Instructions for use of DLE Jetboard
Congratulations on your purchase of DLE Jetboard ! DLE Jetboard was designed as an extreme sport device made of carbon fiber and a 2-stroke engine . Before you start, take
some time to get familiar with your DLE Jetboard and how it works. For your safety, we urge you to take full responsibility for keeping the Jetboard well maintained. Prior to use
the engine, please read the following instructions carefully, the instruction will provide you with basic information on correct Jetboard operation. It's important to perform pre-ride
checks and post-ride maintenance as detailed in this manual.
If any passages of the manual are not completely understood or in case of questions or service , please call our after-sale service centre (400-100-6090）,or visit our website
www.dlengine.com for latest news , we will serve you faithfully

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jetboard and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DLE Jetboard

Summary of Contents for DLE Jetboard

  • Page 1 Congratulations on your purchase of DLE Jetboard ! DLE Jetboard was designed as an extreme sport device made of carbon fiber and a 2-stroke engine . Before you start, take some time to get familiar with your DLE Jetboard and how it works. For your safety, we urge you to take full responsibility for keeping the Jetboard well maintained. Prior to use the engine, please read the following instructions carefully, the instruction will provide you with basic information on correct Jetboard operation.

  • Page 2: Table Of Contents

    Table of Contents 1.Instructions ……………………………………………..……………………………………………......1 2.Safety information …………………………………………....................….2 3.Technical data …………………………..................………………...…3 4.Components ……………………………………....................……...….4 Engine notice ……………………………………………......................…...…... Starter…………………………………………............................…... Crankcase …………………………………………........................……….…... Cylinder ………………………………………………........................…..Exhaust ………………………………………………........................…..Propulsion device…………………………………………........................……... Hull …………………………………………………………........................……..… Inner hull ………………………………………………............................ Bracket………………………………………………............................Control handle …………………………………….…........................………. Controls system…………………………………………….........................….. Charger ………………………………………..…….......................... Fuel tank ………………………………….……….…........................…..
  • Page 3 How to clean carburetor ………………………………………….......................…..… 7.The removal procedure for engine ……………………..................…………29 8. Warning ………………………………..................…………30 9. Warranty information ………………………………..................…………30...

  • Page 4: Instructions

    Jetboard. As a Jetboard owner, you have joined a large community of riders who want to ensure that there are always good places to ride， and only ride in areas where it’s legal to ride Jetboard and approved by the local authorities.
  • Page 5 6）Keep Your Jetboard in Safe Condition It’s important to keep you Jetboard properly maintained and in safe riding condition. To help avoid problems, inspect your Jetboard before every ride and perform all recommended maintenance. Never exceed load limits, and do not remove any original equipment or modify your Jetboard in any way that would change its design or operation.

  • Page 6: Technical Data

    3、Technical data L*W*H : 1800*600*150 Weight: 19.5KG Engine type : Two stroke water-cooled engine Displacement: 106CC Power: 8KW/7500rpm Recommended operational RPM 6700～7800rpm Max. Speed 55km/h Compression ratio: 13:1 Diameter * Stroke 52*50 Engine Starter: Electronic starter Fuel : Unleaded petrol at least. No.92 Fuel mix ratio 50:1 Fuel tank capacity...
  • Page 7 4. Safety instructions & exploded assembly drawing Safety instructions 1.The user must be at least 16 years of age. 2.Using clean gasoline fuel, and the lubricating oil mixture that you should use is 30 to 1.Do not use the lubricating oil mixed with other different make, type, or model lubricating oil , or will cause serious carburetor blocking.

  • Page 8: Starter

    Starter...

  • Page 9: Crankcase

    Crankcase...

  • Page 10: Cylinder

    Cylinder...

  • Page 11: Exhaust

    Exhaust pipe...

  • Page 12: Propulsion Device

    Propulsion device...
  • Page 13 About Propulsion device Check that there are no obstacles or debris obstructing the jet intake grate, propeller, and driveshaft. Remove any debris you might find. If while riding, the Jetboard does not run with sufficient power or strong vibration, stop the engine immediately and check the pump for obstructions or debris and remove anything you might find there before restarting the engine.

  • Page 14: Hull

    Hull...

  • Page 15: Inner Hull

    Inner hull...

  • Page 16: Bracket

    Bracket...

  • Page 17: Control Handle

    2. Check to see if thumb throttle returns automatically to the rest/idle position. 3.If throttle can't return automatically to the engine idle position when released, then don't ride the Jetboard, and check the throttle cable and angle of handle immediately starter key(启动钥匙)；...

  • Page 18: Controls System

    1. Inspect the control system connection before use , and ensure the connection is correct . 2. The control system must not be immersed in water for a long time. 3. No unauthorized control system is allowed to disassemble. Controller specification Name DLE Jetboard E Model ECU-2017 Size 86mm*60mm*60mm Battery capacity: 12.5V 5200mAh...

  • Page 19: Charger

    Connect Name Color/category Remark components Black & red, two cores The blue and black is negative, Water pump connector Water pump （fine） green and brown is positive Black & red,, two cores The brown one is positive, Ignitron connector Ignitron 13 （...
  • Page 20 Charger Charge procedure: 1. After connect the charger to the power supply, insert the power cable into 3S connector. 2. Through LED light to judge whether it is in standby/charging/full charged/default mode. There are four LED lights which separately indicate the battery power is 25%、50%、75%、100%.When it is in standby model, 25%/75% and 50%/100% will flash alternately.

  • Page 21: Fuel Tank

    Fuel tank  Fuel mixture Please use unleaded gasoline 92 # or above, do not use ethanol petrol We recommend that you use FD grade 2-stroke fully synthetic oil (MOTUL 710), cause low-quality fuel may lead to the engine performance degradation, or even make the engine damage.

  • Page 22: Basic Procedures For Operation

    5.Basic procedure for operation Developing your riding skills is an on-going process. Even if you have ridden other watercraft, take time to become familiar with how the Jetboard operates and handles. For your safety, practice riding the Jetboard in calm water close to shore. Do not ride farther out until you get accustomed to the Jetboard .
  • Page 23 Installation of tail fin and side fins 1.For the tail fin and side fins , you should put on the tail fin first, and make sure that the cooling hose and propulsion installation is correct.(Note: Riding without fitted cooling hoses will cause overheating that could damage or destroy the engine);the next thing you need to do is put on the 2 side fins.
  • Page 24 closed open Close the carburetor choke,open the full throttle, and insert the start key ,after 5 seconds the engine will start automatically(Usually you should repeat this process 1-2 times then can make the fuel from tank pump to the engine). You should pull out the key after hear the explosive sound .Then open the choke ,letting go of the throttle, and insert the start key after 5 seconds the engine will in idle status .
  • Page 25 If the engine still refuses to start, refer to the section “If Your Engine Quits or Won’t Start” which on page 26. 5. If not use the Jetboard when you have a rest on the shore, you should put the start key in electric breaking switch hole.When the Jetboard not use for more than 10 minutes, you must start...
  • Page 26 6.The throttle lever controls the speed of Jetboard. The throttle lever will automatically return to the idle status when the lever is released. 7.The start key should be worn around the rider’s wrist where rider holds control handle. The advantage of this is that if the rider falls off the Jetboard or away from the control handle, the engine will shut off immediately when the start key is pulled from the engine kill switch.
  • Page 27 WRNING : Renew lubricating oil once per 10 minutes operation. 1. Remove the screw for oil reservoir. 2. Use a syringe to inject lubricating oil to the oil reservoir, and the oil reservoir capacity is 10 ml. 3. Install the lock screw，and check if any leakage. 4.

  • Page 28: Common Faults And Trouble Shooting

    When you get accustomed to control your Jetboard's direction and throttle ,you should adjust the gravity center according to boat's gesture while you are ridding. When the nose of the Jetboard rises up ,it means that your gravity center too near the rear board, you should lean into the nose of the Jetboard. On the contrary, if your gravity center too near the front board, the connection area between the board bottom and water will increase , which may led to more resistance during ridding and make the ridding speed can't reach its optimal state.
  • Page 29 Checklist How to fix If the fuel, battery is sufficient Supplement fuel , replace battery or charge battery in time . Check to see if the power connection is correct. Replace the incorrect connector Verity wet of spark plug Replace new spark plug or make it dry engine Inspect ignition for flame out Inspect at least the above three rules...

  • Page 30: How To Correct The Problem" Water In The Engine

    noise Inspect exhaust for loosen Maintenance How to correct the problem" Water in the engine " Open the drain valve ,see fig1. Remove the spark plug, and shake out as much water as you can and make it dry, then install the spark plug to spark plug cap. Note: Connect the spark plug to engine,and avoid to damage the control system We should tilt the board at a forty-five degree angle and restart 2-3 times to make sure that the extra water out of the engine.

  • Page 31: Adjustment For Carburetor Needle

    Adjustment for carburetor needle Factory setting: Rotate the needle counter-clockwise 1 lap when in low speed(L) , rotate the needle counter-clockwise 1.25 laps when in high speed(H). . “L”needle used for oil supply when in low speed ,“H” needle used for oil supply when in high speed .The needle is very precision, if you apply a lot of pressure may lead to the carburetor damage. Do not adjust the needle without authorization, the factory settings of our carburetor can start engine normally and can satisfy the operation conditions in most areas.

  • Page 32: How To Clean Carburetor

    How to clean the carburetor: Remove 4 adjusting screws from carburetor first, and then open the seal cover. Remove the parts in sequence as showing, it is recommend to put the removed parts in a storage box. Use professional carburetor cleaner to clean the fuel filter, and make sure without of fuel strainer loss, or the carburetor will be blocked. Clean the carburetor with the corresponding alignment hole, and then install it follow the removing sequence.

  • Page 33: The Removal Procedure For Engine

    7.Removal procedure for engine 1. Loosen the lock screw; 2. Loosen the coupling screw, then pull backward and make it separate; 3. Remove 4 mounting screws; 4. Remove the water tube, fuel tube and power line. Note: Gluing all the mounting screws with Loctite 242, it is necessary to make it be diagonal crossover and tighten uniformly in the same plane. For the engine main body sealing surface which adopts a no-gasket design, you need to clean the appearance when install it, and paint anaerobic planar sealants.

  • Page 34: Warning

    Although the boat has been totally waterproofed , it is not sealed . It is the owner’s responsibility to immediately remove all excess water from the engine compartment. Failure to remove any accumulation of water in the engine compartment can cause damage to the engine and also damage electrical components. When the engine is not running, the Jetboard should lie on the water itself, without any object or person laying on it.
  • Page 35 4.The damage caused by using inferior petrol, will avoid any warranty. 5.DLE will refuse any liability if the operator does not follow the prescribed procedures and cause board damage , or suctions the foreign matter result in faults. 6.Keep the warranty card and instruction well ,in case of rework a warranty card must be shipped with product together to us , so that we can make maintenance records.
  • Page 36 Contact us : Mile Haoxiang Technology Co,Ltd. Tel： 400-100-6090 / 86-15126388003 Sale：13529826090 Fax：086－0873－6131518 Website：www.dlengine.net E-mail：dle@dlengine.com Address: Miyang Industry Zone, Mile Industry Area, Mile City, Honghe Prefecture, Yunnan Province, P R China.
