Summary of Contents for ITI 135310
- Page 1 OPERATION MANUAL 135310 ODEL NDER EMOTE IEWING INSTRUMENT TECHNOLOGY, INC. POB 381, Westfield, MA 01086 33 Airport Road, Westfield, MA 01085 Tel: (413) 562-3606 Fax: (413) 568-9809 Email:iti@scopes.com www.scopes.com...
-
Page 2: Warranty
There are no other express or implied warranties. ITI's sole obligation and purchaser's exclusive remedy for breach of any warranty shall be limited to repair or replacement of the product at the option of ITI. This warranty does not cover, and ITI will not be liable for any resulting direct, proximate, incidental or consequential damages. -
Page 3: Overview Of Applications
Extender supplied with the camera. Screw camera onto the “C” mount or “C” Mount Extender until it bottoms out. ITI recommends a 1/3” format CCD for use with this RVI. A 1/2” format CCD can also be used, although the monitor image will be quite small. - Page 4 ISUAL YEPIECE The Visual Eyepiece screws onto the “C” mount. The “C” Mount Extender should not be used when the Eyepiece is in place - you will not be able to obtain proper focus. OCUSING Start with the RVI out of focus. Rotate Focus Ring so that focus is achieved and continue past clear focus. Rotate Focus Ring in opposite direction to re-establish clear focus.
- Page 5 1. Screw ITI Model 135312 Visual Eyepiece onto the scope’s “C” mount. 2. Attach ITI Model 126070/41mm Visual Adapter to the back of the Eyepiece. 3. Remove lens from ITI Model 135630 NVPS. Screw NVPS onto the back of the Visual Adapter. Remove protective cap from NVPS and attach rubber eyeguard.
- Page 6 2. Unscrew the lens and the protective cap from ITI Model 135630 NVPS. Screw the NVPS onto the 2X Adapter. 3. From the NAV II & III Adapter Kit, screw on the NVPS relay lens to the ITI Model 135630 NVPS (lens will only adapt one way).
-
Page 7: Telescopic Arm
NFRARED MITTER LATE 12 Volt Battery Pack 1. Remove power cord from battery pack storage pouch. 2. Insert power cord plug into receptacle on Infrared Emitter Plate by rotating it until it locks into place. Charging the 12 Volt Battery Pack 1. -
Page 8: Troubleshooting
Room is extremely dark Use low light sensitivity Dirt on external Clean optics optical surfaces Dirt or liquid on internal Return to ITI for repair optical surfaces Image Not Clear Dirt on external optical Clean optics surfaces Scope not focused... -
Page 9: Instrument Care
To proceed with the repair, ITI will require a purchase order for the full quoted repair price. 2) Decline Repair - Upgrade to a New Instrument Choosing this option requires a purchase order for the new equipment at its quoted price. ITI will ship out the next available unit.
