Replacing Your Unifi™ 45 Projector Lamp
Applies to: SMART Board™ 600i2 interactive whiteboard systems and Unifi™ 45 (UF45) projector retrofit kits for
SMART Board 560, 580, 660 and 680 interactive whiteboards

Overview

This document contains instructions for removing your Unifi 45 projector from its boom, removing the old lamp,
installing a new lamp, replacing the projector on its boom, and resetting the lamp timer. If a lamp fails or if a
replacement message appears on the screen of the Unifi 45 projector, a qualified person can replace the projector
lamp. Do not access the service panel without a replacement lamp and instructions in hand.
WARNING • If the projector is mounted on the boom, the manufacturer recommends contacting your
authorized SMART reseller
• Only qualified personnel should replace the projector lamp. Replacing the lamp in a
boom-mounted projector might result in a fall and injury.
• If you continue to use the projector after the replacement message appears, the lamp might
shatter or burst, scattering glass throughout the projector head.
• If the lamp has shattered or burst, do not touch the glass fragments because they might cause
injury. Leave and then ventilate the area where the lamp shattered or burst. Wash your hands
thoroughly if you have come into contact with lamp debris. Thoroughly clean the area around the
projector, and discard any edible items placed in that area because they might be contaminated.
• If the lamp has shattered or burst, call a
instructions. Do not attempt to replace the lamp.
• Remove the projector from the boom before servicing the lamp.
• Complete the procedure described in this document instead of the instructions included in your
replacement lamp box.
• Uncovering the lamp while the projector is mounted on a boom might lead to product damage or
personal injury from falling pieces of glass if the lamp is broken.
• Turn off the projector and wait 15 minutes for the lamp to cool completely before removing the old
lamp assembly.
• Wear protective eyewear while changing the lamp. Failure to do so can cause injury or loss of
eyesight if the lamp shatters or bursts.
• The lamp used in the Unifi 45 projector contains mercury. Recycle or dispose of it as hazardous
waste, in accordance with local regulations.
• To prevent premature lamp failure or exposure to mercury, always handle the fragile lamp
assembly with care. Use gloves when touching the lamp. Do not touch the lamp with your fingers.
• Use only the SB20 replacement lamp (SMART Part No. 01-00247).
• Never replace the lamp assembly with a previously used lamp assembly.
when the lamp must be exchanged.
SMART authorized service representative for
