Product Information:
The ArrowStar XP is a stand-alone, steady burn LED light bar that is wired for negative switched
arrowstick traffic director controllers. Each module in the bar will come with its own -12vdc ground wire
and common +12vdc positive. Each ArrowStar XP comes standard with a Sho-Me 11.1025 series rotary
switch traffic director controller.
Wiring Instructions:
The ArrowStar XP comes standard with approx. eighteen feet of hook-up cable. In this cable there will be
multiple wires. Total number of wires depends on length of bar. Connect the following wires to the Sho-
Me controller color for color. (DO NOT REVERSE POLARITY. DAMAGE MAY OCCUR):
Section
1
White
2.
Black
3.
Brown
4.
Green
5.
Violet
6.
Orange
7.
Yellow
8.
Blue
X.
Red
Red wire on Sho-Me or +12vdc
X.
Grey Red wire on Sho-Me or +12vdc
Technical Information:
Optimal operating voltage: 12 – 14 VDC
Operating current: .47 amps per four inch module
Installation Instructions:
To install the included swivel brackets, remove the end cap screws (two on each end). Place the bracket
over the end cap and re-install both screws. Do not fully tighten screws until you have the proper swivel
position for your installation. To use the suction cups (interior only), install the screw stud into the suction
cup and then install into the swivel bracket using brass nut.
ArrowStar XP
AS-48-XP
