Adtel DigADTEL IP Installation Instructions Manual

ADTEL ®
DigADTEL
®
The DigADTEL IP is a high quality digital on-hold announcer. It is designed to be attached to a 10BASE-T Ethernet
®
network to receive audio production updates via the Internet. These instructions will provide a detailed, illustrated guide on
how to properly attach and troubleshoot the DigADTEL
These instructions contain the following sections:

1.0 Package Contents

2.0 Hookup Instructions
2.1 Verify Hookup
3.0 Hookup Complete
4.0 Troubleshooting
1.0 Package Contents
Once you receive your DigADTEL
items are enclosed:
For Technical Assistance Please Call 1-800-661-9999
IP ON HOLD ANNOUNCER
IP audio announcer, check the packaging to ensure that all of the following
®
DigADTEL IP Audio Announcer
®
•
This is the audio announcer itself.
3.5mm mini-plug to bare wire audio cable
•
This cable is designed for new installations only. One end plugs into one of
the AUDIO OUT ports of the DigADTEL
punched down to a telephone termination block.
Category-5 patch cable
•
This cable is used to provide a 10BASE-T Ethernet connection between the
DigADTEL
router, etc.)
RCA to 3.5mm adaptor
•
This adaptor is to be used in existing installations. It converts an RCA style
connection to a 3.5mm connection. The DigADTEL
accept a 3.5mm connection.
Power Adaptor
•
This is the AC adaptor. It converts standard 120VAC current to the 12V that
the DigADTEL
DigADTEL
IP.
®
® IP unit and a piece of network equipment (i.e. a switch, hub,
IP unit requires.
®
® IP Installation Instructions
® IP unit and the other is
IP unit will only
®
