Eminent EM1500 Quick Start Manual

Dual Display Docking Station USB 3.1 Gen1 (USB 3.0)
Turn your laptop easily into a desktop computer
EM1500
EAN: 8716065338287
Mastercarton: 6
Packaging contents: - EM1500, Power supply, USB 3.1 (gen1) Connection Cable Type A-B,
Stand, DVI-VGA adapter, CD-ROM with drivers, Quick Install Guide

OVERVIEW

Connect up to 2 full HD screens (max. 2048x1152) to your laptop via the HDMI, DVI/VGA port
Easily connect your laptop to all peripherals with only one USB cable
Add 6 extra USB ports to your laptop: 4x USB 2.0 on the rear and 2x USB 3.1 Gen1 (USB 3.0) on the front
USB 3.1 Gen1 (USB 3.0) cable, DVI to VGA adapter and power adapter included
Vertical placement for saving space on your desk and better access to all connections
Suitable for charging your smartphone and tablet via the USB ports
Gigabit LAN port, microphone and headphone connections
Suitable for all laptops with a USB 3.1 Gen1 (USB 3.0) or USB 2.0 port

SPECIFICATIONS

• Hostinterface: USB 3.1 Gen1 (USB 3.0) Type A-B
• USB ports: 4x USB 2.0 Type A
2x USB 3.1 Gen1 (USB 3.0) Type A (with 1x Fast charging USB port)
• LAN: 1x RJ45 Gigabit ethernet port
• Video connections: 1 x HDMI: Maximum resolution: 2048x1152p
1x DVI: Maximum resolution: 2048x1152p
1x DVI-VGA adapter for analog video output
• Audio: 1x 3,5mm jack for Microphone
1x 3,5mm jack stereo audio output (Headphone, 2.0 speakers)
• Dimensions in mm (WxHxD): 31x76x182
• Weight: 221g
• Colour: Black
• Power supply: 5V 4A
• Including: 1x DVI-VGA adapter for analog video output

DESCRIPTION

Turn you laptop in a complete working station with help of the EM1500 USB 3.1 Gen1
(USB 3.0) Dual Monitor Laptop Docking Station. Connect easily all peripherals like
your screen, mouse, keyboard and networking cable to your laptop by using only one
USB cable. You can connect your headphones and microphone to the docking station
as well.
The EM1500 lets you connect up to 2 full HD screens to your laptop via the HDMI
or DVI/VGA port. Besides, your laptop will be extended with 6 additional USB ports.
These USB ports enable you to connect peripherals or to charge your smartphone
and tablet: 4x USB ports 2.0 on the rear and 2x USB 3.1 Gen1 (USB 3.0) ports on
the front. The Docking Station is equipped with a Gigabit LAN networking port, mi-
crophone and headphones connection. All connections are easily accessible, thanks
to the space-saving design.
Enclosed you will find a USB 3.1 Gen1 (USB 3.0) cable, DVI to VGA adapter and po-
wer adapter.
No rights may be derived from inaccurately presented content. Eminent cannot be held liable or responsible for inaccurately presented content.
