Summary of Contents for Kilitronik miniK10m
- Page 1 OPERATING MANUAL unique electronic cam lock Please read this manual before using the miniK10m and miniK10p...
-
Page 2: Table Of Contents
INDEX Description ........................3 Introduction ........................3 Usage ..........................4 Initial Setup ........................4 Assign Master Card ...................... 4 Selecting Operation Option Of The miniK10 ............. 4 Assign/Delete Service Card / Cards ................5 Assign User Card / Cards .................... 5 Deleting User Card ....................... -
Page 3: Description
Front Back DESCRIPTION: Besides the stylish and enriching design of the miniK10m / miniK10p cabinet lock, there are various features that make the lock different from others, such as allowing to use with wet hands, easy and quick installation at wood and steel cabinets, easy application at existing cabinets, easy application at right/left cabinet doors, higher battery life with very low energy consumption, high reliability and operating with a contactless card. -
Page 4: Usage
USAGE: Contactless card lock can be used with three types of cards: “User Card, Service Card and Master Card”. Also, the lock can be used with a password by selecting the user card free operation. Service card is passive by default. -
Page 5: Assign/Delete Service Card / Cards
• Assign/Delete Service card / cards: (If you don’t need to use any service card, skip this step) 1- Press , present the master card to the keypad and press green and red leds blink. 2- Press 5 for selecting service card assign / delete option. And then Press 0 for all service cards are deleted. -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS Personal operation with card (if selected) • To Unlock: 1- Press any number button for wake the lock up. 2- Present any assigned user card / master card / service card to the keypad in 3 seconds. 3- turn the handle to the unlocked position. •... -
Page 7: Locker Mode Operation With Card To Lock/ To Unlock
• To Unlock: 1- Press any number button for wake the lock up. 2- Present any card / master card / service card to the keypad in 3 sec. 3- Turn the handle to the unlocked position. Cardless personal operation (if selected) •... -
Page 8: To Lock With Password
• To Lock with Password: (default “1010”) 1- Enter the user password. 2- Turn the handle to the locked position. USER PASSWORD • To Lock with Card: 1- Press button for wake the lock up. 2- Present master card to the keypad in 3 seconds 3- Turn the handle to the locked position. -
Page 9: To Unlock With Password
• To Unlock with Password: 1- Enter the same password with locking operation. 2- Turn the handle to the unlocked position. LOCKER MODE PASSWORD • To Unlock with Cards: 1- Press button for wake the lock up. 2- Present master card / service card to the keypad in 3 seconds 3- Turn the handle to the unlocked position. -
Page 10: Locker Mode Operation With Card Or Password To Lock/Unlock
Locker Mode Operation with Card or Password to Lock/Unlock (if selected) • To Lock with Password: (default “1010”) 1- Enter the new password. 2- Turn the keypad to the locked position LOCKER MODE PASSWORD • To Unlock with Password: 1- Enter the same password with locking operation. 2- Turn the handle to the unlocked position. -
Page 11: To Lock With Any Card
• To Lock with any card: 1- Press button for wake the lock up. 2- Present any card to the keypad in 3 seconds. 3- Turn the handle to the locked position. • To Unlock with any card: 1- Press button for wake the lock up. -
Page 12: Programming Instuctions
PROGRAMMING INSTRUCTIONS 1- Press , present the master card and then press , green and red leds blink. 2- Enter the program number to be customized and then enter the selected settings number. (Press Program Number and then Selection Number) Restore Default Settings: Press 0 - 1 Default Settings are: Locker mode operation with card, audible operation, penalty operation is... -
Page 13: Light And Audio Warnings
Locking with password / card: Press 6 - 0 Locking operation require a password / card to lock. Automatic Locking (without password/card): Press 6 - 1 Locking operation does not require a password / card to lock. Warning of open door : Press 7 - 1 After door is open for one minute, lock gives an audible warning to user with 8 beeps every seconds to notify user that the door has been left open. -
Page 14: Program Table
Program Table Factory Settings Prog. No 1-1: Locker mode operation with card Prog. No 2-1: Audible beeps and confirmations Prog. No 3-0: Penalty operation PASSIVE Prog. No 4-0: Delete all user card Prog. No 5-0: Service card PASSIVE Prog. No 6-0: Locking with password Prog. -
Page 15: Maintenance
MAINTENANCE: - Clean front of lock with a mild damp cloth with detergent if needed. - Do not use any hard or scratching cleanser. - Do not clean with chemical materials that melt plastic (thinner, acetone, etc.) - Be careful not to spill water on lock. GENERAL WARNINGS: - Read manual before using lock. -
Page 16: Limited Warranty
LIMITED WARRANTY: Kilitronik offers a one year limited warranty all products to be free from manufacturing defects in materials and workmanship. This warranty does not cover the battery, lost combinations or damages caused by improper mounting, improper or unreasonable use. - Page 17 K10p CARD SPECIFICATIONS: Operating Frequency 125KHz Data Coding Type Manchester Coding Data Memory 64 bit Example Appropriate Card em4100 card from EM Microelectronic-Marin K10m APPROPRIATE CARD: MIFARE Classic®, MIFARE® DESFire® cards... Thank you Congratulations for making this eco-friendly choice! By purchasing a miniK10, you will prevent additional batteries going to the landfills over the up to 5 years.
-
Page 18: Quick Info
QUICK INFO LOCKING / UNLOCKING WITH USER CARD LOCKING / UNLOCKING WITH MASTER CARD If cardless personal operation option or cardless locker mode operation option is selected, you should press button at first to lock and unlock by using the master card. Page 18... - Page 19 Notes: ................................................................................................................................................................................................................................................
- Page 20 Hospitals Schools Baths Mailboxes Sports Halls Staff Lockers www.kilitronik.com Vemus Endüstriyel Elektronik San. Ve Tic. Ldt. Şti. NOSAB Zeytin C.14 16220 Nilüfer / BURSA + 90 224 411 10 30 + 90 224 411 10 31 are trademarks of Rev.00 011 580 0589 VEMUS Endüstriyel Elektronik Ltd.
