up minute.
Page 12: Progamming Setting
SK-AC2000 SK-AC2000 Electric Room Thermostat Electric Room Thermostat PARAMETER SETTING PROGAMMING SETTING Lock setting Parameter setting Hotel power-up scene function: when the guest enters room and inserts the card for This system has special lock function to facilitate its management. It will lock the power, the air conditioning system will automatically system if necessary.
Page 13: Product Specifications
SK-AC2000 SK-AC2000 Electric Room Thermostat Electric Room Thermostat PRODUCT SPECIFICATIONS TROUBLE SHOOTING GUIDE Symptom Possible cause Solutions Make sure that input and output line SK-AC2000I SK-AC2000sys No backlight Parameter is tightly connected on the terminal 1 Incorrect wiring or poor contact .
