I N S T A L L A T I O N · O P E R A T I O N · M A I N T E N A N C E G U I D E
MICROWAVE OVEN
SC28LMO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC28LMO and is the answer not in the manual?

Questions and answers

Summary of Contents for Scandium SC28LMO

  • Page 1 I N S T A L L A T I O N · O P E R A T I O N · M A I N T E N A N C E G U I D E MICROWAVE OVEN SC28LMO...

  • Page 2: Table Of Contents

    Index Welcome ............................3 Your Safety — General Warnings .....................4 Before Installation ...............................4 Grounding Installation ............................6 Electric Shock Hazard ............................6 Cleaning ................................7 Utensils ................................7 Materials You Can Use in Microwave Oven ......................8 Materials Not To Be Used in A Microwave Oven .....................9 Setting Up Your Oven ........................10 Parts and Accessories ............................10 Control Knobs ..............................11...

  • Page 3: Welcome

    1. Welcome Welcome Thank you for purchasing this Scandium appliance. To achieve the optimal performance from your appliance, and to avoid the risk of accident or damage, it is essential to read this manual before installation and first time use.

  • Page 4: Your Safety - General Warnings

    2. Your Safety — General Warnings WARNING: It is important that this instruction book be retained with the appliance for future reference. Should the appliance be sold or transferred, always ensure that the book is left with the appliance in order that the new owner can get to know the functions of the appliance and the relevant warnings.
  • Page 5 2. Your Safety — General Warnings 10. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to reduce any flames. 11. Do not overcook food. 12. Do not use the oven cavity for storage purposes. 13.

  • Page 6: Grounding Installation

    2. Your Safety — General Warnings 30. During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. 31. WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements.

  • Page 7: Cleaning

    2. Your Safety — General Warnings Cleaning Be sure to unplug the appliance from the power supply before any cleaning. Clean the cavity of the oven after use with a slightly damp cloth. Clean the accessories in the usual way in soapy water. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty.

  • Page 8: Materials You Can Use In Microwave Oven

    2. Your Safety — General Warnings Materials You Can Use in Microwave Oven UTENSILS REMARKS Aluminium foil Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry to prevent overcooking. Arcing can occur if foil is too close to oven walls.

  • Page 9: Materials Not To Be Used In A Microwave Oven

    2. Your Safety — General Warnings Materials Not To Be Used in A Microwave Oven UTENSILS REMARKS Aluminium tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish. Metal or metal-trimmed utensils Metal shields the food from microwave energy.

  • Page 10: Setting Up Your Oven

    3. Setting Up Your Oven Parts and Accessories Remove the oven and all materials from the carton and oven cavity. Your oven comes supplied with the following accessories: 1 x Glass tray 1 x Turntable ring assembly 1 x Instruction Manual Page 10...

  • Page 11: Control Knobs

    3. Setting Up Your Oven Control Knobs Menu Use control knob to: • Adjust the clock +/- • Menu selection Clock • Weight selection +/- Weight Display Defrost by time Grill Defrost by weight Microwave Reheat Clock Weight in grams Kitchen timer Child lock indicator Auto menu...

  • Page 12: Turntable Installation

    3. Setting Up Your Oven Turntable Installation Never place the glass tray upside down. The glass tray should never be restricted. Both the glass tray and turntable ring assembly must always be used during cooking. All food and containers of food must always be placed on the glass tray for cooking.

  • Page 13: Installation

    4. Installation Installation and Connection • This appliance is only intended for domestic use. The warranty is void if used in any commercial application. • This microwave is intended for built-in use only. It is not intended for counter-top use or for use inside a cupboard.
  • Page 14 4. Installation Venting cut-out Model Type SC28LMO The height of cabinet Required niche size for flush installation (H x W x D) 450 x 560 x 500 Dimensions of the product (H x W x D) 460 x 595 x 413...
  • Page 15 4. Installation CENTER LINE FRONT EDGE Page 15...

  • Page 16: Prepare The Cabinet

    4. Installation B. Prepare the Cabinet 1. Read the instruction on the BOTTOM CABINET TEMPLATE , put the template on the bottom plane of cabinet. CENTER LINE FRONT EDGE 2. Make the marks on the bottom plane of cabinet according to marks “a” of the template Screw A Bracket Centre line...

  • Page 17: Installing The Oven

    4. Installation C. Installing the Oven 4. Install the oven into the cabinet - Make sure the back of the oven is locked by the bracket. - Do not trap or kink the power cord. bracket bracket 5. Open the door, fix the oven to the cabinet with Screw B, at the installation hole. Then fix the Trim-kit plastic cover to the installation hole.

  • Page 18: Operation

    5. Operation Using Your Combi Microwave 1. Setting the clock When the microwave oven is switched on, the LED will display “0:00”, the buzzer will ring once. 1) Press “Kitchen Timer/Clock” twice to select clock function, the hour figures will flash. 2) Turn “...
  • Page 19 5. Operation “Micro/Grill/Combi.” Pad Instructions Microwave Power Grill Power Order Display P100 100% 100% 3. Grill or Combi Cooking Press “Micro./Grill/Combi” the LED will display”P100”,and press “Micro./Grill/Combi” a few times or turn the “ ” to choose the power you want, and “P100”, “P80” “P50”, ”P30”, “P10”, “G”, “C-1” or “C-2” will display for each added press.
  • Page 20 5. Operation 4. Quick Start 1) In standby mode, press “Start/+30Sec./Confirm” to start cooking with 100% power, each added press will increase 30 seconds cooking time up to 95 minutes. 2) In microwave, grill cooking or time defrost state, each press of “Start/+30Sec./Confirm” can increase 30 seconds of cooking time.
  • Page 21 5. Operation 8. Auto Menu 1) Turn “ ” right to choose the menu, and “A-1” to “A-8” will display, which means pizza, meat, vegetable, pasta, potato,fish, beverage and popcorn. 2) Press “Start/+30Sec./Confirm” to confirm. 3) Turn “ ” to choose the default weight as show on the menu chart below. 4) Press “Start/+30Sec./Confirm”...
  • Page 22 5. Operation 1 cup (120 ml) 2 cups (240 ml) Beverage 3 cups (360ml) 50 g Popcorn 100 g 9. Multi-stage cooking 2 stages can be set for cooking. In multi-stage cooking, if one section is defrosting, then defrosting shall be placed in the first section.

  • Page 23: Troubleshooting

    6. Troubleshooting NORMAL OPERATION Radio and TV reception may be interfered when the microwave Microwave oven interfering TV oven is operating. It is similar to the interference of small electrical reception appliances, like a mixer, vacuum cleaner and electric fan. It is normal. In low power microwave cooking, the oven light may become dim.
  • Page 24 It is not the responsibility of Scandium to rectify any incorrect installations. A service call out fee will be charged for any Scandium technician that attends a call, whereby it is established that the fault is due to an incorrect installation or non-manufacturing fault. Should the appliance be installed in such a way that the service agent is unable to gain access to the appliance, the person/s who own the premises or the property where the appliance resides —...

  • Page 25: Specifications

    7. Specifications Model: SC28LMO Rated Voltage: 220-240V ~ 50 Hz Rated Input Power(Microwave): 1450W Rated Output Power(Microwave): 900W Rated Input Power(Grill): 1100W Oven Capacity: Turntable Diameter: Ø 315 mm External Dimensions: 595 x 413 x 460mm Net Weight: 21Kg Page 25...
  • Page 26 7. Specifications General information Cavity (Litre/Cu.ft) Cavity Dimension(WxDxH)mm 328 x 368 x 226 Cavity Interior Stainless Steel Microwave Distribution Turntable Turntable size Turntable material Glass Interior Light Microwave Iutput(W) 1450 Microwave Output(W) Grill Output Power(W) 1100 Convection Input Power(W) General features Auto Menu Clock Kitchen Timer...

  • Page 27: Disclaimer

    All information supplied is to be used for general reference purposes only and is on the understanding that Scandium will not be liable for any loss, liability or damage of whatever kind arising as a result of any reliance upon such information. All pictures used in the guide are for illustrative purposes only.
  • Page 28 Australia 8/3-4 Anzed Court, Mulgrave 3170 Victoria. Phone 1300 881 693 Email info@scandiumappliances.com.au Web www.scandiumappliances.com.au New Zealand 5 Tolich Place, Henderson, Auckland 0610. Phone 0800 200 510 Email info.parex@emerson.com Web www.parex.co.nz Distributed by Axis Group International Pty Ltd. ACN 124 141 322 V1090817...
