Amphenol Procom PRO-ARU4G User Manual

19” rack-mountable active receiver multicoupler

Advertisement

Quick Links

User Manual
19" Rack-mountable
Active Receiver Multicoupler
type
PRO-ARU4G
PRO-ARU8G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO-ARU4G and is the answer not in the manual?

Questions and answers

Summary of Contents for Amphenol Procom PRO-ARU4G

  • Page 1 User Manual 19” Rack-mountable Active Receiver Multicoupler type PRO-ARU4G PRO-ARU8G...
  • Page 2 Title: User Manual for 19” Rack-mountable Active Receiver Multicoupler type PRO-ARU…G (…: 4 or 8) Document version: Reviewed: 1r0 Reviewed: 1r1 Document Change Record Issue Date Sheet (s) Description of change Alterations endorsed and 05-10-2016 First release 09-07-2018 New brand Procom Contacts: Adnan Ahmad Director of Engineering...
  • Page 3: Table Of Contents

    Power supply backup function ................... 6 Installation ......................... 6 Front view ........................6 Rear view ........................6 5.2.1 Rear view PRO-ARU4G ..................7 5.2.2 Rear view PRO-ARU8G ..................7 Connection of power supply voltage ................7 5.3.1 Mains connection ....................7 5.3.2...
  • Page 4: Preface

    1 Preface This user manual covers the Amphenol Procom Active Receiver Multicoupler models: PRO-ARU4G and PRO-ARU8G. In the subsequent chapters, for the sake of clarity: Where the descriptions are valid for both receiver multicoupler models, the figure in the model designation is replaced by “…”, as example: PRO-ARU…G.
  • Page 5: Introduction

    The amplifier system compensates for the n-way splitter loss + circuitry insertion loss. In both PRO-ARU4G and PRO-ARU8G, the ANT signal feeds an amplifier, which is provided with a 4-splitter- or 8-splitter circuitry at the output. The outputs from the splitter circuitry form the 4 or 8 identical RX outputs.
  • Page 6: Power Supply

    Front view The front plate is identical on both receiver multicoupler models. The height of both PRO-ARU4G and PRO-ARU8G are 1HU (44.45 mm). The front plate is provided with 2 pcs. 7 x 10 mm oval mounting holes in each side, intended for rack mounting of the multicoupler, using M6 screws.
  • Page 7: Rear View Pro-Aru4G

    5.2.1 Rear view PRO-ARU4G 12 VDC Mains Mains 24 VDC fuse power inlet fuse inlet – (Equipotential (Protective bonding) earth) 5.2.2 Rear view PRO-ARU8G 12 VDC Mains Mains 24 VDC fuse power inlet fuse inlet – (Equipotential (Protective bonding) earth) Connection of power supply voltage 5.3.1 Mains connection...
  • Page 8: Equipotential Bonding

    However, if any malfunction of the multicoupler occurs, please refer to chapter 7: “Trouble shooting” below. If the instructions in the Trouble shooting chapter is insufficient, please contact nearest Amphenol Procom dealer or Amphenol Procom for further information. Page 8 of 10...
  • Page 9: Trouble Shooting

    Supply voltage not Connect supply voltage. sensitivity connected or off. AC or DC fuse blown, Replace fuse(s). power on LED off Other fault symptoms Contact Amphenol Procom Spare parts Amphenol Article Value Procom Spare part no. Fuse for 230 VAC...
  • Page 10: Block Diagrams

    9 Block Diagrams Block diagram PRO-ARU4G Block diagram PRO-ARU8G Page 10 of 10...
