Page 1: Table Of Contents
28. Compliance standards 29. Technical support and troubleshooting 1. WELCOME Thank you for choosing this quality Ektor product. This manual is intended to help you install this product in a way that ensures the safety of yourself and others. Whilst this Ektor product is designed...
Page 2: Overview
MERCURY III JUMBO INSTALLATION INSTRUCTIONS 2. OVERVIEW Ektor Generation III platform introduces you to a new era of emergency lighting control. With years in the making, the third generation platform builds on the Ektor product ranges’ increasing quality, reliability and performance.
Page 3: Installation
4. INSTALLATION Ektor Mercury III Jumbo can be installed via surface, rod, or chain mounting. To install the Mercury III Jumbo please follow the steps listed below: Remove the product from the box and inspect it for any damage. If you believe the product to be damaged or otherwise unsound, DO NOT install the product.
Page 4: Mounting Options
MERCURY III JUMBO INSTALLATION INSTRUCTIONS Terminal block Battery Inverter NOTE: Ensure the fitting is mounted with the terminal facing outwards as shown in figure 3. Figure 3: Mercury III Jumbo cover removal Removing the decal and diffuser allows access to the Mercury III Jumbo battery and inverter for wiring, servicing and maintenance purposes.
Page 5 ROD MOUNT Refer to 01990 EV-RODMOUNT Installation guide included in rod mount kit. M5 cap screw/ locknut detail 25 tube Rod mount NOTE: DO NOT over-tighten screws when mounting the rod mount to the Mercury III Jumbo. The rod mount is suitable with tubes ranging from 0-2 metres in length.
Page 6: Terminal Block Wiring
7. MAINTAINING YOUR MERCURY III JUMBO WARNING The Ektor Mercury III Jumbo is connected to an unswitched active during normal operating conditions. When disconnected from the mains supply, the Mercury III Jumbo is powered by a LiFePO4 battery operated inverter. Due to this, care should be taken when replacing the battery.
Page 7: Replacing The Battery
AS/NZS 2293 or an equivalent standard can have a positive effect on the battery performance as long as exceed 12 discharge cycles per year is not exceeded 10. POWER AND BATTERY CHARGE The Ektor Generation III platform uses smart battery charging technology which reduces power consumption and increases battery life. Max charge voltage...
Page 8: Wireless Daughterboard
MERCURY III JUMBO INSTALLATION INSTRUCTIONS During the first stage of operation the battery charger charges the battery until full. Afterwards, the unit goes into a stage which charges the battery periodically. This reduces the battery temperature and reduces the loss of electrolytes which ultimately increases the service life of the battery. As a result of stopping the charging process, the power consumption is reduced and only consumes 1/11th of the typical power.
Page 9: Dali Wiring / Central Battery System
13. DALI WIRING / CENTRAL BATTERY SYSTEM The Mercury III Jumbo inverter supports DALI out of the box, a hardwiring diagram is shown below, optionally an installer can order a soft wiring cable set. The inverter also supports central battery systems and can be monitored through DALI.
Page 10: Accessories List
Below are the listings of the accessories and replacements compatible with the Mercury III Jumbo. PART EVOLT CODE CODE COMPLETE UNITS Mercury III Jumbo 40M EV-MERCURY-III-40M 03140 PARTS/REPLACEMENTS Mercury III Jumbo 40M Inverter EV-MERCURY-III-40M-INV 01221 1500mAH 64V 2 cell LiFePO4 Battery EV-1500MAH-6.4V-LIFEP04...
Page 11: Self Test Indicator Leds
19. SELF TEST INDICATOR LEDS The table below shows the operation of the Mercury III Jumbo status indicators: INDICATOR DESCRIPTION YELLOW Device is performing a duration test 2sec ON / 2sec OFF YELLOW Last duration test passed. The duration was met when 4sec ON / 1sec OFF last run.Test ran less than five days ago YELLOW...
Page 12: Product Specifications
MERCURY III JUMBO INSTALLATION INSTRUCTIONS 21. PRODUCT SPECIFICATIONS MERCURY III JUMBO 40M 290mm 540mm 70mm Voltage (V) Viewing Distance 220~240V Surface, rod, jack chain Frequency (Hz) Mounting Type Hardwired (1-16mm □) Ambient Temp. 0 - 40°C Wiring 6.4V Battery Type LiFePO4 Battery Voltage 16 hours...
Page 13: Construction Sites
If you choose to expose the Ektor emergency products to such harsh operating conditions, Evolt may not honour any warranty on the life of the batteries or the dish. This Ektor emergency product is designed to undergo regular discharge tests but it is recommended that the intervals between consecutive tests are not less than two weeks.
Page 14: Warranty Information
Australian Competition and Consumer Act and other Australian laws. Ektor products are warranted in Australia for a period of 12 months from the date of delivery of the product, provided that the products are properly stored, installed, used and maintained in accordance with the instructions contained within their manual.
Page 15: Compliance Standards
28. COMPLIANCE STANDARDS STANDARD TITLE Australian/ New Zealand AS/NZS 2293-3:2005+A1:2010 Emergency escape lighting and exit signs for buildings. Part 3: Emergency escape luminaires and exit signs. Standards AS/NZS 60598-2-22:2005 Luminaires Part 2.22: Particular requirements - Luminaires for emergency lighting (IEC 60598-2-22, Ed. 3.1(2002) MOD). AS 61000.3.2:2007 + A1:2009 Electromagnetic compatibility (EMC) - Limits - Limits for harmonic current emissions (equipment input current...
Page 16 Ph: + 612 9502 1161 Fax: + 612 9502 1154 Email: sales@evolt.com.au evolt.com.au Reference: 609031 V1.6...
