Seuic AUTOID 7P Series Quick Start Manual

5. Please do not look directly into the laser beam of the
scan device during scanning to avoid eye injury.
6. Please connect the USB cable to the device first, then
connect it to the PC via USB port.
7. Please restart the device to replace the SIM/SD card.

Trouble shooting

1. In case of GPRS dialing stay on the validation page
without moving forward, please first check if your SIM card
shall be out of service.
2. If the device is not successfully connected to the PC,
please check whether the USB and the PDA be well
connected.
3. If the device can't enter into sleep mode, please check
whether terminal is using cellular or whether the terminal
is reading or writing data into NAND.

Technical support

Please visit SEUICofficial website www.chinaautoid.net to
download User Manual, SDK different APPs or software to
help you better use the device.2011 SEUIC
Technology. All rights reserved.No part of this publication
may be reproduced or used in any form, nor by any electrical
means without permission in written.
JIANGSU SEUIC TECHNOLOGY CO., LTD
Company address: NO.15.Xinghuo Road, Nanjing New High
Technology Industry Zone, Nanjing City, Jiangsu Province,China
Hotline: 0086-400-777-0876
Company official website:www.Seuic.com
Product official website:www.ChinaAUTOID.net
Mailbox:AUTOID@seuic.com
Post code:210061
6
JIANGSU SEUIC TECHNOLOGY CO.,LTD

QUICK START GUIDE

Charging indicator
Scan indicator
Scan button
Scan button
Power on/off button
SIM card slot
LED light on/off button
Memory card slot
(Figure 1)
End flap cable port
Applicable series ：
7P
®
Install battery and battery cover
Take out the device, the battery and the stylus pen
from the package, install the battery and battery
cover in according to he instruction label.
Initial Use
Please ensure the battery is with power supply to
boost up the system.
Open
Press the Power on/off button until the PDA vibrates.
Turn off
Press the Power on/off button for at least 5 seconds,
the indicator on the right corner goes off and device
shuts off. Or press the power on/off button for 3
seconds, tap Off on the prompted operation interface
and the device shuts off.
Sleep Mode
Press the Power on/off for 1 second during working
status,the device enters into sleep mode. Or the users
can press the Power on/off for at least 3 seconds for
the promoted operation interface, tap Sleep Mode to
enter into sleep.
Reset the device
(Figure 2)
How to reset the device
Either scan button in both sides of the device.
Keyboard scan button.
series
Keyboard power button.
Press the abovementioned three keys in the same
time and release them together can reset the system.
：
