  • Page 1 FORZA BOLT OUTBOARD MOTOR OWNER’S MANUAL...

  • Page 3: Table Of Contents

    Table Of Contents Introduction………………………………………………………..1 Safety Information………………………………………………….1 3.Refuelling Information…………………………………………..1 4.Safety Matters………………………………………………………2 5.Preparation………………………………………………………….3 6.Operation…………………………………………………………….3 7.Maintenance………………………………………………………...4 8.Storage ……………………..……………………………………….5 9.Common Faults and Troubleshooting Method………...………...5 10.Outboard Motor Dimension and Weight………………………...6 11.Operating Instructions...........……………...7 12.Model Specifications……..…………………………………..13...

  • Page 4: Introduction

    If you have any questions about the operation or maintenance of outboard motor, please contact Forza Power Equipment or your nearest Forza Authorized Dealer. Please read and understand Owners Manual completely before you using it. 2. Safety Information 1.

  • Page 5: Safety Matters

    17. Please use clean gasoline to prevent carburetor blockage or hard starting. 18. Please check the oil pipe for damage and leaks and replace, if needed. 19. Please use only FORZA spare parts, or else the outboard motor may get damaged.

  • Page 6: Preparation

    5. Preparation 1. Lubrication Information Use high quality clean lubricants, we do not recommended any special additive lubricants. Please Add 320ml of oil for new machines, then check the oil level gauge scale to ensure the correct amount of oil. Figure (1) 2.

  • Page 7: Maintenance

    2.2 After starting the outboard motor, adjust idle speed after warming up motor for 3 to 5 mins. 3.Stop machine Adjust the engine idle speed and let run another 30 seconds before stopping. Do not close choke lever to stop engine or it may cause engine damage.

  • Page 8: Storage

    8. Storage and Transportation Empty gasoline to avoid fuel line and carburetor blockage if motor will not be used for a period exceeding 30 days or for seasonal storage. 2. If putting in long-term storage, please empty gasoline from fuel tank, then run the machine, until the engine stopped due to lack of gasoline.

  • Page 9: Outboard Motor Dimension And Weight

    10.Outboard motor Dimension and Weight Figure 2 Outboard motor Gross weight:12kgs...

  • Page 10: Operating Instructions

    11. Structural Characteristics and Working Principle Figure 3 1. Fuel tank 2. Oil level gauge 3. Throttle grip,Steering handle 4. Tilted support positioning pin 5. Clamp screw 6. Clamp bracket 7. Starter 8. Muffler cover 9. Handle 10. Tilt lever 11.
  • Page 11 Figure 4 1.Choke valve switch 2.Air filter 3. Starter handle Figure 5 Outboard motor includes a handle, so you can safely and conveniently pick up and carry the motor.
  • Page 12 Figure 6 Figure 7 1.Stop Button 2.Throttle Cable Assy. 3.Anode 4. Propeller Locating Pin Figure 8 Figure 9 The Trim angle of the outboard motor helps determine the position of the bow of the boat in the water. Correct trim angle will help improve performance and fuel economy while reducing strain on the engine.
  • Page 13 Figure 10 Cruising in Shallow water 1. When boat cruising in shallow water, you must operate outboard motor in low speed, it may be necessary for you to adjust or lift the motor. When the water is shallow, you may have to turn off the engine or lift and pass, or you may damage the outboard motor.
  • Page 14 Figure 11...
  • Page 15 Figure 12...

  • Page 16: Model Specifications

    When cruising normally, outboard motor should be same as figure 11 When operating in Reverse boat, Outboard motor status same as figure 12 When operating in reverse, use a slow speed, otherwise the boat will be unstable. Outboard motor bracket can rotate 360 °.Simply rotate 180 °, move steering handle toward the rear, and the boat can go backwards.
