Summary of Contents for Blu LW6030A
- Page 1 Wall-Mount Toilet Installation Guide FLOOR LW6020A LW6030A 2017-12 1 866 907 0122 blubathworks.com...
-
Page 2: Installation Requirements
- Adhere to all local building and plumbing codes. The diagrams in this guide are not construction plans. They are visual aids. 1. Inspect this product to ensure you have all parts as shown that are required for proper installation. Blu recommends that the installer refer to the Geberit toilet system installation and maintenance instructions. -
Page 3: Installation Notes
If further assistance is required, please contact: Product Support at 1.866.907.0122 (09:00 – 17:00hrs PST) or email technical@blubathworks.com North America Blu Bathworks Inc. 188 Smithe Street,Vancouver, BC, Canada, V6B 6A9 T +1.604.299.0122 F +1.604.299.0125 Please refer to blubathworks.com for warranty, terms & conditions under warranty & procedure for warranty service. - Page 4 Installation Instructions for Wall-mount Toilet LW6020A · LW6030A Decide the Size of Drainage Pipe Inst Insert discharge pipe into the pipe hub in the wall. Place a Place discharge pipe with gasket into waste outlet of bowl. a). Use he straight edge flush against the wall and mark a line on the Also place flush pipe with fin gasket into inlet of bowl.
- Page 5 Install the connecting bolt of bowl. a). Use hexagonal key to screw the b). Insert the auxiliary part into the aiming c). the auxiliary part is totally inserted into owl. Then conical nut into mounting fittings. screw by pushing the part tothe top from the aiming screw.
- Page 6 2017-12 1 866 907 0122 blubathworks.com...
- Page 7 continued... 2017-12 1 866 907 0122 blubathworks.com...
-
Page 8: Hinge Adjustment
Toilet Seat Installation Instructions LSeat-004 · LSeat-slim Hinge Adjustment Maximum adjustment of the pin position is achieved by rotating the hinge anchor around the screw (adjustment A in the parts diagram above.) Further fine adjustment of the pin position can be achieved by sliding the screw in the adjustment plate (adjustment B). -
Page 9: Fitting The Seat
Fixing the Hinge Anchor Place the Top Fix Inserts into the fixing holes in the • toilet pan. Insert the screws within the Hinge Anchors as shown and begin to tighten the screws until they are loosely secured to allow for adjustment of the seat on the pan. - Page 10 Toilet Seat Maintenance Wipe the toilet seat with a soft wet cloth • Clean the toilet seat with a neutral cleanser, and then dry it with a clean cloth • Caution Do not stand on the lid or ring of your toilet seat •...
- Page 11 LW6020A 2¼" [60] 13½" [342] 14¼" [360] 7" [180] 11" [280] 19" [485] 21½" [545] 9¾" [250] 13" [330] 18½" [470] 14¼" [360] 7" 1½" [180] Ø2¼" [35] [55] Ø1" 5½" 4¼" [25] [140] [105] 6½" [165] Ø4" [100] 2017-12 1 866 907 0122 blubathworks.com...
- Page 12 LW6030A 18½" [470] 14¼" [360] 7" [180] 11" [280] 2¾" 13½" [70] [345] 21¼" [540] 10¼" [260] 12½" [320] 17¼" [440] 14¼" [360] 7" [180] 1½" Ø2¼" Ø1" [40] [55] [25] 1½" [35] 5¼" 4" [135] [100] 7¼" [185] Ø4"...
