Page 2
- STELLEN SIE KEINE FLÜSSIGKEITS elektrischen und elektronischen Geräten GEFÜLLTEN Entsprechend der Firmengrundsätze der GEFÄSSE WIE VASEN AUF DAS GERÄT ACME the game company GmbH wurden - VERWENDEN SIE AUSSCHLIESSLICH hochwertige wiederverwertbare Komponenten EMPFOHLENE ZUBEHÖRTEILE in diesem Produkt verbaut. Dieses Symbol auf - DEMONTIEREN SIE NICHT DAS GERÄT...
Page 3
Installation des FPV-Kopfes Um die Sensoreinheit zu wechseln, drehen Sie den Kamerakopf bis die Schrauben sichtbar werden. Lösen Sie die vier Schrauben mit einem kleinen Kreuzschlitz- Schraubendreher. Ziehen Sie die Sensoreinheit vorsichtig vom Stecker des Flachbandkabels ab. Verbinden Sie nun das Flachbandkabel des Kopfes mit dem der Kamera wie abgebildet.
Page 4
Installation of the FPV-Head To replace the sensor unit, turn the head of the camera until you can see the screws. Remove these four screws with the appropriate screwdriver. Carefully disconnect the sensor unit from the plug of the ribbon cable. Now connect the ribbon cable of the FPV-head with the one of the cam as shown on the picture.
Page 5
Installation de la tête FPV Pour remplacer la lentille et le capteur, vous devez accéder aux vis présentes sur la face arrière de la tête de la caméra. Utilisez pour cela le tournevis adéquat. Une fois que vous avez dévissé les vis, vous allez accéder au capteur et à...
Page 6
FlyCamOne HD, los servos tienen que ser conectados a los canales 5 y 6. La cabeza FPV tiene 4 hoyos sobre sus lados permitiéndole de fijar el todo a su modelo. ACME the game company GmbH Industriestr. 10a 33397 Rietberg Germany...
