REO REOTRON SMP CP Series Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REOTRON
SMP CP
SMP CP/M
DC-Power supply
SMP CP-M_ANL_EN_rev04
05.01.2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REOTRON SMP CP Series and is the answer not in the manual?

Questions and answers

Summary of Contents for REO REOTRON SMP CP Series

  • Page 1 REOTRON SMP CP SMP CP/M DC-Power supply SMP CP-M_ANL_EN_rev04 05.01.2017...

  • Page 2: Technical Information For The User

    Declaration of conformity We declare that these products conform with the following standards and directives: RoHS COMPLAINT Directives: Standards: - 2014/30/EU - EN 61000-6-4:2007 +A1:2011; EN 61000-6-2:2005 - 2014/35/EU - EN 50178:1997 - 2011/65/EU RoHs REO AG, D - 42657 Solingen...

  • Page 3: Table Of Contents

    REOTRON SMP CP - CP/M Instruction manual Contents Technical Information for the User ....................... 2 1.0 General ..............................4 2.0 Functions ..............................5 3.0 Technical Data ............................6 4.0 User controls ............................7 4.1 Controls ............................... 7 4.2 Adjustment: ............................7 4.3 Adjustment procedure .........................

  • Page 4: General

    REOTRON SMP CP - CP/M Instruction manual 1.0 General Switch mode power supply for cathodic corrosion protection applications The REOTRON SMP range of DC Power units are primary-switched power supplies with galvanic isolat- ed output voltage. The units can be used voltage controller or current controller, or as a combined unit to control both voltage and current.

  • Page 5: Functions

    REOTRON SMP CP - CP/M Instruction manual 2.0 Functions Inputs: Terminals Set-point 1 Voltage set-point: 11(-), 13(+), 14(+10Vref.) or power set-point: 11(-), 12 (+) with 4...20 mA 0...10 V, DC, 0(4)...20 mA or Potentiometer 10 k Set-point 2 Current set-point: 15(-), 17(+), 0...10 V, DC, 0(4)...20 mA or Potentiometer 10 k 18(+10Vref.)

  • Page 6: Technical Data

    REOTRON SMP CP - CP/M Instruction manual 3.0 Technical Data REOTRON SMP REOTRON SMP CP REOTRON SMP CP CP & CP/M 24-5 & CP/M 48-10 & CP/M 48-20 Input voltage 110VAC/230VAC, 110VAC/230VAC, 110VAC, 230VAC +/- 10% +/- 10% +/- 10% +/- 10% Input frequency range 50 / 60 Hz...

  • Page 7: User Controls

    REOTRON SMP CP - CP/M Instruction manual 4.0 User controls 4.1 Controls The six buttons and a LED display found in the front- panel are used for operating and setting up the unit. All operating methods and adjustable parameters can DISPLAY be set up through this panel.

  • Page 8: Display Messages

    REOTRON SMP CP - CP/M Instruction manual 4.4 Display messages During normal running mode ‘run’ is shown in the LED display. In the programming mode an abbreviation for the corresponding parameter (see setting up instructions) and its set value, are displayed. Setting changes are stored upon leaving the programming mode or if a key is not touched for a period of 100 seconds.

  • Page 9: Possible Settings

    REOTRON SMP CP - CP/M Instruction manual 4.5 Possible settings Default Parameter Code Menu settings: (factory) Code:  0 / I E.S.O. Disable external set-point  0 / I 4.20 4...20 mA  0 / I E.F.P. Power regulation  0...100 % Minimum voltage ...

  • Page 10: Set Up

    REOTRON SMP CP - CP/M Instruction manual 5.0 Set up Minimum values or internal set-points Code 002 Set point 1, Voltage [%] Set point 2, Current [%] Set point 3, Power [%] Running mode 5.1 Configuration Code 003 E.S.O. = 0 = External Set point E.S.O.

  • Page 11: Minimum And Maximum Values

    REOTRON SMP CP - CP/M Instruction manual 5.2 Minimum and maximum values Code 020 Min ouptput voltage [%] (without external set point) Min output current [%] (without external set point) Min output power [%] (without external set point) Output voltage limit [%] Umax Output current limit [%] Imax...

  • Page 12: Reset Error Message

    REOTRON SMP CP - CP/M Instruction manual 5.3 Reset error message Code 009 Clear error An error message can also be cleared by pushing the green “I”-Button in the Display. 5.4 Save user parameters Code 143 Save current parameter settings Running mode 5.5 Recall saved settings Code 210...

  • Page 13: Service Menu

    REOTRON SMP CP - CP/M Instruction manual 5.7 Service menu Display the set-point values sent to the unit. Code 050 Display set point voltage [%] Display set point current [%] Display set point power [%] Running mode Display the effective values measured by the unit. Code 051 Display feedback voltage [%] Display feedback current [%]...

  • Page 14: Connections

    REOTRON SMP CP - CP/M Instruction manual 6.0 Connections REOTRON SMP CP & CP/M 24-5 REOTRON SMP CP & CP/M 48-10 /-20...

  • Page 15: Dimensions

    REOTRON SMP CP - CP/M Instruction manual 7.0 Dimensions REOTRON SMP CP 24-5...
  • Page 16 REOTRON SMP CP - CP/M Instruction manual REOTRON SMP CP/M 24-5...
  • Page 17 REOTRON SMP CP - CP/M Instruction manual REOTRON SMP CP 48-10 /-20...
  • Page 18 REOTRON SMP CP - CP/M Instruction manual REOTRON SMP CP/M 48-10 /-20...
  • Page 19 REOTRON SMP CP - CP/M Instruction manual...
  • Page 20 REO Shanghai Inductive Components Co., Ltd No. 536 ShangFeng Road · Pudong, 201201 Shanghai · China REO Vibratory Feeding and Power Electronics Division Tel.: +86 (0)21 5858 0686 · Fax: +86 (0)21 5858 0289 Brühler Straße 100 · D-42657 Solingen E-Mail: info@reo.cn ·...
