  • Page 1: Table Of Contents

    Connecting the transmitter Connecting the transmitter to a computer Connecting the receiver Setting channels Energy-saving function Troubleshooting Cleaning Disposal Technical Data Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 2: Welcome

    3 Year Warranty. Please fill in and return the Warranty Card to the address provided. We hope you will enjoy your purchase for many years to come. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 3: Safety Instructions

    The rubber feet on the appliances may leave marks on furniture surfaces. Place the devices on a suitable underlay if necessary. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 4 The low transmitting power of the appliances eliminates any danger to health according to the current state of research and technology. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 5: Package Contents

    • 1x DIN SCART cable for the A/V input "SOURCE 1" • 1x DIN SCART cable for the A/V output "TV" Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 6 • 1x audio adapter 3.5mm stereo jack to cinch socket • 2x DIN AV cinch cable Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 7: About This Appliance

    / video source and the receiver is connected to the appliance that is to receive the signal. Refer to “Connecting the transmitter” on page 14 and “Connecting the receiver” on page 22. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 8 The three infrared transmitters in the infrared extender then send these signals to the relevant appliances. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 9 Examples of use Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 10 The range may be lower depending on the environmental conditions. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 11: Controls

    Controls Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 12 EXTEND: Audio/video DIN output for TV 15. 1 2: Switch source ½ 7.2V : Connection for mains adapter 7.2V 200 mA Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 13: Connecting The Transmitter

    1. Connect the DIN plug on the transmitter to the A/V OUT socket. 2. Connect the SCART plug to the SCART connection on the TV. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 14 Connect the appliance plug to the 7.2V socket on the transmitter and connect the mains adapter to a 230 V ~ 50 Hz power outlet. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 15 1. Use the channel switch at the bottom of the appliance to select a channel (A/B/C/D) to which the signal will be sent. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 16 With one appliance The following diagram shows a typical arrangement with a satellite receiver and a TV on the transmitter side: Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 17 The following diagram shows a typical arrangement with a satellite receiver, a TV and a DVD player on the transmitter side: Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 18: Connecting The Transmitter To A Computer

    4. Connect the red and white plugs on the AV cinch cable to your PC’s audio output. PCs usually have 3.5mm stereo jacks, so you can use the adapter supplied. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 19 8. Right-click once on the Desktop and choose "Properties" to view the "Display Properties": 9. Now click on "Settings" to configure your PC’s output. Various graphics cards can differ enormously here. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 20 To avoid loss of data you should back up all data to external media (such as CD-R) each time you change your PC system. MEDION AG accepts no liability for loss of data. Functionality: The enormous differences between operating systems and graphics cards mean that we cannot guarantee the functionality described in this section ("Connecting the transmitter to a computer").

  • Page 21: Connecting The Receiver

    2. On your TV, choose channel 36 to display the signal, or tune the stations in on your TV. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 22 2. You can also press down any button on the remote control belonging to an appliance that is connected to the transmitter for 10 seconds, and it will switch appliances. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 23 DIN AV cinch cable and SCART adapter or with a 75 Ohm aerial cable on the receiver side. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 24 Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 25: Setting Channels

    Note that the radio signals that are created during operation may affect other radio systems such as a WLAN system. In this case, switch to a different signal transmitting channel. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 26: Energy-Saving Function

    If the energy-saving function was switched off on the transmitter, the receiver will remain in the energy-saving mode. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 27: Troubleshooting

    The infrared transmitter’s diodes should be approx. 1 cm away from the infrared receiver of the audio/video source. • Have you aligned your infrared diodes correctly? Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 28: Cleaning

    This may be a local collection point for old appliances. Seek the advice of your local authority about the local options for disposing of waste. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...

  • Page 29: Technical Data

    100 m in rooms: Up to 30 m Connections: 1 DIN output 1 aerial output 75 Ohm Subject to technical modifications. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
  • Page 30 The appliances comply with the European directives for radio equipment and telecommunications equipment. (R&TTE 1999/5/EC). The certificate of conformity is posted on the Internet at: http://www.medion.com/conformity. Helpline No. UK/ North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508 Web Support www.medion.co.uk Model Number: 81883...
