Summary of Contents for mydome UK113
- Page 1 Light switch timer 3 step Installation overview 3 minute quick programming guide A police accredited product info@mydome.co.uk|0203 637 0856...
- Page 2 Important information Thank you for Purchasing the Light Switch Timer – Please read the instructions to learn how to install and use your new timer. Whilst you will not be accessing or touching any wiring it is advisable as a precaution to turn off the mains electricity during installation of the cradle.
- Page 3 Contents Installation Setting the time Programming the unit FAQ – Trouble shooting Timer features...
-
Page 4: Step 1 - Installing The Cradle
STEP 1 – Installing the cradle Turn off the power to the lights at the mains 1 - Using a screw driver, loosen both screws on the switch plate - Eight to Ten turns of the screw is usually enough to install the cradle. The screw does not need to be fully removed. -
Page 5: Step 4 - Programming The Unit
Press day/ hour / min buttons until correct day & time is displayed. Press enter (temperature gauge will reappear) PS – Be sure to pay attention to the AM /PM indicator. Step 4 – Programming the unit Press prog button ... -
Page 6: Step 5 - Installing The Unit
lights on every day at the same time. *the user can repeat for as many programs as they need. There are 9 possible on/off programmes Once set the timer will continue to operate and repeat the program each week Step 5 – Installing the unit Slot the unit into the cradle Press the On and Off buttons to test on /off operation Aligning the control wheels... -
Page 7: Faq And Troubleshooting
AM/PM indicator Day and time Auto / manual indicator Room temperature Low Battery Indicator Programme number ‘ON’ time FAQ & troubleshooting Why does the light switch timer not turn lights on and off? (‘n’ shaped inserts required) The gap between the switch and the control wheels is too large. - Page 8 Remove the cradle by loosening the screws on the switch by a few turns • Insert the “n” shaped insert into the recess of the cradle as shown. • Re install the cradle. • Re-tighten the screws and insert the unit Note the Inserts sit between the wall and the switch plate –...
- Page 9 plate may have been installed upside down. You will need to rotate your switch 180 degrees. Upon doing so your light switch timer will function as intended. How do I reset the timer? To reset the timer and erase all pre-set programmes, use a pointed object, such as a straightened paper clip, to gently press the rest button.
- Page 10 Will the light switch timer work on a 2 way circuit switch plate? When using the timer on a 2 way circuit it is important to note the on /off position of the switch will change and as a result the unit may not operate as expected.
- Page 11 Using your timer Using the On/OFF buttons Normal operation of your lights outside of programmed times using the “on” and “off” buttons does not impact your pre- programmed timetable. Stop the programs from running Holding the hour button for 7 seconds will cause a bar/line to appear on top of the word ‘Auto’...
- Page 12 Programming Examples: The following demonstrate how to set your timer to operate multiple programmes at a variety of times on various days. ON 1 MON TUE WED THU FRI SAT SUN 6:15 AM OFF 1 MON TUE WED THU FRI SAT SUN 8:30 AM ON 2 MON TUE WED THU...
- Page 13 Clear Programming: To clear a previous programme Press PROG, you will see the PROG 1 ON day and time on the screen Press ENTER to advance to the desired programme number that you want to remove Press DAY continually until programme is clear, showing -:- - . Review Programming To review your programmed times Press PROG.
- Page 14 random and different each day of the week. • Press PROG, press ENTER repeatedly to cycle through the programmes till you get to PROG 0 • Press ON button to activate the random programme or press OFF button to turn off the programme. •...
- Page 15 Guarantee Your Switched On Products Light Switch Timer (model UK113) is guaranteed for one year from the date of purchase. Please retain your receipt as proof of purchase as this will be required to process any replacements / returns. This guarantee does not apply to defects resulting from action...
- Page 17 N shaped insert instructions Only to be used to reduce the gap between switch plate and light switch timer – details in the guide booklet (FAQ – pg. 8) Remove the cradle by loosening the screws on the switch by a few turns •...
