SPECIFICATION OF PV CHARGE CONTROLLER
PV CHARGE CONTROLLER
XANTRA ADVANCED 360V -
380V/100A PWM SOLAR
CHARGE CONTROLLER
Installation and operating instructions
Users:
Thank you very much for selecting our PV CHARGE CONTROLLER!
This manual contains important information and suggestion about
installation, operation and trouble shooting. Please read them carefully
before you use it
Phone Numbers: +2348120855444, +2348123655444
Version: 5.0 (2016.12)
PSC Solar UK
www.pscsolaruk.com
info@pscsolaruk.com
Advertisement
Table of Contents
Summary of Contents for PSC Solar YQPV-HP360V/100A
- Page 1 PV CHARGE CONTROLLER XANTRA ADVANCED 360V - 380V/100A PWM SOLAR CHARGE CONTROLLER Installation and operating instructions Version: 5.0 (2016.12) PSC Solar UK www.pscsolaruk.com info@pscsolaruk.com Phone Numbers: +2348120855444, +2348123655444 Users: Thank you very much for selecting our PV CHARGE CONTROLLER! This manual contains important information and suggestion about installation, operation and trouble shooting.
-
Page 2: Table Of Contents
SPECIFICATION OF PV CHARGE CONTROLLER Content 1. SAFETY INSTRUCTIONS ............2 1.1 S ....2 AFETY INSTRUCTIONS ARE IDENTIFIED AS FOLLOWS 1.2 S ............2 AFETY RECAUTIONS 1.3 A ............. 3 FTER SALE SERVICE .............. 3 XCLUSION OF IABILITY 2. PRODUCT INFORMATION .............3 2.1 T .............. -
Page 3: Safety Instructions
SPECIFICATION OF PV CHARGE CONTROLLER 1. Safety Instructions 1.1 Safety instructions are identified as follows WARNING: This symbol indicates potentially dangerous condition. Users should pay extreme caution when performing this task. CAUTION: This symbol indicates critical procedure for safe and proper operation of the controller NOTE: This symbol indicates the procedure or function that is important for safe and proper operation of the controller. -
Page 4: After-Sale Service
SPECIFICATION OF PV CHARGE CONTROLLER work performed on the system. 1.3 After-sale service The controller has two years of warranty since the manufacture date. Please operate the controller following the manual strictly. If there are some problems happen, please contact us directly for professional suggestions, if the problems still can’t be solved, then send it back to us with freight prepaid, and provide related information about the controller, such as invoice, S/N... -
Page 5: Topology Diagram
SPECIFICATION OF PV CHARGE CONTROLLER automatically operation. With the features of PWM (Pulse Width Modulation) battery charging and unique control technology, the PV charge controller improves battery life efficiently. The PV charge controller is only suitable for controlling solar modules. Never connect any other types of charging source to the controller. -
Page 6: Installation Instruction
SPECIFICATION OF PV CHARGE CONTROLLER performance 2.2.5 It adopts imported IGBT power module or MOSFET as electronic switch which can improve the stable performance of controller. 2.2.6 3’’ LCD displays the system status and working parameters 2.2.7 Parameters setting flexibly by touching keys 2.2.8 Users can parallel connect lots of t controllers in a system 2.2.9 Fully enclosed duct design and high-speed fan for cooling makes the controller working under harsh environments... -
Page 7: Wiring Instruction
SPECIFICATION OF PV CHARGE CONTROLLER you wire the system. Caution: When you install the controller, please ensure there is enough air through the heat sink of controller, we suggest 200mm space at each left and right. Caution: Please ensure all battery and PV arrays are turn off when you install controller in the system. -
Page 8: Mounting
SPECIFICATION OF PV CHARGE CONTROLLER But we also offer another two types of wiring as following: Solar Panel 1 Solar Panel 2 Battery Type 2: 2 groups of PV input and 1 group of battery output Solar Panel Battery Load Type 3: 1 group of PV input, 1 group of battery output, 1 group of DC output 3.3 Mounting... -
Page 9: Wiring The Controller To The System
SPECIFICATION OF PV CHARGE CONTROLLER 3.3.3 Mark holes Mark the four mounting hole locations on the mounting surface. 3.3.4 Drill holes Remove the controller and drill 4mm holes in the marked locations. 3.3.5 Fix controller Place the controller and align the mounting holes with the drilled holes in step 3.3.3. - Page 10 SPECIFICATION OF PV CHARGE CONTROLLER that the breaker is off. Warning: Risk of electric shock! The solar module’s high voltage output can cause severe shock or injury. Be careful operation when installing solar wiring. 3.4.5 Connect loads to the controller (if controller has this function) NOTE: Right connect the positive and negative 3.4.6 Confirm the wiring...
-
Page 11: Operation
SPECIFICATION OF PV CHARGE CONTROLLER 4. Operation 4.1 Instruction of HMI interface Menu/cursor right Value increase/cursor up Error indicator Enter/cursor left Charging indicator Value decrease/cursor down 4.2 Operating interface NOTE: It will enter to monitoring interface automatically if there is no operation within 3 minutes. The controller will enter to initial interface after you power the controller (step 3.4.7) as follow: The initial interface will last 3 seconds, then enter to monitoring... - Page 12 SPECIFICATION OF PV CHARGE CONTROLLER Eq-Chrg: Equalize charging FL-Chrg: Float charging Note: Error instruction OV-Volt: Over voltage OV-Curr: Over current UV-Volt: Under voltage OV-Temp: Over temperature NC-IGBT: module error (if it comes up with this error, please shut down the battery and PV arrays in time and contact us immediately.
- Page 13 SPECIFICATION OF PV CHARGE CONTROLLER 4.2.2 Monitoring At main menu interface, press + or - key, the inverse cursor moves between main menu 1 and main menu 2, when the inverse cursor points at 1. Monitoring, then press “Enter” to enter to monitoring interface as following: This interface shows the charging information 4.2.3 Device Set...
- Page 14 SPECIFICATION OF PV CHARGE CONTROLLER interface. If you choose “Save”, the interface will enter to the following interface and return to main menu 1 interface after 5 seconds. The settings will be saved. If you choose “Cancel”, it also returns to monitoring interface without saving the settings.
- Page 15 SPECIFICATION OF PV CHARGE CONTROLLER Note: Instruction of each parameter OV.Disc: Over voltage disconnect OV_Rect: Over voltage reconnect EQ_Chrg: Equalize voltage FL_Chrg: Float voltage EQ_Rect: Equalize recovery voltage UV-Rect: Low voltage reconnect UV_Disc: Low voltage disconnect EQ_Time: Equalize time Note: the adjustable arrange of Equalize time is 10~180 minutes Note: The working parameters will affect the battery life directly, the default parameters are the best, so if...
- Page 16 SPECIFICATION OF PV CHARGE CONTROLLER BV: Rated voltage of battery system PV: Rated charging current It’s a factory default model for reference, users can’t modify them. 4.2.6 Password Set At main menu 2, let the inverse cursor point at 5. Password, press “Enter” key and enter to password setting interface as follow: Modify the password through pressing + or - key, after you done the setting, press “Enter”...
- Page 17 SPECIFICATION OF PV CHARGE CONTROLLER Note: There is no step of putting password for this step, so care about it! 4.2.8 Factory Reset At main menu 2, let the inverse cursor point at 7. Factory Reset, press “Enter” and enter to password interface as follow: If you put a wrong password, the interface will show the following information and return to main menu 1...
-
Page 18: Instruction Of Pwm Technology
SPECIFICATION OF PV CHARGE CONTROLLER Note: the buzzer will alarm simultaneously if there is any error, if you both about it, you can cancel the alarm function by yourself, the setting step please refer to 4.2.3 5. Instruction of PWM technology 5.1 What is PWM charging model Pulse Width Modulation (PWM) is the most effective means to achieve constant voltage battery charging by switching the solar... -
Page 19: Troubleshooting & Maintenance
SPECIFICATION OF PV CHARGE CONTROLLER other equipment in the system, while maintaining full battery storage capacity. Load(s) can continue draw power from battery in float charging stage, even that the system load(s) exceed charging current, the controller will no longer be able to maintain the battery at the Float charging stage, it will return to Bulk charging stage once battery bank system voltage below than equalize charging point. -
Page 20: Model Instruction
YQ PV - HP ***/*** Yo Power PV System High Power System Rated System Voltage Rated Charging Current 8. Technical Specification Model YQPV-HP360V/100A Electrical Parameter Rated system voltage 360V Max. input voltage 720V Rated charging current 100A No. of input... -
Page 21: Dimension
SPECIFICATION OF PV CHARGE CONTROLLER Environment Parameter 3’’ LCD (White backlight) Display Display language English Indicator light Error indicator/Charging indicator Terminal type TC Series barrier terminal Humidity 0~98%, non-condensing Environment temperature -25°C +55°C ≤4000M, should reduce power if the Elevation elevation high than 4000M Protection level IP32... - Page 22 SPECIFICATION OF PV CHARGE CONTROLLER Indicator Fault Possible reason Troubleshooting There are other equipment Battery over Turn off the PV module(s) and check OV-Volt charging battery and make the charge the real battery voltage system voltage unstable Battery over The consumption power is high Shut down loads or check if the under UV-Volt discharge...
