Poly-Control

Danalock V3

SKU: POLELOCKV3

Quickstart

This is a secure Door Lock for Europe. To run this device please insert fresh 4 * CR123A batteries. Please make sure the internal battery is fully

charged. To add this device to your network execute the following action:

Push the switch once.

Create PDF in your applications with the Pdfcrowd

HTML to PDF API

PDFCROWD

Table of Contents

Need help?

Do you have a question about the Danalock V3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Poly-Control Danalock V3

Page 1 Poly-Control Danalock V3 SKU: POLELOCKV3 Quickstart This is a secure Door Lock for Europe. To run this device please insert fresh 4 * CR123A batteries. Please make sure the internal battery is fully charged. To add this device to your network execute the following action: Push the switch once.
Page 2: What Is Z-Wave
What is Z-Wave? Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section. (For more information about frequency regulations please refer to the frequency coverage overview at Sigma Designs Website Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is not in direct wireless range of the transmitter.
Page 3 Let the door lock automatically when you leave your home. The auto-lock-function locks the door automatically after a predefined time. Properties: Z-Wave Plus & Bluetooth Version EU frequency: 868,42 MHz (Z-Wave) Package content: 1x Danalock V3 incl. Batteries (without lock cylinder) Power supply: 4x CR123 Battery lifetime: 6-12 month torque: 1,5 Nm Prepare for Installation / Reset Please read the user manual before installing the product.
Page 4: Installation
The Danalock can be set to factory settings by pushing the switch ten times. Safety Warning for Batteries The product contains batteries. Please remove the batteries when the device is not used. Do not mix batteries of different charging level or different brands.
Page 5 2. Pull out the old cylinder Insert your key and turn it so the cam lines up with the body of the cylinder. Now pull out the cylinder. 3. Adjust the new cylinder Measure the back part (on the outside of your door) of the old cylinder from the middle of the screwhole and away (see illustration). In the Danalock box you’ll nd an adjustable lock cylinder.
Page 6 4. Unscrew the small screws on both sides of the cylinder and pull it apart. 5. Insert the same size of spacer piece and brass tube to make the adjustable cylinder match the old cylinder. Please look at the following size guide to find the right length for the spacer piece and the brass tube.
Page 7 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
Page 8 Size guide - When you adjust the size of the Danalock cylinder to the old cylinder you‘ll have to exchange the brass tube in the center with another that fits the spacer piece. Here are the different combinations. 6. Assemble the cylinder and screw the small screws back in on both sides of the cylinder. Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
Page 9 7. Insert the adjustable cylinder Insert the new cylinder, and re-insert the lock-screw in the mortise-plate to fix the cylinder. (b) Do not tighten the screw to hard - make sure the cylinder is working by locking and unlocking with your hand. 8.
Page 10 IMPORTANT! Avoid pulling the cylinder out of place. It is important that the spacer flushes or sticks out from the hole in the rosette plate. 9. Break the screws to the right length Depending on which spacer or spacer combination you chose, it is now important that the screws that fasten the cylinder to the back plate have the right length.
Page 11 10. Fasten the back plate to the cylinder Now fasten the back plate to the cylinder with the rosette spacer in between them. Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
Page 12 IMPORTANT! Check that the lock atill works! Make sure that the lock still works properly by tuning the tailpiece. If you cant lock and unlock this way please loosenthe cylinder screws. 11. Give the tailpiece the right length To avoid damaging the Danalock you will have to shorten the new cylindertailpiece to max 35mm from the door surface. Use two plierts or a wire cutter to shorten the tailpiece.
Page 13 12. Attach the tailpiece adaptor Insert the gteen taipliece adaptor in the center tube on the backside of the Danalock. Press on the adaptor until a click ensures it is fixed firmly to the Danalock. 13. Fit the tailpiece to the middle of the housing base Fit the Danalock over the back plate.
Page 14 14. Align the plate marks Find the small marking on the edge of the back plate and align the mark on the back of the Danalock baseplate with it. Now you are sure to hit the notches on the back plate with the Danalock. 15.
Page 15 16. Activate batteries Pull out the plasitc teb to activate the batteries. Alight will flash to confirm the Danalock is ready. Dismount instruction If at any time you need to dismount the Danalock from your door, insert a pen tip into the hole at the top inner edge of the lock and press while turning the lock counter-clockwise until the lock releases.
Page 16 Inclusion/Exclusion On factory default the device does not belong to any Z-Wave network. The device needs to be added to an existing wireless network to communicate with the devices of this network. This process is called Inclusion. Devices can also be removed from a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network.
Page 17: Product Usage
Exclusion Push the switch once. Product Usage LED signals LEDs are installed at the edge of the Danalock, which are protected by LEDs. Different colors indicate certain operations. Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
Page 18 1x green Activating the pairing mode Puts the Danalock V3 into pairing mode in order to connect it via other radio standards. to control it, press button once and wait 5 seconds until the lock turns green flashes. Now you have 30 seconds to connect the V3 with a gateway.
Page 19: Quick Troubleshooting
Turn the V3 by hand until the lock is unlocked (if necessary incl. door latch) and press the button twice. Wait 5 seconds until the V3 flashes yellow, then move in the other direction until the lock is locked and press 1x. 3x white Automatic adjustment Turn the V3 by hand until the lock is unlocked and leave the lock locked.
Page 20: Configuration Parameters
low battery. Door Lock operation report: triggered upon a change in door lock Notification: triggered upon a change in door lock Configuration Parameters Z-Wave products are supposed to work out of the box after inclusion, however certain configuration can adapt the function better to user needs or unlock further enhanced features.
Page 21: Technical Data
Enable Parameter 4: BLE Temporary Allowed The BLE is enabled for a number of seconds. Size: 4 Byte, Default Value: 0 Setting Description Disable 1 - 2147483647 Enable no. of seconds Parameter 5: BLE Always Allowed Size: 1 Byte, Default Value: 0 Setting Description BLE Always disabled...
Page 22: Supported Command Classes
Hardware Platform ZM5202 5712560000462 IP Class IP 20 Battery Type 4 * CR123A Device Type Door Lock Keypad Network Operation Listening Sleeping Slave Z-Wave Version 6.71.01 Certification ID ZC10-17095764 Z-Wave Product Id 0x010E.0x0009.0x0001 Firmware Updatable Updatable by Consumer by RF Supported Notification Types Access Control Supported Command Classes...
Page 23: Explanation Of Z-Wave Specific Terms
Notification V8 Powerlevel Security Security 2 Supervision Transport Service V2 Version V2 Zwaveplus Info V2 Explanation of Z-Wave specific terms Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways,Remote Controls or battery operated wall controllers.
